Каталог запасных частей к технике: Ammann ARP 35. Frame accessories
1259761
1259761
1259761
1259761
1
1
1
2
4
5
5
6
6
7
7
8
8
8
8
10
10
11
11
12
13
13
13
13
16
17
17
18
19
19
20
20
21
21
21
21
22
22
23
25
25
26
26
26
26
27
27
28
28
29
29
30
30
30
30
31
31
33
33
34
34
35
35
35
35
36
36
38
38
39
39
39
39
39
39
39
39
40
40
40
45
45
46
46
47
47
53
54
54
55
55
57
57
58
58
58
58
58
58
59
60
60
60
60
61
61
61
61
62
64
67
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1259761 | 1259761 | Sealing kit | |
| 4-13200 | 4-13200 | Frame accessories | |
| 1 | 4-13194 | Container lid | |
| 2 | 4-S19401 | Battery mounting | |
| 4 | 4-13193 | Cover | |
| 5 | 4-13199 | Holder | |
| 6 | 4-13192 | Cap | |
| 7 | 4-02258A | Plate | |
| 8 | 4-07200A | Ring | |
| 10 | 4-06947A | Bolt | |
| 11 | 4-13966 | Washer | |
| 12 | 4-5160670073 | Sealing plug | |
| 13 | 1178459 | Fluid motor | |
| 16 | 4-6160070611 | Rubber mount | |
| 17 | 4-5462000005 | Pivot bearing | |
| 18 | 4-5325030033 | Clamping device | |
| 19 | 4-6160100180 | Leadthrough | |
| 20 | 4-6160100181 | Leadthrough | |
| 21 | 4-9200000070 | Rubber mount | |
| 22 | 4-5462110028 | Nut | |
| 23 | 4-9500000380 | Cover | |
| 25 | 4-6160142402 | Ring | |
| 26 | 4-6160142131 | O-ring | |
| 27 | 1178470 | Nilos ring | |
| 28 | 4-5462070204 | Bearing | |
| 29 | 1179191 | Bearing | |
| 30 | 4-5535010242 | Circlip | |
| 31 | 4-5462110144 | Washer | |
| 33 | 4-3174000061 | Lock washer | |
| 34 | 4-3679600080 | Strain washer | |
| 35 | 4-3900017080 | Spring washer | |
| 36 | 4-3170600100 | Washer | |
| 38 | 4-3679600100 | Strain washer | |
| 39 | 4-3679600130 | Strain washer | |
| 40 | 4-3170600130 | Washer | |
| 45 | 4-3048500060 | Hexagon nut | |
| 46 | 4-3149200080 | ГАЙКА | |
| 47 | 4-3048500100 | Hexagon nut | |
| 53 | 4-3002506020 | Hexagon head screw | |
| 54 | 4-3002508016 | Hexagon head screw | |
| 55 | 4-3114308025 | Socket head cap screw | |
| 57 | 4-3002510030 | Hexagon head screw | |
| 58 | 4-3002512020 | Hexagon head screw | |
| 59 | 4-3002512025 | Hexagon head screw | |
| 60 | 4-5536210006 | Greasing nipple | |
| 61 | 4-5358030042 | Plug | |
| 62 | 4-5531020002 | Hose clamp | |
| 64 | 4-5422250006 | Sealing tape | |
| 67 | 4-6531013521 | Plate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
