Каталог запасных частей к технике: Ammann AV110X. Cab part B
1
8
9
10
11
13
14
15
16
35
39
45
45
46
47
47
50
50
50
50
50
50
51
51
52
53
53
54
54
55
55
57
58
59
60
61
62
63
64
65
66
67
68
69
69
69
69
92
93
99
100
100
106
106
107
107
111
111
117
117
117
117
119
119
131
131
134
134
138
143
143
143
144
144
145
156
156
159
160
160
160
161
161
163
163
163
163
171
171
172
172
175
176
178
191
191
191
195
195
196
196
197
197
199
199
199
199
199
199
199
199
200
200
200
200
200
200
201
201
202
203
204
204
204
204
220
220
220
220
221
221
223
223
223
224
224
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-14637 | 4-14637 | Cabin | |
| 1 | 4-14680 | Cabin | |
| 8 | 4-06083А | Limit stop | |
| 9 | 4-06084А | Limit stop | |
| 10 | 4-436864 | РЫЧАГ | |
| 11 | 4-436865 | РЫЧАГ | |
| 13 | 4-437393 | КРЕПЛЕНИЕ | |
| 14 | 4-437394 | КРЕПЛЕНИЕ | |
| 15 | 4-05936А | Holder | |
| 16 | 4-06091А | Holder | |
| 35 | 4-05821А | Cover | |
| 39 | 4-06036А | Cover | |
| 45 | 4-437397 | ШАЙБА | |
| 46 | 4-06853А | Washer | |
| 47 | 4-06155А | Washer | |
| 50 | 4-05935А | Washer | |
| 51 | 4-05942А | Washer | |
| 52 | 4-06154А | Washer | |
| 53 | 4-05934А | Washer | |
| 54 | 4-04894А | Threshold | |
| 55 | 4-4100030143 | Spring | |
| 57 | 4-6610010911 | Pane of glass | |
| 58 | 4-6610010912 | Pane of glass | |
| 59 | 4-6610010917 | Pane of glass | |
| 60 | 4-6610010915 | Pane of glass | |
| 61 | 4-6610010918 | Pane of glass | |
| 62 | 4-6610010916 | Pane of glass | |
| 63 | 4-6610010899 | Pane of glass | |
| 64 | 4-6610010914 | Pane of glass | |
| 65 | 4-6610010913 | Pane of glass | |
| 66 | 4-6610010919 | Pane of glass | |
| 67 | 4-6610010920 | Pane of glass | |
| 68 | 4-6610010910 | Rear windscreen | |
| 69 | 4-06087А | Screw | |
| 92 | 4-5358030042 | Plug | |
| 93 | 4-6531010017 | Foil | |
| 99 | 4-6150020021 | Rubber profile | |
| 100 | 4-6150030010 | Handle | |
| 106 | 4-5358570045 | Armrest | |
| 107 | 4-5358190064 | Windshield washer | |
| 111 | 4-5358020383 | Gas pressure spring | |
| 117 | 4-5358570059 | Leadthrough | |
| 119 | 4-6160070617 | Rubber mount | |
| 131 | 4-5358190025 | Scraper | |
| 134 | 4-5358010500 | Profile | |
| 138 | 4-5358570046 | Plug | |
| 143 | 4-6150090092 | КОЖУХ | |
| 144 | 4-6150090076 | Cover | |
| 145 | 4-6150090097 | Cover | |
| 156 | 4-3115105010 | Countersunk screw | |
| 159 | 4-3002506012 | Hexagon head screw | |
| 160 | 4-3002506016 | Hexagon head screw | |
| 161 | 4-3113106016 | Socket head cap screw | |
| 163 | 4-3002506020 | Hexagon head screw | |
| 171 | 4-3115108025 | Countersunk screw | |
| 172 | 1196388 | Oval head countersunk screw | |
| 175 | 4-3002516025 | Hexagon head screw | |
| 176 | 4-3002516050 | Hexagon head screw | |
| 178 | 4-3136900160 | БОЛТ ПОДВЕСНОЙ | |
| 191 | 4-3170200053 | Washer | |
| 195 | 4-3170200105 | Washer | |
| 196 | 4-3170200064 | ШАЙБА | |
| 197 | 4-3170200084 | ШАЙБА | |
| 199 | 4-3900017060 | Spring washer | |
| 200 | 4-3172900066 | Washer | |
| 201 | 4-3900017080 | Spring washer | |
| 202 | 4-3900017160 | Spring washer | |
| 203 | 4-3172700180 | ШАЙБА | |
| 204 | 4-6150090075 | Outer washer | |
| 220 | 4-3149200050 | Nut | |
| 221 | 4-3149200060 | ГАЙКА | |
| 223 | 4-3149200080 | ГАЙКА | |
| 224 | 4-3048500080 | Hexagon nut |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
