Каталог запасных частей к технике: CARMIX-5.5XL. TRANSMISSION HYDRAULIC PLANT
1
2
3
4
4
5
6
7
8
9
10
11
12
13
13
14
14
15
16
17
18
18
19
20
21
22
22
23
24
25
26
27
28
29
30
31
32
32
33
34
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 037.0021.0000 | Tap | |
| 2 | 008.0257.0000 | Hose fitting | |
| 3 | 803.0X47.0130 | Hydraulic hose | |
| 4 | 008.0196.0000 | Hose fitting | |
| 5 | 027.0038.0000 | Filter | |
| 6 | 027.0011.0002 | Vacuum manometer | |
| 7 | 027.0006.0001 | Filter cartridge | |
| 8 | 803.0X24.0100 | Hydraulic hose | |
| 9 | 008.0258.0000 | Hose fitting | |
| 10 | 028.0077.0000 | Pump | |
| 11 | 028.0077.0001 | Electrovalve | |
| 12 | 028.0064.0002 | Electromagnet | |
| 13 | 007.0016.0000 | Half flange | |
| 14 | 006.0031.0000 | O-Ring | |
| 15 | 802.0966.0390 | Hydraulic hose | |
| 16 | 802.0966.0360 | Hydraulic hose | |
| 17 | 029.0068.0000 | Motor | |
| 18 | 008.0189.0000 | Hose fitting | |
| 19 | 024.0053.0000 | Valve | |
| 20 | 008.0051.0000 | Hose fitting | |
| 21 | 811.0544.0091 | Hydraulic hose | |
| 22 | 008.0167.0000 | Hose fitting | |
| 23 | 811.0527.0185 | Hydraulic hose | |
| 24 | 008.0094.0000 | Hose fitting | |
| 25 | 008.0205.0000 | Hose fitting | |
| 26 | 811.0447.0170 | Hydraulic hose | |
| 27 | 008.0302.0000 | Hose fitting | |
| 28 | 811.0145.0347 | Hydraulic hose | |
| 29 | 811.0145.0357 | Hydraulic hose | |
| 30 | 811.0447.0145 | Hydraulic hose | |
| 31 | 008.0178.0000 | Hose fitting | |
| 32 | 008.0052.0000 | Hose fitting | |
| 33 | 811.0422.0092 | Hydraulic hose | |
| 34 | 008.0243.0000 | Hose fitting | |
| 35 | 008.0200.0000 | Hose fitting |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
