Каталог запасных частей к технике: BOMAG BF 300 C S340 TV. Lubrication system

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
05970007
1
2
3
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
20
21
22
23
23
24
25
26
27
28
29
30
31
32
33
33
34
35
36
37
38
39
40
41
42
43
43
44
45
46
47
48
49
50
51
52
53
54
55
55
55
55
55
55
56
56
56
56
56
56
56
56
56
56
56
Позиция на иллюстрации Заводской номер детали Название детали
05970007 05970007 Lubrication system
1 05970019 Distributor combination
2 05970101 Distributor block
3 05970105 Distributor plate
4 05970109 Distributor piece
5 05970060 Angular fitting
6 05970062 Check valve
7 05970063 Check valve
8 07230565 Socket-head cap screw
9 07230641 Socket-head cap screw
10 08661064 Star lock washer
11 05970020 Distributor combination
12 05970101 Distributor block
13 05970105 Distributor plate
14 05970107 Distributor piece
15 05970060 Angular fitting
16 05970062 Check valve
17 05970116 Screw plug
18 07230565 Socket-head cap screw
19 07230641 Socket-head cap screw
20 08661064 Star lock washer
21 05970021 Distributor combination
22 05970101 Distributor block
23 05970104 Distributor plate
24 05970107 Distributor piece
25 05970060 Angular fitting
26 05970062 Check valve
27 05970116 Screw plug
28 07230565 Socket-head cap screw
29 07230641 Socket-head cap screw
30 08661064 Star lock washer
31 05970022 Distributor combination
32 05970101 Distributor block
33 05970104 Distributor plate
34 05970109 Distributor piece
35 05970060 Angular fitting
36 05970062 Check valve
37 05970116 Screw plug
38 07230565 Socket-head cap screw
39 07230641 Socket-head cap screw
40 08661064 Star lock washer
41 05970023 Distributor combination
42 05970101 Distributor block
43 05970104 Distributor plate
44 05970109 Distributor piece
45 05970060 Angular fitting
46 05970062 Check valve
47 05970116 Screw plug
48 07230565 Socket-head cap screw
49 07230641 Socket-head cap screw
50 08661064 Star lock washer
51 05970081 High pressure hose
52 05970117 Cutting ring
53 05970118 Cap nut
54 05970037 Grease gun
55 05970114 Kit,seal
56 05970115 Kit,seal
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
