Каталог запасных частей к технике: Ammann AV110X. Lifting hydraulics
2
2
5
6
7
10
13
14
15
16
17
17
20
20
20
22
24
26
29
32
35
35
39
40
41
42
45
45
46
49
49
49
50
50
50
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-210792 | 4-210792 | Lifting hydraulics | |
| 2 | 4-440553 | Diaphragm | |
| 5 | 4-5451050060 | Block | |
| 6 | 1199578 | Hand pump | |
| 7 | 4-5160650159 | Ball cock | |
| 10 | 4-5160680037 | Screwed connection | |
| 13 | 4-5160650126 | Screwed connection | |
| 14 | 4-5160650127 | Connector | |
| 15 | 4-5160650078 | Connector | |
| 16 | 4-5160650059 | Screwed connection | |
| 17 | 4-5160650112 | Connector | |
| 20 | 4-5160670076 | Adjustable male stud run | |
| 22 | 4-5160660078 | L-connection | |
| 24 | 4-5160660091 | T-socket | |
| 26 | 4-5160660119 | Clutch | |
| 29 | 4-5160571752 | Reduction | |
| 32 | 4-6090010411 | Sealing ring | |
| 35 | 4-5325030033 | Clamping device | |
| 39 | 4-5160571702 | Hydraulic hose | |
| 40 | 4-5160571858 | Hydraulic hose | |
| 41 | 4-5160571204 | Hydraulic hose | |
| 42 | 4-5160571707 | Hydraulic hose | |
| 45 | 4-3002506014 | Hexagon head screw | |
| 46 | 4-3001506070 | Hexagon head screw | |
| 49 | 4-3174000061 | Lock washer | |
| 50 | 4-3170200064 | ШАЙБА |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
