Каталог запасных частей к технике: CASE IH 921F. SEAT ASSY, AIR SUSPENSION

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
24
25
26
27
28
29
30
31
32
33
35
36
36
37
37
38
38
39
40
41
42
43
43
44
45
46
47
48
49
50
51
52
54
Позиция на иллюстрации Заводской номер детали Название детали
87584096 87584096 SUSPENSION
82848105 82848105 KIT
82035078 82035078 BELLOWS
398148A1 398148A1 BASE
87396449 87396449 SUSPENSION
82035086 82035086 LEVER
87585037 87585037 SHOCK ABSORBER
82035082 82035082 STOP
82035079 82035079 SHOCK ABSORBER
82035073 82035073 HANDLE
71486982 71486982 LEVER & PIN ASSY
82035122 82035122 SUSPENSION
87398040 87398040 SEAT ASSY
82035111 82035111 KIT
82035123 82035123 HANDLE
1 82035095 CONTROL
2 NSS NOT SERVICED SEPARATELY
3 82035052 BUSHING
4 87585124 SPECIAL BOLT
5 NSS NOT SERVICED SEPARATELY
6 NSS NOT SERVICED SEPARATELY
7 82035087 SCREW
8 82035065 RIVET
9 85817486 COVER
10 82035081 PLUG
11 NSS NOT SERVICED SEPARATELY
12 NSS NOT SERVICED SEPARATELY
13 87584172 SPRING
14 NSS NOT SERVICED SEPARATELY
15 NSS NOT SERVICED SEPARATELY
16 NSS NOT SERVICED SEPARATELY
17 82035087 SCREW
18 NSS NOT SERVICED SEPARATELY
19 85817560 WASHER
20 NSS NOT SERVICED SEPARATELY
21 NSS NOT SERVICED SEPARATELY
22 82035065 RIVET
23 NSS NOT SERVICED SEPARATELY
24 85817496 WASHER
25 87567829 WASHER
26 82035116 BEARING
27 87584102 CABLE
28 NSS NOT SERVICED SEPARATELY
29 85817492 HANDLE
30 85819815 SCREW
31 82035106 CABLE
32 82035075 CABLE
33 NSS NOT SERVICED SEPARATELY
34 82035126 BUMPER
35 82035057 ROLLER
36 87567830 SEAT ACCESSORY
37 NSS NOT SERVICED SEPARATELY
38 NSS NOT SERVICED SEPARATELY
39 82035130 ROLLER
40 NSS NOT SERVICED SEPARATELY
41 NSS NOT SERVICED SEPARATELY
42 47335175 STOP
43 345125A1 AIR COMPRESSOR KIT
44 87396450 SPRING
45 NSS NOT SERVICED SEPARATELY
46 NSS NOT SERVICED SEPARATELY
47 NSS NOT SERVICED SEPARATELY
48 87584100 CABLE
49 82035077 HOSE KIT
50 87584103 CLAMP
51 NSS NOT SERVICED SEPARATELY
52 NSS NOT SERVICED SEPARATELY
53 87583859 CONSOLE
54 82035071 GUIDE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
