Каталог запасных частей к технике: Ammann ARS122. Platform Railing Assembly
1
2
3
4
5
6
7
8
8
9
10
11
11
12
13
14
15
16
16
16
16
17
18
19
20
20.01
21
21
22
23
23
23
24
25
26
27
28
28
28
28
29
30
30
30
30
31
31
31
31
32
33
33
33
34
34
35
36
36
36
37
38
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1472853 | 1472853 | Platform Railing Assembly | |
| 1 | 1472854 | Platform | |
| 2 | 1472194 | Front cover | |
| 3 | 1472188 | Operator panel | |
| 4 | 4-441374 | ТРУБКА В СБОРЕ | |
| 5 | 1472223 | Bracket | |
| 6 | 1472275 | Bracket | |
| 7 | 1472195 | Cover | |
| 8 | 1456827 | Knob | |
| 9 | 4-435283 | ЦЕПЬ | |
| 10 | 4-441543 | Spring | |
| 11 | 1472843 | Rubber profile | |
| 12 | 1472844 | Insulating hose | |
| 13 | 1472191 | Mirror Arm | |
| 14 | 1456820 | Padlock | |
| 15 | 1451487 | Driver's seat | |
| 16 | 4-3002508025 | Hexagon head screw | |
| 17 | 1472859 | Door | |
| 18 | 1456935 | Hinge | |
| 19 | 1472225 | Hinge lock | |
| 20 | 4-9500001015 | Tongue lock | |
| 20.01 | 1502430 | Door Lock Key | |
| 21 | 4-3799106022 | Countersunk screw | |
| 22 | 4-3679600060 | Strain washer | |
| 23 | J902123 | Hexagon nut | |
| 24 | 4-3002508016 | Hexagon head screw | |
| 25 | 4-3002506025 | Hexagon head screw | |
| 26 | 4-3002505010 | Hexagon head screw | |
| 27 | 1472089 | Bottle holder | |
| 28 | 4-3048500080 | Hexagon nut | |
| 29 | 4-3002506020 | Hexagon head screw | |
| 30 | 4-3900017080 | Spring washer | |
| 31 | 4-3170200064 | ШАЙБА | |
| 32 | 4-3170200053 | Washer | |
| 33 | 4-3679600080 | Strain washer | |
| 34 | 1471872 | Clamp | |
| 35 | 4-3002510030 | Hexagon head screw | |
| 36 | 4-3170200105 | Washer | |
| 37 | 4-3048500100 | Hexagon nut | |
| 38 | 1451564 | Rear View Mirror |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
