87438190
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Позиция на иллюстрации
Заводской номер детали
Название детали
86624451
86624451
BUSHING
86624450
86624450
BUSHING
87438190
87438190
CYLINDER ASSY
86631598
86631598
KIT
1
86611742
ROD
2
848220
PISTON
3
86631597
CYLINDER HEAD
4
86611740
CYLINDER
5
280724
NUT
6
87414
NIPPLE
7
214389
PLUG
8
86563839
SEAL
9
86631610
SEAL
10
86631607
SEAL
11
86631616
SEAL
12
86512008
WASHER
13
52419
O-RING
14
783874
RING
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
