1
1
2
3
3
4
5
6
6
7
8
9
10
11
Позиция на иллюстрации
Заводской номер детали
Название детали
1
72186231
ALARM
2
440134A1
BRACKET
3
86639317
WASHER
4
86624176
WASHER
5
86500688
NUT
6
86624176
WASHER
7
86624978
BOLT
8
86500689
NUT
9
435437A1
STRAP
10
391364A1
HARNESS
11
121410A1
FUSE
