Каталог запасных частей к технике: Ammann AP 240. Steering hydraulics
2
2
3
4
5
6
10
11
11
12
13
14
17
17
17
17
18
19
19
20
20
20
20
21
24
24
26
30
31
34
35
35
36
37
37
38
40
42
43
46
47
48
53
53
53
53
53
54
54
55
60
60
60
60
60
61
65
65
66
66
69
69
70
70
71
71
72
72
73
73
74
74
75
75
76
76
80
81
81
82
82
83
83
90
93
95
98
101
101
101
101
101
101
102
106
107
110
113
113
115
120
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4-09900A | 4-09900A | Steering hydraulics | |
| 2 | 4-423838 | КОЛЬЦО | |
| 3 | 4-10761A | Hook | |
| 4 | 4-410763 | ЦАПФА | |
| 5 | 4-10918A | Spacer element | |
| 6 | 4-11369A | Threaded rod | |
| 10 | 4-S5451180156 | Hydraulic cylinder | |
| 11 | 1209014 | Servo valve | |
| 12 | 1210637 | Valve | |
| 13 | 4-5160680039 | ВЕНТИЛЬ | |
| 14 | 4-5536210006 | Greasing nipple | |
| 17 | 4-5160650038 | Screwed connection | |
| 18 | 4-5160650112 | Connector | |
| 19 | 4-5160650059 | Screwed connection | |
| 20 | 4-5160650085 | Screwed connection | |
| 21 | 4-5160650050 | Screwed connection | |
| 24 | 4-5160680038 | БОЛТ | |
| 26 | 4-5160660082 | Clutch | |
| 30 | 4-5160670029 | Screwed connection | |
| 31 | 4-5160670076 | Adjustable male stud run | |
| 34 | 4-5160670065 | L-connection | |
| 35 | 4-5160670056 | T-socket | |
| 36 | 4-5160660031 | T-socket | |
| 37 | 4-5160660015 | ТРОЙНИК Т | |
| 38 | 4-5160660067 | T-socket | |
| 40 | 4-5160670124 | Reduction | |
| 42 | 4-5160680050 | Flange | |
| 43 | 4-5160680164 | Flange | |
| 46 | 4-5160660046 | МУФТА | |
| 47 | 4-5358050082 | Quick-release coupling | |
| 48 | 4-5160660083 | Cover | |
| 53 | 4-5160580027 | Sleeve | |
| 54 | 4-5358050066 | Sleeve | |
| 55 | 4-5358050039 | Sleeve | |
| 60 | 4-5358050032 | Cap | |
| 61 | 4-5358050047 | Cap | |
| 65 | 4-5160572310 | Hydraulic hose | |
| 66 | 4-5160572315 | Hydraulic hose | |
| 69 | 4-5160572305 | Hydraulic hose | |
| 70 | 4-5160572314 | Hydraulic hose | |
| 71 | 4-5160572313 | Hydraulic hose | |
| 72 | 4-5160572312 | Hydraulic hose | |
| 73 | 4-5160572309 | Hydraulic hose | |
| 74 | 4-5160572308 | Hydraulic hose | |
| 75 | 4-5160572307 | Hydraulic hose | |
| 76 | 4-5160572304 | Hydraulic hose | |
| 80 | 4-5160572301 | Hydraulic hose | |
| 81 | 4-5160572306 | Hydraulic hose | |
| 82 | 4-5160572311 | Hydraulic hose | |
| 83 | 4-5160572302 | Hydraulic hose | |
| 90 | 4-5160572303 | Hydraulic hose | |
| 93 | 4-5160572298 | Hydraulic hose | |
| 95 | 4-5535010030 | СТОПОРНОЕ КОЛЬЦО | |
| 98 | 4-3114306030 | Socket head cap screw | |
| 101 | 4-3002508040 | БОЛТ | |
| 102 | 4-3002508045 | Hexagon head screw | |
| 106 | 4-3048500080 | Hexagon nut | |
| 107 | 4-3048500100 | Hexagon nut | |
| 110 | 4-3170200064 | ШАЙБА | |
| 113 | 4-3900017080 | Spring washer | |
| 115 | 4-3900017100 | Spring washer | |
| 120 | 4-5358030042 | Plug |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
