Каталог запасных частей к технике: Ammann AV110X. Electrical installation
1
2
4
5
6
7
8
8
9
14
15
16
19
20
21
22
26
26
26
27
27
28
28
29
29
29
30
30
30
30
31
31
32
32
33
33
33
35
36
37
38
39
40
41
43
44
45
47
47
48
48
49
49
51
53
53
54
54
55
55
56
57
57
58
58
59
60
61
62
63
67
68
69
71
71
71
71
71
71
71
71
72
72
73
73
74
74
77
77
77
77
78
78
79
79
80
80
81
81
81
81
81
81
82
82
83
83
84
84
86
86
86
86
86
86
87
88
91
92
93
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-107209 | 4-107209 | Electrical installation | |
| 1 | 4-S211694 | Instrument panel | |
| 2 | 4-S210839 | Switch cabinet | |
| 4 | 4-211348 | Cable harness | |
| 5 | 4-211342 | Cable harness | |
| 6 | 4-211233 | Cable harness | |
| 7 | 4-211349 | Cable harness | |
| 8 | 4-211350 | Cable harness | |
| 9 | 4-211351 | Cable harness | |
| 14 | 4-441140 | Holder | |
| 15 | 4-04152А | Pipe | |
| 16 | 4-09940А | Holder | |
| 19 | 4-5435060058 | Battery | |
| 20 | 4-5435060046 | Clamp | |
| 21 | 4-5435060047 | Clamp | |
| 22 | 4-5435060055 | Cover | |
| 26 | 4-5358170062 | Spotlight | |
| 27 | 4-5358170108 | Lamp | |
| 28 | 4-5358170109 | Lamp | |
| 29 | 4-5433050025 | Incandescent lamp | |
| 30 | 4-5433060014 | Incandescent lamp | |
| 31 | 4-5433050012 | Incandescent lamp | |
| 32 | 4-5433050013 | Incandescent lamp | |
| 33 | 4-5358220010 | Terminal block | |
| 35 | 4-5358170063 | Signal horn | |
| 36 | 4-3140385203 | Interference filler | |
| 37 | 4-5422120023 | Sensor | |
| 38 | 4-5358170091 | Isolator | |
| 39 | 4-5358010401 | Ignition lock | |
| 40 | 4-53580:0402 | Flap | |
| 41 | 4-5358010399 | Fusebox | |
| 43 | 4-5413070111 | ГОЛОВКА | |
| 44 | 4-5413070113 | Clutch | |
| 45 | 4-5413070121 | Auxiliary switch block | |
| 47 | 4-5358020006 | Potentiometer | |
| 48 | 4-5480030026 | Knob | |
| 49 | 4-3140375100 | Nut | |
| 51 | 4-5432010008 | Diode | |
| 53 | 4-5358200097 | Switch | |
| 54 | 4-5358210081 | Plate | |
| 55 | 4-5358200091 | T-piece | |
| 56 | 4-5358220040 | Cover | |
| 57 | 4-6531012703 | Symbol | |
| 58 | 4-6531013317 | Symbol | |
| 59 | 4-6531013183 | Symbol | |
| 60 | 4-6531013184 | Symbol | |
| 61 | 4-6531013187 | Symbol | |
| 62 | 4-6531013188 | Symbol | |
| 63 | 4-6531012582 | Symbol | |
| 67 | 4-3002505012 | Hexagon head screw | |
| 68 | 4-3002506012 | Hexagon head screw | |
| 69 | 4-3002508016 | Hexagon head screw | |
| 71 | 4-3113104035 | Socket head cap screw | |
| 71 | 4-3113104035 | Socket head cap screw | |
| 72 | 4-3113105012 | Socket head cap screw | |
| 72 | 4-3113105012 | Socket head cap screw | |
| 73 | 4-3113104012 | Socket head cap screw | |
| 73 | 4-3113104012 | Socket head cap screw | |
| 74 | 4-3113105055 | Socket head cap screw | |
| 74 | 4-3113105055 | Socket head cap screw | |
| 77 | 4-3048500050 | Hexagon nut | |
| 77 | 4-3048500050 | Hexagon nut | |
| 78 | 4-3048500100 | Hexagon nut | |
| 78 | 4-3048500100 | Hexagon nut | |
| 79 | 4-3149200040 | Nut | |
| 79 | 4-3149200040 | Nut | |
| 80 | 4-3170200043 | ШАЙБА | |
| 80 | 4-3170200043 | ШАЙБА | |
| 81 | 4-3170200053 | Washer | |
| 81 | 4-3170200053 | Washer | |
| 82 | 4-3170200064 | ШАЙБА | |
| 82 | 4-3170200064 | ШАЙБА | |
| 83 | 4-3170200084 | ШАЙБА | |
| 83 | 4-3170200084 | ШАЙБА | |
| 84 | 4-3170200105 | Washer | |
| 84 | 4-3170200105 | Washer | |
| 86 | 4-3174000051 | Lock washer | |
| 86 | 4-3174000051 | Lock washer | |
| 87 | 4-3174000082 | Lock washer | |
| 88 | 4-3174000102 | Lock washer | |
| 91 | 4-6150051018 | Staple strip | |
| 92 | 4-6150051016 | Staple strip | |
| 93 | 4-6150051017 | Staple strip |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
