Каталог запасных частей к технике: Ammann AV110X. Cooling system
1
2
3
7
8
9
10
11
12
13
14
14
15
16
17
18
18
19
20
21
22
23
23
23
23
24
24
25
25
26
26
26
27
27
31
31
31
32
33
33
34
35
35
36
37
37
38
38
39
39
40
41
42
43
44
44
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-02346А | 4-02346А | Cooling system | |
| 1 | 4-03187А | Collar | |
| 2 | 4-09099А | Grate | |
| 3 | 4-04677А | Clutch | |
| 7 | 4-04758А | Plug | |
| 8 | 4-06533А | Nozzle | |
| 9 | 4-08801А | Spacer | |
| 10 | 4-5358140066 | Radiator | |
| 11 | 4-5358140066А | Fan | |
| 12 | 4-9540000145 | Fluid motor | |
| 13 | 4-9540000144 | Temperature controller | |
| 14 | 4-6160070610 | Rubber mount | |
| 15 | 4-9200000087 | Manifold | |
| 16 | 4-9200000089 | Hose | |
| 17 | 4-9200000088 | Hose | |
| 18 | 4-6160090106 | Hose | |
| 19 | 4-6160090059 | Hose | |
| 20 | 4-6160090027 | Hose | |
| 21 | 4-5413680009 | Sensor | |
| 22 | 4-5531020067 | Connector | |
| 23 | 4-5531020070 | Hose clamp | |
| 24 | 4-5531020075 | Hose clamp | |
| 25 | 4-5531020073 | Hose clamp | |
| 26 | 4-5531020003 | Hose clamp | |
| 27 | 4-5531020004 | Hose clamp | |
| 31 | 4-3002506012 | Hexagon head screw | |
| 32 | 4-3114308030 | Socket head cap screw | |
| 33 | 4-3002510020 | Hexagon head screw | |
| 34 | 4-3048500080 | Hexagon nut | |
| 35 | 4-3048500100 | Hexagon nut | |
| 36 | 4-3172900066 | Washer | |
| 37 | 4-3174000082 | Lock washer | |
| 38 | 4-3174000102 | Lock washer | |
| 39 | 4-3170200105 | Washer | |
| 40 | 4-6120070105 | Gasket | |
| 41 | 1225144 | Plug | |
| 42 | 4-3001508050 | Hexagon head screw | |
| 43 | 4-3172900090 | Washer | |
| 44 | 4-3900017060 | Spring washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
