Каталог запасных частей к технике: CASE IH 845. HEATER ASSY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
3
4
5
6
7
8
9
9
9
9
10
11
11
11
11
11
11
11
12
12
12
13
13
14
15
15
16
17
18
19
20
21
22
22
23
24
25
26
27
28
29
30
31
32
33
34
35
Позиция на иллюстрации Заводской номер детали Название детали
1 84267543 HEATER
2 47635214 KIT Std Filter, Incl 2, 45
2 47635215 FILTER ASSY Charcoal Filter, Incl 2, 45
3 84380586 CASE, Filter
4 84380587 ELECTRIC MOTOR, Blower
5 84380588 GASKET, Blower
6 84380589 CABLE CLIP, Spring, Blower
7 84380590 RESISTOR
8 84380592 WIRE HARNESS, W/ Relay
9 84380593 CABLE CLIP, Harness
10 84380594 BRACKET, Relay
11 84380596 SCREW, 4 X 16
12 84380597 CASE, Cup, Condensate
13 84380598 LATCH HOOK, Filter, Closing
14 84380599 KNOB, Closing
15 5192101 BLOCK, Anti-vibration
16 84380601 SPACER, Washer, Silent, Block
17 84380602 GASKET, Left, Air Outlet
18 84380603 GASKET, Right, Air Outlet
19 84380604 GASKET, Air Inlet
20 84380608 GASKET, Hose Interface
21 84380609 PLATE, Plate, Water Condensate
22 84380611 CLIP, Spring, M6 for Ducts
23 84380612 GASKET, Harness
24 47456103 HEATER Incl 25 - 26
25 84380614 GASKET, Heater Core
26 84380615 GASKET, Heater, Lateral
27 84381032 BOX, Lower
28 84381034 BOX, Upper
29 84381035 BOX, Bottom
30 47638727 KIT Incl 7, 8, 9, 10, 11, 23
31 47635213 KIT Mount, Incl 16, 17,
32 47635216 KIT Knob, Incl 12, 14, 15, 41, 42
33 47635219 KIT Box, Incl 39 - 41
34 47635221 GASKET KIT Gasket, Incl 6, 18, 19, 21, 25, 27, 28, 32
35 47635222 KIT Bottom Box, Incl 3, 22
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
