Каталог запасных частей к технике: Ammann ARP 35. Cover hood
13
13
13
13
26
26
26
26
25
25
25
25
23
22
21
21
20
19
19
18
18
17
17
16
16
14
10
9
9
9
9
8
7
6
5
4
3
2
1
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 13 | 4-3178102525 | Split-pin | |
| 26 | 4-3679600080 | Strain washer | |
| 25 | 4-3679600060 | Strain washer | |
| 23 | 4-3900017050 | Spring washer | |
| 22 | 4-3170200053 | Washer | |
| 21 | 4-3172900090 | Washer | |
| 20 | 4-3048500050 | Hexagon nut | |
| 19 | 4-3002508025 | Hexagon head screw | |
| 18 | 4-3002508020 | Hexagon head screw | |
| 17 | 4-3001506022 | Hexagon head screw | |
| 16 | 4-3002506012 | Hexagon head screw | |
| 14 | 4-3115505016 | Oval head countersunk screw | |
| 4-19445 | 4-19445 | Covering hood | |
| 10.01 | 4-9500001014 | Key | |
| 10 | 4-9500001016 | Tongue lock | |
| 9 | 4-6150020021 | Rubber profile | |
| 8 | 4-5358010501 | Hinge | |
| 7 | 4-19524 | Pull rod | |
| 6 | 4-20278 | Plate | |
| 5 | 4-19447 | Plate | |
| 4 | 4-19446 | Plate | |
| 3 | 4-19509 | Cover | |
| 2 | 4-S19448 | Rear cover | |
| 1 | 4-S19488 | Front cover |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
