Каталог запасных частей к технике: Ammann AV 70X. Yoke
1
2
3
4
4
6
7
8
9
10
11
12
12
12
12
15
15
16
16
17
17
18
19
19
19
19
22
28
28
30
30
30
30
35
35
36
36
36
36
37
37
37
39
40
40
40
40
50
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-10228A | 4-10228A | Yoke | |
| 1 | 4-10279A | Yoke | |
| 2 | 4-10227A | Yoke | |
| 3 | 4-09696A | Transverse beam | |
| 4 | 4-10245A | Plate | |
| 6 | 4-10364A | Cover | |
| 7 | 4-08966A | Spacer washer | |
| 8 | 4-08967A | Spacer washer | |
| 9 | 4-5353080052 | Venting valve | |
| 10 | 4-5531020063 | Connector | |
| 11 | 4-10741A | Hose | |
| 12 | 4-9200000031 | Rubber mount | |
| 15 | 4-3002520050 | Hexagon head screw | |
| 16 | 4-3002516050 | Hexagon head screw | |
| 17 | 4-3002516045 | Hexagon head screw | |
| 18 | 4-3002516040 | Hexagon head screw | |
| 19 | 4-3002512030 | Hexagon head screw | |
| 22 | 4-3002508012 | Hexagon head screw | |
| 28 | 4-3048500160 | Hexagon nut | |
| 30 | 4-3530020120 | Nut | |
| 35 | 4-3900017200 | Spring washer | |
| 36 | 4-3170600170 | ШАЙБА | |
| 37 | 4-3900017160 | Spring washer | |
| 39 | 4-3170600080 | Washer | |
| 40 | 4-3170600130 | Washer | |
| 50 | 4-5358570073 | Plug |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
