Каталог запасных частей к технике: BOMAG BW 24R. Dashboard
1
1
2
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
20
21
22
23
23
24
24
25
25
26
26
27
27
28
28
29
29
30
30
31
31
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 05762203 | Front element | |
| 2 | 05762202 | Incandescent bulb | |
| 3 | 05762201 | Lower part | |
| 4 | 05762214 | Front element | |
| 5 | 05762210 | Fastening flange | |
| 6 | 38052311 | Switch,normally open | |
| 7 | 05762213 | Front element | |
| 8 | 05762210 | Fastening flange | |
| 9 | 38052311 | Switch,normally open | |
| 10 | 06510177 | Cover | |
| 11 | 05762213 | Front element | |
| 12 | 05762210 | Fastening flange | |
| 13 | 38052311 | Switch,normally open | |
| 14 | 05750840 | Interval switch | |
| 15 | 05762213 | Front element | |
| 16 | 05762210 | Fastening flange | |
| 17 | 38052312 | Switch,normally closed | |
| 18 | 05762213 | Front element | |
| 19 | 05762210 | Fastening flange | |
| 20 | 38052311 | Switch,normally open | |
| 21 | 38052312 | Switch,normally closed | |
| 22 | 06510177 | Cover | |
| 23 | 05762214 | Front element | |
| 24 | 05762210 | Fastening flange | |
| 25 | 38052311 | Switch,normally open | |
| 26 | 05762211 | Front element | |
| 27 | 05762210 | Fastening flange | |
| 28 | 38052311 | Switch,normally open | |
| 29 | 05762206 | Front element | |
| 30 | 05762210 | Fastening flange | |
| 31 | 38052312 | Switch,normally closed |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
