Каталог запасных частей к технике: Ammann ASC 170. Cab wiring
1
2
5
6
7
8
9
10
10.01
14
15
18
18
19
19
20
20
21
22
23
24
28
29
32
33
34
37
38
40
40
42
43
45
47
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-324455 | 4-324455 | Electrical installation | |
| 1 | 4-S318389 | Windscreen wiper rear | |
| 2 | 4-211443 | Cable harness | |
| 5 | 4-5358190009 | Windscreen wiper motor | |
| 6 | 4-5358190028 | Drive | |
| 7 | 4-5358190056 | Segment | |
| 8 | 4-5358190057 | Washer | |
| 9 | 4-5535010606 | Circlip | |
| 10 | 4-5358190053 | Scraper | |
| 10.01 | 4-8300880039 | Scraper | |
| 14 | 4-5358170038 | Lamp | |
| 15 | 4-5358170039 | Incandescent lamp | |
| 18 | 4-5358200091 | T-piece | |
| 19 | 4-5358200092 | Intermediate piece | |
| 20 | 4-5358220045 | Switch | |
| 21 | 4-5358220081 | Switch | |
| 22 | 4-5358210016 | Plate | |
| 23 | 4-5358220046 | Plate | |
| 24 | 4-5358220055 | Plate | |
| 28 | 4-6160100180 | Leadthrough | |
| 29 | 4-6160100159 | Leadthrough | |
| 32 | 4-3123204010 | Plate screw | |
| 33 | 4-3110304012 | Hexagon head screw | |
| 34 | 4-3002505012 | Hexagon head screw | |
| 37 | 4-3140100040 | Hexagon nut | |
| 38 | 4-3048500050 | Hexagon nut | |
| 40 | 4-3048500080 | Hexagon nut | |
| 42 | 4-3174000041 | Lock washer | |
| 43 | 4-3174000051 | Lock washer | |
| 45 | 4-3174000082 | Lock washer | |
| 47 | 4-3170200043 | ШАЙБА |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
