Каталог запасных частей к технике: CARMIX-3.5TT. TRANSMISSION PLANT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 008.0181.0000 | Hose fitting | |
| 2 | 008.0053.0000 | Hose fitting | |
| 3 | 027.0011.0002 | Vacuum manometer | |
| 4 | 027.0006.0001 | Filter cartridge | |
| 5 | 027.0006.0000 | Filter | |
| 6 | 009.0016.0000 | Oil level indicator | |
| 7 | 803.0442.0083 | Hydraulic hose | |
| 8 | 008.0189.0000 | Hose fitting | |
| 9 | 028.0057.0000 | Pump | |
| 10 | 028.0064.0001 | Electrovalve | |
| 11 | 028.0064.0002 | Electromagnet | |
| 12 | 008.0101.0000 | Hose fitting | |
| 13 | 007.0003.0000 | Half flange | |
| 14 | 006.0029.0000 | O – Ring | |
| 15 | 802.0566.0310 | Hydraulic hose | |
| 16 | 802.0566.0360 | Hydraulic hose | |
| 17 | 007.0004.0000 | Half flange | |
| 18 | 006.0030.0000 | O – Ring | |
| 19 | 029.0074.0000 | Motor | |
| 20 | 008.0165.0000 | Hose fitting | |
| 21 | 008.0166.0000 | Hose fitting | |
| 22 | 008.0050.0000 | Hose fitting | |
| 23 | 811.0544.0350 | Hydraulic hose | |
| 24 | 008.0200.0000 | Hose fitting | |
| 25 | 008.0121.0000 | Hose fitting | |
| 26 | 008.0131.0000 | Hose fitting | |
| 27 | 811.0814.0180 | Hydraulic hose | |
| 28 | 008.0213.0000 | Hose fitting | |
| 29 | 008.0094.0000 | Hose fitting | |
| 30 | 024.0058.0000 | Valve | |
| 31 | 811.0524.0215 | Hydraulic hose | |
| 32 | 008.0205.0000 | Hose fitting | |
| 33 | 811.0427.0046 | Hydraulic hose | |
| 34 | 008.0055.0000 | Hose fitting | |
| 35 | 811.0147.0342 | Hydraulic hose | |
| 36 | 811.0147.0347 | Hydraulic hose | |
| 37 | 008.0315.0000 | Hose fitting | |
| 38 | 008.0130.0000 | Hose fitting | |
| 39 | 029.0074.0001 | Solenoid |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
