Каталог запасных частей к технике: CASE IH WX-188 (часть 1). 10.254.01 - INTAKE MANIFOLD

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано Ammann BOMAG CARMIX CASE IH Changlin ChengGong Dimex Doosan DYNAPAC Foton HAMM Hidromek Hitachi Hyundai JCB JLG John Deere Komatsu LIEBHERR LiuGong Lonking (LongGong) Luneng MANITOU Mitsuber New Holland PENGPU RM-Terex SANY SDLG SEM Shantui Shehwa HBXG Soosan TIGARBO VOGELE Volvo WAY WIRTGEN XCMG XGMA Xiamen YTO Yuchai Zoomlion Автокран АЗСМ Алтайлесмаш Амкодор АОМЗ Атек АТЗ Балканкар Рекорд БелАЗ Беловеж Борекс Брянский Арсенал Булат ВЭКС ГАЗ Геомаш Гидромаш Донекс Дормаш Дормашина Дорэлектромаш ДЭЗ ЕлАЗ ЗЗГТ Ижнефтемаш Канаш-электрокар КЗКТ ККЗ Клевер Клинцовский автокрановый завод КМЗ КМЗ 1 Мая Ковровец Коммаш Кранэкс КЭЗ КЭМЗ ЛЗА МАЗ МЗИК МЗКМ МЗКТ Михневский РМЗ МоАЗ Мозырский МЗ МТЗ ОЗП Онежец ПАО "ТЗА" ППС Детва Промтрактор ПТЗ Раскат СпецАгрегат ТВЭКС ТТМ УВЗ Угличмаш УЗТМ ХТЗ ЧЗКМ ЧСДМ ЧТЗ ЭКСКО ЭКСМАШ ЮрМаш

Модель Не выбрано 595LSP, 595SLE (2010) 695ST (часть 1) (2015) 695ST (часть 2) (2015) 695ST (часть 3) (2015) 695ST Tier 4A (часть 1) (2012) 695ST Tier 4A (часть 2) (2012) 695ST Tier 4A (часть 3) (2012) 821F (2011) 845 (2002) 921F (2011) Case-430 (2005) Case-570T (2010) Case-580T (часть 1) (2012) Case-580T (часть 1) (2016) Case-580T (часть 2) (2012) Case-580T (часть 2) (2016) SR250 (2012) SV300 (2012) TR270 (2014) TR320 (2012) TV380 (2012) WX-188 (часть 1) (2014) WX-188 (часть 2) (2014)

Схема > Не выбрано 00.000.02(01) - MAINTENANCE PARTS 05.100.01(01) - INITIAL STOCKING LIST 10.001.01 - ENGINE 10.001.02 - CRANKCASE 10.001.03 - CRANKCASE 10.012.01(01) - ENGINE SUSPENSION 10.012.04 - HOOKS - ENGINE 10.101.01 - CYLINDER HEAD 10.101.02 - CYLINDER HEAD COVERS 10.101.03 - BREATHER - ENGINE 10.102.01 - ENGINE OIL SUMP 10.102.02 - CRANKCASE COVERS 10.103.01 - CRANKSHAFT 10.103.02 - FLYWHEEL 10.103.03 - CRANKCASE COVERS 10.105.01 - PISTON - ENGINE 10.105.02 - CONNECTING ROD 10.106.01 - CAMSHAFT - TIMING CONTROL 10.106.02 - ROCKER SHAFT 10.106.03 - CRANKCASE COVERS 10.110.01 - PULLEY - CRANKSHAFT 10.114.02 - POWER TAKE OFF 10.202.01(01) - AIR CLEANER 10.202.01(02) - AIR CLEANER 10.206.01(02) - PRIMARY FUEL FILTER 10.206.01 - FUEL FILTER 10.206.02 - OIL FILTERS - ENGINE 10.210.01(02) - PIPING FUEL 10.210.01 - FUEL PUMP 10.210.02(01) - VAR - 781268 - FUEL TRANSFER PUMP 10.210.03 - PIPING FUEL 10.214.01(01) - PIPING FUEL - END YR 14-OCT-2014 10.214.01(01A) - PIPING FUEL - BEGIN YR 19-MAY-2014 10.216.01(01) - FUEL TANK 10.218.01 - INJECTION EQUIPMENT - PIPING 10.218.02 - INJECTION EQUIPMENT - INJECTOR 10.218.03 - INJECTION EQUIPMENT - PIPING 10.218.04 - INJECTION EQUIPMENT - PIPING 10.218.05 - PIPING - FUEL 10.221.01(01) - ACCELERATOR - CONTROLS 10.240.01 - INJECTION PUMP 10.240.02 - INJECTION PUMP - CONTROL 10.250.01 - TURBOCHARGING 10.254.01 - INTAKE MANIFOLD 10.254.02(01) - MUFFLER 10.254.05 - EXHAUST MANIFOLD 10.304.01(01) - PUMP, ENGINE OIL & RELATED PARTS 10.304.01(02) - PUMP, ENGINE OIL & RELATED PARTS 10.304.01(03) - PIPING ENGINE OIL 10.304.05 - PIPING - ENGINE OIL 10.400.01 - PIPING - ENGINE COOLING SYSTEM 10.400.02(01) - RADIATOR 10.402.01 - THERMOSTAT - ENGINE COOLING SYSTEM 10.402.02 - WATER PUMP 10.402.03 - WATER PUMP - CONTROL 10.406.01(01) - RADIATOR - END YR 14-MAR-2015 10.406.01(01A) - RADIATOR - BEGIN YR 15-MAR-2015 10.406.01(02) - RADIATOR, COMPONENTS 10.408.01(02) - RADIATOR 10.408.01 - HEAT EXCHANGER - ENGINE 10.408.02 - INTAKE MANIFOLD - HEATER 10.408.03 - HEAT EXCHANGER - ENGINE 10.414.01(01) - ENGINE - FAN 21.113.01(01) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE TRANSMISSION GEAR - HOUSING & COVERS 21.113.01(01A) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE, TRANSMISSION, GEAR, HOUSING & COVERS - BEGIN YR 23-MAY-2014 21.113.02(01) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE TRANSMISSION GEAR - HOUSING - END YR 22-MAY-2014 21.113.02(01A) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE, TRANSMISSION, GEAR, HOUSING - BEGIN YR 23-MAY-2014 21.113.03(01) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE TRANSMISSION GEAR - CLUTCH DISC - END YR 22-MAY-2014 21.113.03(01A) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE, TRANSMISSION, GEAR, CLUTCH DISC - BEGIN YR 23-MAY-2014 21.113.03(02) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE TRANSMISSION GEAR - CLUTCH DISC - END YR 22-MAY-2014 21.113.03(02A) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE, TRANSMISSION, GEAR, CLUTCH DISC - BEGIN YR 23-MAY-2014 21.113.04(01) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE TRANSMISSION GEAR - LUBE PUMP - OIL - END YR 22-MAY-2014 21.113.04(01A) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE, TRANSMISSION, GEAR, LUBE PUMP, OIL- BEGIN YR 23-MAY-2014 21.113.05(01) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE TRANSMISSION GEAR - PLANETARY - END YR 22-MAY-2014 21.113.05(01A) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE TRANSMISSION GEAR - PLANETARY - BEGIN YR 23-MAY-2014 21.113.06(01) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE TRANSMISSION GEAR - OUTPUT SHAFT GROUP - END YR 22-MAY-2014 21.113.06(01A) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE, TRANSMISSION, GEAR, OUTPUT SHAFT, GROUP - BEGIN YR 23-MAY-2014 21.113.07(01) - VAR - 461150, 461151, 461153, 461155, 461252, 461253, 461254, 461256 -UNDERCARRIAGE, TRANSMISSION, GEAR - BEGIN YR 23-MAY-2014 23.314.01(01) - VAR - 461163 - 20 KM/H VERSION - TRANSMISSION SHAFT 23.314.0101(01) - VAR - 461512 - 35 KM/H VERSION - TRANSMISSION SHAFT 25.100.01(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) - FRONT AXLE 25.100.01(02) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) - FRONT AXLE 25.100.0101(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) -FRONT AXLE 25.100.0101(02) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) -FRONT AXLE 25.100.02(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) - FRONTAXLE - HOUSING AND JOINTS 25.100.0201(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) -FRONT AXLE - HOUSING AND JOINTS 25.102.01(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) - FRONTAXLE - BEVEL GEAR 25.102.0101(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) -FRONT AXLE - BEVEL GEAR 25.102.02(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) - FRONTAXLE - DIFFERENTIAL - END YR 14-OCT-2015 25.102.02(01A) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT), FRONTAXLE, DIFFERENTIAL - BEGIN YR 15-OCT-2015 25.102.0201(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) -FRONT AXLE - DIFFERENTIAL - END YR 14-OCT-2015 25.102.0201(01A) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT),FRONT AXLE, DIFFERENTIAL - BEGIN YR 15-OCT-2015 25.108.01(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) - FRONTAXLE SHAFT 25.108.0101(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) -FRONT AXLE SHAFT 25.108.02(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) - FRONTAXLE - WHEEL JOINT 25.108.0201(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) -FRONT AXLE - WHEEL JOINT 25.108.03(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) - FRONTAXLE- WHEEL RIM STUD 25.108.0301(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) -FRONT AXLE- WHEEL RIM STUD 27.100.01(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) - REARAXLE 27.100.01(02) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) REARAXLE 27.100.0101(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) - REARAXLE 27.100.0101(02) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) REARAXLE 27.106.01(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) REARAXLE BEVEL GEAR - GROUP 27.106.0101(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) REARAXLE BEVEL GEAR - GROUP 27.106.02(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) REARAXLE DIFFERENTIAL 27.106.0201(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) REARAXLE DIFFERENTIAL 27.108.03(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) - REARAXLE- WHEEL RIM STUD 27.120.01(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) REARAXLE HOUSING 27.120.0101(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) REARAXLE HOUSING 27.124.01(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) REARAXLE WHEEL HUB & REDUCTION GEAR 27.124.0101(01) - VAR - 461252, 461253, 461254, 4612565 - UNDERCARRIAGE (L=2,75MT) REARAXLE WHEEL HUB & REDUCTION GEAR 33.202.01(01) - BRAKE PEDAL 33.202.01(02) - BRAKE - LINES 33.202.01(03) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) - BRAKE- LINES 33.202.0101(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) -BRAKE - LINES 33.202.02(01) - VAR - 461150, 461151, 461153, 461155 - UNDERCARRIAGE (L=2,50MT) -FRONT/REAR AXLE - WHEEL HUB & BRAKE GROUP 33.202.0201(01) - VAR - 461252, 461253, 461254, 461256 - UNDERCARRIAGE (L=2,75MT) -FRONT/REAR AXLE - WHEEL HUB & BRAKE GROUP 35.106.01(01) - COUPLING/CLUTCH INSTAL 35.106.01(02) - VARIABLE DELIVERY HYDRAULIC PUMP 35.106.01(03) - VARIABLE DELIVERY HYDRAULIC PUMP - BREAKDOWN 35.106.01(04) - VARIABLE DELIVERY HYDRAULIC PUMP - BREAKDOWN 35.106.01(05) - VARIABLE DELIVERY HYDRAULIC PUMP - BREAKDOWN 35.106.01(06) - VARIABLE DELIVERY HYDRAULIC PUMP - BREAKDOWN 35.106.01(07) - VARIABLE DELIVERY HYDRAULIC PUMP - BREAKDOWN 35.300.01(01) - HYD. OIL TANK 35.300.01(02) - HYD. OIL TANK INSTALL 35.304.01(01) - GEAR PUMP INSTALLATION 35.304.01(02) - GEAR PUMP - BREAKDOWN 35.322.01(01) - VAR - 461150, 461151, 461153 - UNDERCARRIAGE SOLENOID VALVE 35.322.01(02) - UNDERCARRIAGE SOLENOID VALVE - BREAKDOWN 35.322.0101(01) - VAR - 461151, 461253 - 2 STABS WELDED - UNDERCARRIAGE SOLENOIDVALVE 35.322.0101(02) - VAR - 461151, 461253 - UNDERCARRIAGE SOLENOID VALVE - BREAKDOWN 35.322.0102(01) - VAR - 461153, 461254 - FRONT BLADE/REAR STABILIZERS WELDED -UNDERCARRIAGE SOLENOID VALVE 35.322.0103(01) - VAR - 461155, 461256 - FRONT/REAR STABILIZERS (2 BOLTED-2 WELDED) -UNDERCARRIAGE SOLENOID VALVE 35.322.0103(02) - VAR - 461155, 461256 - UNDERCARRIAGE SOLENOID VALVE - BREAKDOWN 35.322.02(01) - HYDRAULIC SYSTEM LOWER CARRIAGE 35.322.0201(01) - VAR - 461151, 461253 - 2 STABS WELDED - HYDRAULIC SYSTEM LOWERCARRIAGE 35.322.0202(01) - VAR - 461153, 461254 - FRONT BLADE/REAR STABILIZERS WELDED -HYDRAULIC SYSTEM LOWER CARRIAGE 35.322.0203(01) - VAR - 461155, 461256 - FRONT/REAR STABILIZERS (2 BOLTED-2 WELDED) -HYDRAULIC SYSTEM LOWER CARRIAGE 35.352.01(01) - SWING MOTOR - BSN NFLB04725 35.352.01(01A) - SWING MOTOR - ASN NFLB04724 35.352.01(02) - SWING MOTOR - BREAKDOWN 35.352.01(03) - SWING MOTOR - BREAKDOWN 35.352.01(04) - SWING MOTOR - BREAKDOWN 35.352.01(05) - SWING MOTOR - BREAKDOWN 35.352.01(06) - SWING MOTOR - BREAKDOWN 35.353.01(01) - HYDRAULIC SYSTEM LOWER CARRIAGE 35.353.02(01) - VAR - 461163 - 20 KM/H VERSION - TRAVEL MOTOR 35.353.02(02) - VAR - 461163 - 20 KM/H VERSION - TRAVEL MOTOR - BREAKDOWN 35.353.02(03) - VAR - 461163 - TRAVEL VALVE - BREAKDOWN 35.353.0201(01) - VAR - 461512 - 35 KM/H VERSION - TRAVEL MOTOR 35.353.0201(02) - VAR - 461512 - 35 KM/H VERSION - TRAVEL MOTOR - BREAKDOWN 35.353.03(01) - VAR - 461512 - 35 KM/H VERSION - HYDRAULIC SYSTEM - UPPER 35.353.04(01) - VAR - 461150, 461151, 461153, 461155, 461252, 461254, 461256 - PIPING,TRAVEL 35.354.01(01) - JOINT SWIVEL 35.354.01(02) - JOINT SWIVEL - BREAKDOWN 35.354.01(03) - JOINT SWIVEL 35.355.01(02) - SOLENOID VALVE - BREAKDOWN 35.355.01(03) - SOLENOID VALVE - BREAKDOWN 35.355.01(04) - SOLENOID VALVE - LINES 35.355.01(05) - SOLENOID VALVE - LINES 35.359.01(01) - CONTROL VALVE - MOUNTING 35.359.01(02) - CONTROL VALVE - VERSION 01 - BREAKDOWN 35.359.01(03) - CONTROL VALVE - VERSION 01 - 02 - BREAKDOWN 35.359.01(04) - CONTROL VALVE - VERSION 01 - 02 - BREAKDWON 35.359.01(05) - PILOT VALVE 35.359.01(06) - CONTROL VALVE - VERSION 01 - 02 - BREAKDOWN 35.359.01(07) - CONTROL VALVE - VERSION 01 - 02 - BREAKDOWN 35.359.01(08) - CONTROL VALVE - VERSION 01 - 02 - BREAKDOWN 35.359.01(09) - CONTROL VALVE - VERSION 01 - 02 - BREAKDOWN 35.359.01(10) - CONTROL VALVE - VERSION 01 - BREAKDOWN 35.359.01(11) - PRESSURE CONTROL VALVE 35.359.01(12) - VALVE - PRESSURE COMPENSATOR 35.359.01(13) - CONTROL VALVE - BREAKDOWN 35.359.01(14) - CONTROL BLOCK - VERSION 01 - 02 - BREAKDOWN 35.359.01(15) - CONTROL VALVE - VERSION 02 - BREAKDOWN 35.359.01(16) - CONTROL VALVE - VERSIONI 02 - BREAKDOWN 35.359.01(17) - HYDRAULIC CONTROL VALVE - VERSION 02 - BREAKDOWN 35.360.01(01) - HAMMER VALVE - BREAKDOWN 35.360.02(01) - VAR - 461533, 461534, 461535 - NIBBLER & BREAKER - HYD LINES - VERSION01 35.360.02(02) - VAR - 461533, 461534, 461535 - NIBBLER & BREAKER - SOLENOID VALVE -BREAKDOWN 35.360.02(03) - VAR - 461533, 461534, 461535 - NIBBLER & BREAKER - SOLENOID VALVE -BREAKDOWN 35.360.02(04) - VAR - 461533, 461534, 461535 - NIBBLER & BREAKER - HYD LINES - VERSION01 35.360.02(05) - VAR - 461533 - NIBBLER & BREAKER (L=2,2MT) - HYD LINES 35.360.02(06) - VAR - 461533, 461534, 461535 - NIBBLER & BREAKER - HYD LINES - VERSION02 35.360.02(07) - VAR - 461533, 461534, 461535 - NIBBLER & BREAKER - HYD LINES - VERSION02 35.360.02(08) - VAR - 461533, 461534, 461535 - NIBBLER & BREAKER - HYD LINES - VERSION02 35.360.0201(05) - VAR - 461534 - NIBBLER & BREAKER (L=2,6MT) - HYD LINES 35.360.0202(05) - VAR - 461535 - NIBBLER & BREAKER (L=3,1MT) - HYD LINES 35.360.03(01) - VAR - 461535, 461534, 461533 - CHECK VALVE 35.360.03(02) - VAR - 461535, 461534, 461533 - CHECK VALVE - BREAKDOWN 35.595.01(01) - GREASE SYSTEM - VERSION 01 35.595.01(02) - GREASE SYSTEM - BSN NCLE04388 35.595.01(02A) - GREASE SYSTEM - ASN NCLE04389 35.595.01(03) - GREASE SYSTEM - BSN NCLE04388 35.595.01(03A) - GREASE SYSTEM - ASN NCLE04389 35.700.01(01) - PUMP - HYD LINES 35.700.01(02) - PUMP - HYD LINES 35.700.01(03) - PUMP - HYD LINES 35.700.01(04) - PUMP - HYD LINES 35.702.01(01) - MAIN PIPING 35.702.01(02) - MAIN PIPING - VERSION 01 35.702.01(03) - MAIN PIPING 35.702.01(04) - MAIN PIPING 35.702.01(05) - MAIN PIPING - VERSION 02 35.702.02(01) - BOOM PIPING - VERSION 01 35.702.02(02) - BOOM PIPING - VERSION 02 35.702.02(03) - BOOM PIPING - VERSION 02 35.702.02(04) - BOOM PIPING - VERSION 02 35.702.02(05) - BOOM PIPING - VERSION 02 35.702.03(01) - PIPE-BREAK PROTEC. BOOM CYLINDERS - VERSION 01 35.702.03(02) - PIPE-BREAK PROTEC. BOOM CYLINDERS - VERSION 02 35.705.01(01) - RETURN LINE 35.705.01(02) - RETURN LINE 35.726.01(01) - VAR - 461527, 461528, 461529 - GRAB ROTATION 22L/MIN. - HYD. LINES 35.726.01(02) - VAR - 461527, 461528, 461529 - GRAB ROTATION 22L/MIN. - VALVE -BREAKDOWN 35.726.0101(01) - VAR - 461530, 461531, 461532 - GRAB ROTATION 80L/MIN. - HYD. LINES 35.726.0101(02) - VAR - 461530, 461531, 461532 - GRAB ROTATION 80L/MIN. - LOW FLOWVALVE - BREAKDOWN 35.726.0101(03) - VAR - 461530, 461531, 461532 - GRAB ROTATION 80L/MIN. - LOW FLOWVALVE - BREAKDOWN 35.726.0101(04) - VAR - 461530, 461531, 461532 - GRAB ROTATION 80L/MIN. - LOW FLOWVALVE ON/OFF - BREAKDOWN 35.726.02(01) - VAR - 461527, 461528, 461529, 461530, 461531, 461532 - GRAB ROTATION22L/MIN. - 80L/MIN. - HYD. LINES - VERSION 01 35.726.02(02) - VAR - 461527, 461528, 461529, 461530, 461531, 461532 - GRAB ROTATION22L/MIN. - 80L/MIN. - HYD. LINES - VERSION 02 35.726.02(03) - VAR - 461527, 461528, 461529, 461530, 461531, 461532 - GRAB ROTATION22L/MIN. - 80L/MIN. - HYD. LINES - VERSION 02 35.726.03(01) - VAR - 461527, 461530 - GRAB ROTATION 22L/MIN. - 80L/MIN. (L=2,2MT) - HYD.LINES 35.726.0301(01) - VAR - 461528, 461531 - GRAB ROTATION 22L/MIN. - 80L/MIN. (L=2,6MT) -HYD. LINES 35.726.0302(01) - VAR - 461529, 461532 - GRAB ROTATION 22L/MIN. - 80L/MIN. (L=3,1MT) -HYD. LINES 35.726.04(01) - VAR - 461527, 461528, 461529, 461530, 461531, 461532 - GRAB ROTATION22L/MIN. - 80L/MIN. - HYD. LINES 35.726.05(01) - VAR - 461527, 461528, 461529 - GRAB ROTATION 22L/MIN., JOYSTICK - END YR14-JAN-2015 35.726.05(01A) - VAR - 461527, 461528, 461529 - GRAB ROTATION 22L/MIN., JOYSTICK -BEGIN YR 15-JAN-2015 35.726.0501(01) - VAR - 461530, 461531, 461532 - GRAB ROTATION 80L/MIN., JOYSTICK - ENDYR 14-JAN-2015 35.726.0501(01A) - VAR - 461530, 461531, 461532 - GRAB ROTATION 80L/MIN., JOYSTICK -END YR 15-JAN-2015 35.730.01(01) - POSITIONER CYLINDER INSTAL - VERSION 02 35.730.01(02) - POSITIONER CYLINDER - BREAKDOWN 35.732.01(01) - VAR - 461151, 461153, 461155, 461253, 461254, 461256 - STABILIZER CYLINDER- BREAKDOWN 35.732.02(01) - VAR - 461151, 461153, 461253, 461254 - STABILIZER CYLINDER - LINES 35.736.01(01) - LIFT CYLINDER - VERSION 01 35.736.01(02) - LIFT CYLINDER - VERSION 01 - BREAKDOWN 35.736.01(03) - SAFETY VALVE - LEFT SIDE - VERSION 01 35.736.01(04) - SAFETY VALVE - RIGHT SIDE - VERSION 01 35.736.01(05) - LIFT CYLINDER - VERSION 02 35.736.01(06) - LIFT CYLINDER - VERSION 02 - BREAKDOWN 35.736.01(07) - SAFETY VALVE - LEFT SIDE - VERSION 02 35.736.01(08) - SAFETY VALVE - RIGHT SIDE - VERSION 02 35.737.01(01) - ARM CYLINDER INSTAL 35.737.01(02) - ARM CYLINDER - BREAKDOWN 35.737.02(01) - VAR - 461212 - ARM PIPING W/O SAFETY VALVE - VERSION 01 35.737.02(02) - VAR - 461212 - ARM PIPING W/O SAFETY VALVE - VERSION 02 35.737.0201(01) - VAR - 461213 - OBJECT HANDLING - HYD. LINE - VERSION 01 35.737.0201(02) - VAR - 461213 - OBJECT HANDLING - HYD. LINE - VERSION 01 35.737.0201(03) - VAR - 461213 - OBJECT HANDLING - HYD. LINE 35.737.0201(04) - VAR - 461213 - OBJECT HANDLING - HYD. LINE - VERSION 02 35.737.0201(05) - VAR - 461213 - OBJECT HANDLING - HYD. LINE - VERSION 02 35.738.01(01) - VAR - 781490 - HYD LINES - DIPPER STICK (L=2,2MT) 35.738.01(02) - BUCKET CYLINDER - BREAKDOWN 35.738.01(03) - BUCKET CYLINDER - HYD LINES 35.738.0101(01) - VAR - 781176 - HYD LINES - DIPPER STICK (L=2,6MT) 35.738.0102(01) - VAR - 781179 - HYD LINES - DIPPER STICK (L=3,1MT) 35.738.02(01) - VAR - 461537 - ADDITIONAL PARTS W/O NIBBLER & BREAKER 35.741.01(01) - VAR - 461150, 461153, 461252, 461254 - BLADE CYLINDERS BREAKDOWN 35.741.02(01) - VAR - 461150, 461252 - BLADE REAR - CYLINDERS PIPING 35.910.01(01) - VAR - 781128 - QUICK COUPLER - HYD. LINES

1

2

3

4

5

6

Позиция на иллюстрации	Заводской номер детали		Название детали
1	2856513		COVER
2	4899039		SCREW
3	4899921		GASKET
4	4893036		PLUG
5	4895424		INLET MANIFOLD
6	4895294		SCREW

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
