Каталог запасных частей к технике: CASE IH TR270. HYDROSTATIC PUMP, DRIVE LINES, MECHANICAL CONTROLS

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
29
30
31
32
33
33
34
35
36
37
Позиция на иллюстрации Заводской номер детали Название детали
1 13021 HOSE CLAMP #08, 0.50"/0.91", Type F Worm, Stainless
2 15734 SCREW, Hex Soc Hd, 1/2"-13 x 1 3/4"
3 65319 WASHER, M13 x 25 x 3.5, HT
4 76344 ELBOW
5 300442 HEX SOC SCREW
6 L18331 CABLE TIE
7 L104616 TEE
8 87711337 COUPLING, Drive, Star
9 9706693 BOLT
10 87698844 BOLT, Flange, M12 X 20 Full
11 9804277 NUT
12 9804279 NUT
13 16044321 BOLT
14 87359470 HYD CONNECTOR
15 84257174 HOSE ASSY., Charge to Brake
16 84257175 HOSE ASSY., Brake
17 84259516 FLEXIBLE HOSE, Assembly, LV Interlock
18 87326965 ELBOW
19 84273629 FITTING, M10 X 1
20 84273645 HOSE, Pump Drain
21 87314487 HYD CONNECTOR, Bead, Hose, 1/2in
22 84305548 FLYWHEEL Cover
23 87021277 TUBE ASSY
24 87013729 O-RING
25 86625255 WASHER
26 84373389 RIGID TUBE, Assembly, EH, Aux Charge
27 84373394 HOSE, EH Aux to EH Aux Drain
28 86513653 TEE
29 86513020 CONNECTOR
30 86512936 ELBOW, 90є, 9/16"-18, 37є x 7/16"-20, O-Ring
31 84549542 CLAMP Hose, CTB, 22mm ID
32 84560744 MOUNT Pump Support
33 84560831 FLEXIBLE HOSE Loop
34 84560841 HOSE ASSY. Loop
35 84560843 HOSE ASSY. Loop
36 86011090 BOLT, Hex Flg, M10 x 70, 8.8
37 87655042 SPECIAL WASHER
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
