Каталог запасных частей к технике: Ammann AV 70X. Cube
1
2
4
5
6
7
12
12
12
12
14
14
16
18
18
19
22
22
23
24
27
30
30
31
35
37
40
41
44
45
50
55
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-11184A | 4-11184A | Cube | |
| 1 | 4-08452A | Cube | |
| 2 | 4-440860 | Plug | |
| 4 | 4-5358010206 | Temperature controller | |
| 5 | 4-5451060055 | Nonreturn valve | |
| 6 | 4-5451060031 | Nonreturn valve | |
| 7 | 4-5503580053 | Temperature switch | |
| 12 | 4-5160650059 | Screwed connection | |
| 14 | 4-5160650038 | Screwed connection | |
| 16 | 4-5160650098 | Connector | |
| 18 | 4-5160650066 | Screwed connection | |
| 19 | 4-5160571786 | Connector | |
| 22 | 4-5160670028 | Screwed connection | |
| 23 | 4-5160670029 | Screwed connection | |
| 24 | 4-5160660027 | Adjustable male stud run | |
| 27 | 4-5160660087 | Swivel union | |
| 30 | 4-5160670065 | L-connection | |
| 31 | 4-5160670056 | T-socket | |
| 35 | 4-5160670094 | Reduction | |
| 37 | 4-5160670034 | Plug | |
| 40 | 4-6160142202 | O-ring | |
| 41 | 4-6160142205 | O-ring | |
| 44 | 4-5535010231 | Circlip | |
| 45 | 4-6090010412 | Sealing ring | |
| 50 | 4-3114308120 | Socket head cap screw | |
| 55 | 4-3900017080 | Spring washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
