Каталог запасных частей к технике: Ammann ASC 170. Cab part A
9
10
11
12
13
14
15
16
17
19
20
20
22
22
22
27
34
34
35
35
37
37
38
40
45
66
69
75
79
82
82
90
93
94
94
96
96
98
98
98
98
99
99
101
107
111
111
111
111
118
118
120
120
123
123
123
123
123
135
135.01
136
136.01
137
138
139
140
141
141
142
142
143
143
144
144
146
147
148
154
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-003364 | 4-003364 | Cabin | |
| 9 | 4-209539 | Cover | |
| 10 | 4-209540 | Cover | |
| 11 | 4-6610010834 | Pane of glass | |
| 12 | 4-6610010835 | Pane of glass | |
| 13 | 4-6610010885 | Pane of glass | |
| 14 | 4-6610010839 | Pane of glass | |
| 15 | 4-6610010837 | Pane of glass | |
| 16 | 4-6610010886 | Pane of glass | |
| 17 | 4-322065 | Cover | |
| 19 | 4-322818 | Cover | |
| 20 | 4-435471 | Bolt | |
| 22 | 4-322146 | Pull rod | |
| 27 | 4-3172900115 | Washer | |
| 34 | 4-440693 | Nut | |
| 35 | 4-440661 | Washer | |
| 37 | 4-6580050008 | Band | |
| 38 | 4-434969 | Gasket | |
| 40 | 4-610245 | Gasket | |
| 45 | 4-322445 | Plate | |
| 66 | 4-5358570037 | Plug | |
| 69 | 4-6150020020 | Rubber profile | |
| 75 | 4-5351010179 | Roller blind | |
| 79 | 4-5531020051 | Clutch | |
| 82 | 4-9200000003 | Ventilation nozzle | |
| 90 | 4-5535010952 | Nut | |
| 93 | 4-3001510065 | Hexagon head screw | |
| 94 | 4-3002510020 | Hexagon head screw | |
| 96 | 4-3002506012 | Hexagon head screw | |
| 98 | 4-3002506016 | Hexagon head screw | |
| 99 | 4-3002506020 | Hexagon head screw | |
| 101 | 4-3113106016 | Socket head cap screw | |
| 107 | 4-3115105010 | Countersunk screw | |
| 111 | 4-3123204012 | Plate screw | |
| 118 | 4-3170200105 | Washer | |
| 120 | 4-3170200064 | ШАЙБА | |
| 123 | 4-3174000061 | Lock washer | |
| 135 | 4-9500001004 | Crank | |
| 135.01 | 4-9500001014 | Key | |
| 136 | 4-9500001005 | Crank | |
| 136.01 | 4-9500001014 | Key | |
| 137 | 4-9500001006 | Lever | |
| 138 | 4-9500001007 | Lever | |
| 139 | 4-9500001008 | Door lock | |
| 140 | 4-9500001009 | Door lock | |
| 141 | 4-9500001010 | Washer | |
| 142 | 4-9500001011 | Washer | |
| 143 | 4-9500001012 | Bolt | |
| 144 | 4-9500001013 | Cover | |
| 146 | 4-6610010896 | Side window glass | |
| 147 | 4-6610010897 | Side window glass | |
| 148 | 4-6150030011 | Handle | |
| 154 | 4-6531012884 | Symbol |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
