Каталог запасных частей к технике: Ammann ARS122. Driving Hydraulic
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
3
4
5
6
6
6
6
7
8
9
9
10
11
12
13
14
14
15
16
17
17
17
18
19
20
21
22
23
24
24
24
24
24
25
25
25
26
27
28
29
29
30
31
32
33
34
35
36
37
38
38
39
39
40
41
41.01
42
43
44
45
46
47
48
49
50
50
50
50
50
50
50
50
50
50
50
51
52
53
54
55
56
56
57
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1472014 | 1472014 | Driving hydraulic | |
| 1 | 4-5160580016 | Yoke | |
| 2 | 4-5160650120 | Connector | |
| 3 | 4-5160571662 | Hydraulic hose | |
| 4 | 4-5160571659 | Hydraulic hose | |
| 5 | 4-5160571658 | Hydraulic hose | |
| 6 | 4-5160650134 | Connector | |
| 7 | 4-5160571657 | Hydraulic hose | |
| 8 | 4-5160571656 | Hydraulic hose | |
| 9 | 4-5160571660 | Hydraulic hose | |
| 10 | 1-901064 | Screwed socket | |
| 11 | 4-5160571654 | Hydraulic hose | |
| 12 | 4-5160571337 | Hydraulic body | |
| 13 | 4-5160570203 | Hydraulic hose | |
| 14 | 4-5160571630 | Connector | |
| 15 | 4-5160650029 | Connector | |
| 16 | 4-5160571652 | Hydraulic hose | |
| 17 | 4-5160650058 | Screwed connection | |
| 18 | 4-5160571653 | Hydraulic hose | |
| 19 | 4-5160572449 | Connector | |
| 20 | 1482425 | Hose | |
| 21 | 1-901433 | Muff | |
| 22 | 1474326 | Hose | |
| 23 | 1474325 | Hose | |
| 24 | 4-5160650086 | Connector | |
| 25 | 1482422 | Hydraulic Hose | |
| 26 | H0088612 | T-Socket | |
| 27 | 1482424 | Hydraulic Hose | |
| 28 | 1474322 | Hydraulic Hose | |
| 29 | 1455395 | Ferrule | |
| 30 | 4-5160571648 | Hydraulic hose | |
| 31 | 4-5160570615 | Hydraulic hose | |
| 32 | 4-5160571655 | Hydraulic hose | |
| 33 | 4-5160650078 | Connector | |
| 34 | 4-442833 | Diaphragm | |
| 35 | 1474321 | Hydraulic Hose | |
| 36 | 4-323956 | Cube | |
| 37 | 4-323957 | Cube | |
| 38 | 4-6160142202 | O-ring | |
| 39 | 4-5160670114 | Plug | |
| 40 | 4-5160670040 | Plug | |
| 41 | 1479206 | Hyd. Brake Block | |
| 41.01 | 1176590 | Pressure switch | |
| 42 | 4-5451050101 | Block | |
| 43 | 4-6160142203 | O-ring | |
| 44 | 4-442829 | Washer | |
| 45 | 4-3114312160 | Socket head cap screw | |
| 46 | 4-3900017120 | Spring washer | |
| 47 | 4-3048500120 | Hexagon nut | |
| 48 | 4-3114310060 | Socket head cap screw | |
| 49 | 4-3900017100 | Spring washer | |
| 50 | 4-3114310035 | Socket head cap screw | |
| 51 | 4-6150051017 | Staple strip | |
| 52 | 1474333 | Spiral Guard Hose | |
| 53 | 1474334 | Spiral Guard Hose | |
| 54 | 1474327 | Spiral Guard Hose Protector | |
| 55 | 1455539 | Nipple | |
| 56 | 4-3114310100 | Cylinder head screw | |
| 57 | 4-5160650045 | Connector |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
