Каталог запасных частей к технике: Ammann AV110X. Switch cabinet
1
2
3
6
7
10
11
12
13
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
30
31
33
36
37
37
38
39
40
41
41
41
42
43
45
46
46
47
48
48
49
49
49
50
53
53
54
55
55
56
56
57
59
60
62
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-210839 | 4-210839 | Contact | |
| 1 | 4-10052А | Housing | |
| 2 | 4-04647А | Cover | |
| 3 | 4-04670А | Panel | |
| 6 | 4-441140 | Holder | |
| 7 | 4-04130A | Plate | |
| 10 | 4-9540000147 | Steering | |
| 11 | 4-5358010411 | Socket | |
| 12 | 4-5432020002 | Socket | |
| 13 | 4-5358170081 | Relay support | |
| 14 | 4-5358170079 | Relay | |
| 15 | 4-5358170078 | Circuit breaker | |
| 16 | 4-5432010008 | Diode | |
| 17 | 4-5422080029 | Relay | |
| 18 | 4-9200010006 | Fusebox | |
| 19 | 4-9200010005 | Bridge | |
| 20 | 4-9200010004 | Bunch plug | |
| 21 | 4-9200010003 | Bunch plug | |
| 22 | 4-9200010002 | Bunch plug | |
| 23 | 4-9200010001 | Bunch plug | |
| 24 | 4-5422060014 | Fuse | |
| 25 | 4-5422060012 | Fuse | |
| 26 | 4-5422060016 | Fuse | |
| 27 | 4-5422060013 | Fuse | |
| 28 | 4-5422060017 | Fuse | |
| 30 | 4-5358170101 | Bushing | |
| 31 | 4-5358170099 | Fuse | |
| 33 | 4-6120070106 | Adhesive tape | |
| 36 | 4-3113102008 | Socket head cap screw | |
| 37 | 4-3113103012 | Socket head cap screw | |
| 38 | 4-3113104012 | Socket head cap screw | |
| 39 | 4-3113105010 | Socket head cap screw | |
| 40 | 4-3113105012 | Socket head cap screw | |
| 41 | 4-3798506008 | Oval head screw | |
| 42 | 4-3002506014 | Hexagon head screw | |
| 43 | 4-3002506030 | Hexagon head screw | |
| 45 | 4-3140100020 | Hexagon nut | |
| 46 | 4-3149200030 | Nut | |
| 47 | 4-3149200040 | Nut | |
| 48 | 4-3149200050 | Nut | |
| 49 | 4-3048500060 | Hexagon nut | |
| 50 | 4-3048500080 | Hexagon nut | |
| 53 | 4-3170200032 | ШАЙБА | |
| 54 | 4-3170200043 | ШАЙБА | |
| 55 | 4-3170200053 | Washer | |
| 56 | 4-3170200064 | ШАЙБА | |
| 57 | 4-3170200084 | ШАЙБА | |
| 59 | 4-3174000061 | Lock washer | |
| 60 | 4-3174000082 | Lock washer | |
| 62 | 4-3174500022 | Serrated lock washer | |
| 66 | 4-6150051018 | Staple strip | |
| 67 | 4-6150051016 | Staple strip |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
