Каталог запасных частей к технике: Vaderstad Carrier CR420-820. Lighting, rear CR 420-820, 4761-
1
2
3
4
5
5
6
7
8
9
10
11
12
13
13
13
14
14
15
15
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 451306 | Lighting | |
| 2 | 451308 | Plate | |
| 3 | 446695 | Rear lights glass | |
| 3 | 413499 | Bulb | |
| 3 | 413339 | Bulb | |
| 3 | 450596 | Rear Lights | |
| 4 | 429694 | Plug | |
| 5 | 307393 | Reflex, yellow | |
| 6 | 307392 | Reflex, red | |
| 7 | 451313 | Pin | |
| 8 | 451312 | Pin | |
| 9 | 451314 | Spring | |
| 9 | 458123 | Spring | |
| 10 | 451319 | Washer | |
| 11 | 50000602022 | Screw | |
| 12 | 52030600092 | Washer | |
| 13 | 51010600021 | Lock nut | |
| 14 | 51000600021 | Nut | |
| 15 | 50130601671 | Screw | |
| 16 | 51010500021 | Lock nut | |
| 17 | 451310 | Bracket | |
| 18 | 433004 | Extension cable with contact implement | |
| 19 | 51010800021 | Lock nut | |
| 20 | 52000500041 | Washer | |
| 21 | 451317 | Connector | |
| 22 | 451318 | Cable harness | |
| 23 | 451311 | Bracket | |
| 24 | 451316 | Connector | |
| 25 | 307388 | Warning board | |
| 25 | 307389 | Warning board | |
| 26 | 421460 | Plate | |
| 27 | 421434 | Decal 25 km/h | |
| 28 | 50000602021 | Screw | |
| 28 | 50000606021 | Screw | |
| 29 | 456353 | Bushing | |
| 30 | 52000600041 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
