Каталог запасных частей к технике: Changlin ZL50H. Z50G.14T Hydraulic System (4)
1
2
3
4
5
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
20
20
21
22
23
23
24
25
26
27
28
28
29
30
31
32
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Z50G.34.5 | Oil tank | |
| 2 | B-G000930-00017 | Washer | |
| 3 | B-G057830-00143 | Bolt | |
| 4 | B-Q020710-00094 | O-ring | |
| 5 | B-G057830-00053 | Bolt | |
| 6 | B-G00097B-00006 | Washer | |
| 7 | Z50G.34-1 | Hose | |
| 8 | B-J088700-00020 | Clamp | |
| 9 | Z50G.14G.2 | Oil pipe | |
| 10 | B-Q020710-00006 | O-ring | |
| 11 | W-16-00957 | Hose | |
| 12 | W-15-00108 | O-ring | |
| 13 | B-G057830-00009 | Bolt | |
| 14 | B-J010020-00003 | Washer | |
| 15 | B-Q020140-00003 | Separated flange | |
| 16 | Z50G.14T.2 | Hose | |
| 17 | Z30.4M-2 | Joint body | |
| 18 | B-J010020-00003 | Washer | |
| 19 | B-G057830-00037 | Bolt | |
| 20 | B-G000930-00003 | Washer | |
| 21 | B-J010000-00002 | Plug screw | |
| 22 | Z50G.14T.3 | Oil pipe | |
| 23 | B-Q020710-00077 | 0-ring | |
| 24 | B-G000930-00001 | Washer | |
| 25 | B-G057830-00010 | Bolt | |
| 26 | B-Q020710-00099 | O-ring | |
| 27 | Z50E.14N.3 | Oil pipe | |
| 28 | B-J088700-00018 | Clamp | |
| 29 | Z50G.14-2 | Hose | |
| 30 | W-01-00021 | Pump | |
| 31 | Z50G.14D.1 | Oil pipe | |
| 32 | B-G057830-00009 | Bolt |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
