Каталог запасных частей к технике: Ammann ARP 35. Hydraulic oil tank
1
2
6
7
8
9
10
15
16
17
18
18
21
22
25
28
32
34
37
40
41
46
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-12942 | 4-12942 | Hydraulic oil tank | |
| 1 | 4-12941 | Hydraulic oil tank | |
| 2 | 4-12940 | Container lid | |
| 6 | 4-5358500002 | Filler neck | |
| 7 | 4-5451050018 | Strainer | |
| 8 | 1176929 | Level sensor | |
| 9 | 4-5536860012 | Inspection glass | |
| 10 | 4-5160670073 | Sealing plug | |
| 15 | 4-5160650111 | Screwed connection | |
| 16 | 4-5160650059 | Screwed connection | |
| 17 | 4-5160650036 | Screwed connection | |
| 18 | 4-5160650066 | Screwed connection | |
| 21 | 4-5160660078 | L-connection | |
| 22 | 4-5160670065 | L-connection | |
| 25 | 4-3029506016 | Stud bolt | |
| 28 | 4-3002510025 | Hexagon head screw | |
| 32 | 4-3048500060 | Hexagon nut | |
| 34 | 4-3048500100 | Hexagon nut | |
| 37 | 4-3900017060 | Spring washer | |
| 40 | 4-3900017100 | Spring washer | |
| 41 | 4-3170200105 | Washer | |
| 46 | 4-5422250006 | Sealing tape |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
