Каталог запасных частей к технике: Ammann AV 70X. Spraying
1
2
7
7
7
7
8
8
9
9
10
10
11
11
13
13
13
13
13
13
13
14
14
14
15
15
16
16
17
17
21
21
22
23
24
25
26
27
28
29
30
31
31
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
36
36
36
36
36
36
39
39
40
40
40
41
41
42
42
46
46
46
46
46
46
46
47
47
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-07960A | 4-07960A | Showering | |
| 1 | 4-07961A | Plate | |
| 2 | 4-07962A | Cover | |
| 7 | 4-5325110014 | Reduction | |
| 8 | 4-5325110009 | Reduction | |
| 9 | 4-9500600010 | ВОДЯНОЙ НАСОС | |
| 10 | 4-5358520088 | Water filter | |
| 11 | 4-5326020006 | Valve | |
| 13 | 4-5531020052 | Connector | |
| 14 | 4-5531020054 | Connector | |
| 15 | 4-5325110015 | Manifold | |
| 16 | 4-5531020100 | Connector | |
| 17 | 4-5531020101 | Cap | |
| 21 | 4-07963A | Hose | |
| 22 | 4-07964A | Hose | |
| 23 | 4-07965A | Hose | |
| 24 | 4-07966A | Hose | |
| 25 | 4-07967A | Hose | |
| 26 | 4-07968A | Hose | |
| 27 | 4-07969A | Hose | |
| 28 | 4-07970A | Hose | |
| 29 | 4-07971A | Hose | |
| 30 | 4-07972A | Hose | |
| 31 | 4-08241A | Hose | |
| 35 | 4-5531020002 | Hose clamp | |
| 36 | 4-5531020073 | Hose clamp | |
| 39 | 4-3001508075 | Hexagon head screw | |
| 40 | 4-3002508014 | Hexagon head screw | |
| 41 | 4-3002508012 | Hexagon head screw | |
| 42 | 4-3113105025 | БОЛТ | |
| 46 | 4-3170600080 | Washer | |
| 47 | 4-3170200053 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
