Каталог запасных частей к технике: ChengGong CG-932H. Z33E0301T7 Combining Gear Set
1
2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
23
24
26
27
28
29
30
31
32
33
34
34
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
49
50
51
52
53
54
55
56
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z33E030101T7 | Powe Shift Pump | |
| 2 | ZL30B.3.1.2 | Exceed Clutch | |
| 4 | ZL30B.3.1.3-6 | Union | |
| 5 | 05C3201 | Breather | |
| 6 | ZL30B.3.1-1 | 2nd Input Gear | |
| 7 | ZL30B.3.1-2 | 1st Input Gear | |
| 8 | ZL30B.3.1-3 | Oil Seal Ring-2nd Gear | |
| 9 | ZL30B.3.1-4 | Oil Seal Ring-1st Gear | |
| 10 | ZL30B.3.1-5A | Bushing | |
| 11 | ZL30B.3.1-6 | Spacer | |
| 12 | ZL30B.3.1-7 | Copper Pipe | |
| 13 | Z33E030100001T7 | Housing | |
| 14 | ZL30B.3.1-9 | Gasket | |
| 15 | ZL30B.3.1-10A | Shaft-Oil Pump | |
| 16 | ZL30B.3.1-11 | Spacer | |
| 17 | ZL30B.3.1-12 | Valve Cover | |
| 18 | ZL30B.3.1-13 | Adjusting Screw | |
| 19 | ZL30B.3.1-14 | Nut | |
| 20 | ZL30B.3.1-15 | Gasket | |
| 21 | ZL30B.3.1-16 | Spring | |
| 23 | ZL30B.3.1-18 | Clip | |
| 24 | ZL30B.3.1-19 | Valve | |
| 26 | ZL30B.3.1-21A | Shaft-Steering Pump | |
| 27 | Z33E030100002T7 | Flange-Steering Pump | |
| 28 | Z33E030100003T7 | Protective Sheet | |
| 29 | ZL30B.3.1-24 | Gear | |
| 30 | ZL30B.3.1-25 | Spacer | |
| 31 | GB/T3452.1-2005 | O-Ring | |
| 32 | GB/T3452.1-2005 | O-Ring | |
| 33 | GB/T5783-2000 | Connector | |
| 34 | GB/T93-87 | Washer 20 | |
| 35 | GB/T276-94 | Bearing | |
| 36 | GB/T276-94 | Bearing | |
| 37 | GB/T276-94 | Bearing | |
| 38 | GB/T301-95 | Bearing | |
| 39 | GB/T276-94 | Bearing | |
| 40 | GB/T6170-86 | Nut | |
| 41 | GB/T93-87 | Washer 20 | |
| 42 | GB/T5783-2000 | Connector | |
| 43 | GB/T276-94 | Bearing | |
| 44 | GB/T276-94 | Bearing | |
| 45 | GB/T893.1-86 | Snap Ring | |
| 46 | GB/T276-94 | Bearing | |
| 47 | GB/T70.1-2000 | Bolt M10X100 | |
| 48 | GB/T276-94 | Bearing | |
| 49 | GB/T5783-2000 | Connector | |
| 50 | GB/T93-87 | Washer 20 | |
| 51 | HG4-692-67 | Oil Seal PD60x80x12 | |
| 52 | HG4-692-67 | Oil Seal PD60x80x12 | |
| 53 | GB/T898-88 | Stud | |
| 54 | GB/T5783-2000 | Connector | |
| 55 | 1CH-30-27 | Union | |
| 56 | GB/T93-87 | Washer 20 |
