Каталог запасных частей к технике: New Holland T9.615, T9.670. TRANSMISSION TO COOLER LINES

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано AGCO Amity CASE IH DongFeng Fortschritt Foton Franz Kleine Gaspardo Great Plains KRONE KUHN Lemken Lovol MacDon Massey Ferguson New Holland TIGARBO Vaderstad Versatile Wirax Агро Агротехмаш Бобруйскагромаш (ОАО «УКХ «Бобруйскагромаш») БЭМЗ ВгТЗ Воронежсельмаш ВТЗ Гомсельмаш ДКЗ ЗАО "Техника-сервис" ЗиД КЗК Кировец-Ландтехник Клевер Красная Звезда Лидагропроммаш Лидсельмаш ЛТЗ Машстройхолдинг Минитракторы Мордовагромаш МТЗ Навигатор-Новое машиностроение Нефтекамский автозавод ПТЗ Ремком РСМ Сибсельмаш ТеКЗ ТКЗ ХЗТСШ ХТЗ ЮМЗ

Модель Не выбрано CSX7080 (D660) (2008) T8 (2012) T9.615, T9.670 (2012) TL5040 (2012) TS6.110 (2012) Комбайн CR9080 E3 (часть 1) (2014) Комбайн CR9080 E3 (часть 2) (2014) Трактор T9.505 (часть 1) (2012) Трактор T9.505 (часть 2) (2012) Трактор TJ425 (часть 1) (2010) Трактор TJ425 (часть 2) (2010)

Схема > Не выбрано FILTERS AND CAPACITIES ARTICULATION LOCKS FIRE EXTINGUISHER MOUNTING (EUROPE) INITIAL STOCKING LIST "A" (ISL) INITIAL STOCKING LIST "B" (ISL) HEATER - ENGINE BLOCK ENGINE MOUNTS AIR INTAKE AIR INTAKE AIR INTAKE AIR CLEANER & PLENUM AIR CLEANER & FILTERS FILTER - FUEL, WITH WIF SENSOR FUEL LINES, LIFT PUMP & COOLER, FRONT FUEL LINES, FILTER, & SIGHT GAUGE, REAR FUEL TANKS / REAR FENDERS - T9.670 ENGINE COOLING SYSTEM RADIATOR & COOLERS HYDRAULIC FAN, MOTOR, & ATTACHMENTS HYDRAULIC FAN PLUMBING SCR TANK AND PLUMBING DEF/SCR TANK SCR EXHAUST EXHAUST, TIER 2 (NO SCR) - T9.615 AND T9.670 SCR WIRING AND DENOX2 MODULE HEAT SHIELD, SCR EXHAUST (EUROPE) LUBE - HYDRAULIC PUMP DRIVE WITHOUT PTO LUBE - HYDRAULIC PUMP DRIVE WITH PTO LUBE - PTO TRANSFER CASE HYDRAULIC PUMP DRIVE WITH & WITHOUT PTO - MOUNTING & VALVES HYDRAULIC PUMP DRIVE WITHOUT PTO - HOUSING COVERS AND SERVO HYDRAULIC PUMP DRIVE WITH PTO - AUXILIARY DRIVE COVER HYDRAULIC PUMP DRIVE WITH PTO - HOUSING COVERS, SERVO, AND YOKE HYDRAULIC PUMP DRIVE WITH & WITHOUT PTO - IDLER SHAFT, INPUT SHAFT, OUTPUT SHAFT, & DRIVE GEAR HYDRAULIC PUMP DRIVE WITH PTO - INPUT CLUTCH SHAFT PTO - TRANSFER CASE MOUNTING PTO - TRANSFER CASE PTO DRIVELINES AND MOUNTING (NORTH AMERICA) PTO DRIVELINES AND MOUNTING (EUROPE) PTO DRIVELINES & HANGER BEARING ASSEMBLIES POWER SHIFT TRANSMISSION - LUBRICATION POWER SHIFT TRANSMISSION - OIL FILTER TRANSMISSION OIL COOLER & HOSES TRANSMISSION TO COOLER LINES POWER SHIFT TRANSMISSION - TRANSMISSION MOUNTING POWER SHIFT TRANSMISSION - REAR HOUSING, YOKES, AND RETAINERS, PS4, 8.5C POWER SHIFT TRANSMISSION - REAR HOUSING, YOKES, AND RETAINERS, PS6, 9C POWER SHIFT TRANSMISSION - FRONT HOUSING POWER SHIFT TRANSMISSION - FRONT HOUSING YOKES AND RETAINERS, PS4, 8.5C POWER SHIFT TRANSMISSION - FRONT HOUSING YOKES AND RETAINERS, PS6, 9C POWER SHIFT TRANSMISSION - VALVE MOUNTING POWER SHIFT TRANSMISSION - REGULATOR VALVE POWER SHIFT TRANSMISSION - RANGE SELECTOR VALVE POWER SHIFT TRANSMISSION - SHAFT ASSEMBLIES AND CLUTCHES, PS4, 8.5C POWER SHIFT TRANSMISSION - SHAFT ASSEMBLIES AND CLUTCHES, PS6, 9C POWER SHIFT TRANSMISSION - 1ST INPUT SHAFT, PS4, 8.5C POWER SHIFT TRANSMISSION - 1ST INPUT SHAFT, PS4, 8.5C POWER SHIFT TRANSMISSION - 1ST INPUT SHAFT, PS6, 9C POWER SHIFT TRANSMISSION - 1ST INPUT SHAFT, PS6, 9C POWER SHIFT TRANSMISSION - 2ND SHAFT, PS4, 8.5C POWER SHIFT TRANSMISSION - 2ND SHAFT, PS6, 9C POWER SHIFT TRANSMISSION - 4TH SHAFT, PS4, 8.5C POWER SHIFT TRANSMISSION - 4TH SHAFT, PS6, 9C POWER SHIFT TRANSMISSION - 5TH OUTPUT SHAFT, PS4, 8.5C POWER SHIFT TRANSMISSION - 5TH OUTPUT SHAFT, PS6, 9C DRIVESHAFT MOUNTING - WITH 8.5C TRANSMISSION - T9.615 DRIVESHAFTS - WITH 8.5C TRANSMISSION - T9.615 DRIVESHAFT MOUNTING - 500 SERIES AXLE WITH 8.5C OR 9C TRANSMISSION - T9.615 & T9.670 DRIVESHAFTS - 500 SERIES AXLE WITH 8.5C OR 9C TRANSMISSION - T9.615 & T9.670 DRIVESHAFT MOUNTING - 600 SERIES AXLE WITH 9C TRANSMISSION - T9.670 DRIVESHAFTS - 600 SERIES AXLE WITH 9C TRANSMISSION - T9.670 PARK BRAKE - HYDRAULICS (NORTH AMERICA) PARK BRAKE - HYDRAULICS (EUROPE) PARK BRAKE - VALVE ASSEMBLY AND FITTINGS, TOW/PARK BRAKE (NORTH AMERICA) PARK BRAKE - VALVE ASSEMBLY AND FITTINGS, TOW/PARK BRAKE (EUROPE) PARK BRAKE - VALVE ASSEMBLY, TOW/PARK BRAKE (EUROPE) PARK BRAKE - VALVE COMPONENTS, TOW/PARK BRAKE (EUROPE) PARK BRAKE - VALVE COMPONENTS, TOW/PARK BRAKE (EUROPE) BRAKE VALVE - HIGH PRESSURE TRAILER BRAKES - HYDRAULIC LAYOUT HYDRAULIC PUMP - AXLE / MAIN CHARGE HYDRAULIC PUMP, VARIABLE DISPLACEMENT HYDRAULIC PUMP MOUNTING & FITTINGS - STANDARD HYDRAULICS HYDRAULIC PUMP - STANDARD HYDRAULICS - PISTON PUMP, 71CC HYDRAULIC PUMP MOUNTING & FITTINGS - HIGH OUTPUT HYDRAULICS HYDRAULIC PUMP - HIGH OUTPUT HYDRAULICS - PISTON PUMP, 100CC HYDRAULIC PUMP - MEGAFLOW, 85CC CYLINDER ASSY - THREE POINT HITCH THREE POINT HITCH THREE POINT HITCH - ROCKERSHAFT THREE POINT HITCH - UPPER LINK, WITHOUT POWER TAKEOFF THREE POINT HITCH - UPPER LINK, WITH POWER TAKEOFF LINK ASSEMBLY - UPPER LINK ASSEMBLY - LIFT QUICK HITCH THREE POINT HITCH - HYDRAULIC PLUMBING 500 & 600 SERIES WHEELED AXLE - AXLE LUBE FRONT, WITH AND WITHOUT DIFFERENTIAL LOCK 500 & 600 SERIES WHEELED AXLE - AXLE LUBE REAR, WITH AND WITHOUT DIFFERENTIAL LOCK AUXILIARY VALVE STACK - 4 SPOOL AUXILIARY VALVE STACK - 4 SPOOL - SCRAPER UNITS - T9.615 AUXILIARY VALVE STACK - 4 SPOOL, W/ THREE POINT HITCH AUXILIARY VALVE STACK - 4 SPOOL, W/ TRAILER BRAKES AUXILIARY VALVE STACK - 4 SPOOL, W/ TRAILER BRAKES - SCRAPER UNITS - T9.615 AUXILIARY VALVE STACK - 4 SPOOL, W/ THREE POINT HITCH & TRAILER BRAKES AUXILIARY VALVE STACK - 6 SPOOL AUXILIARY VALVE STACK - 6 SPOOL, W/ THREE POINT HITCH AUXILIARY VALVE STACK - 6 SPOOL, W/ TRAILER BRAKES AUXILIARY VALVE STACK - 6 SPOOL, W/ THREE POINT HITCH & TRAILER BRAKES AUXILIARY VALVE STACK - 8 SPOOL AUXILIARY VALVE STACK - 8 SPOOL, W/ TRAILER BRAKES VALVE ASSEMBLY - AUXILIARY - MAIN, RIGHT, & LEFT VALVE ASSEMBLY - TRAILER BRAKE / PRIORITY VALVE ASSEMBLY - THREE POINT HITCH VALVE ASSEMBLY - CONNECTOR VALVE COUPLER ASSEMBLY VALVE COUPLER ASSEMBLY - SCRAPER UNITS POWER BEYOND COUPLERS LOW PRESSURE RETURN MEGA/TWIN FLOW PLUGS DRAIN HOSES - AUXILIARY VALVE STACK - 4, 6, & 8 SPOOL DRAIN BOTTLES - AUXILIARY VALVE STACK - 4, 6, & 8 SPOOL REMOTE HYDRAULIC HOSES REMOTE HYDRAULIC HOSES HYDRAULICS - FILTER, FILTER SUPPORT, & PLUMBING, STANDARD FLOW HYDRAULICS - FILTER, FILTER SUPPORT, & PLUMBING, HIGH FLOW HYDRAULICS - FILTER & FILTER HEAD COOLER - HYDRAULIC OIL & HOSES HYDRAULIC OIL TANK STANDARD HYDRAULICS - PUMP LUBRICATION CIRCUIT HIGH OUTPUT HYDRAULICS - PUMP LUBRICATION CIRCUIT HIGH FLOW HYDRAULICS - HOSES & PUMP SOLENOID VALVE, DIFFERENTIAL LOCK CHARGE RELIEF VALVE COOLER BYPASS VALVE DRAWBAR - HEAVY DUTY, WITHOUT THREE POINT HITCH DRAWBAR - HEAVY DUTY, WITH THREE POINT HITCH DRAWBAR - STANDARD - T9.560 DRAWBAR - CATEGORY 5, WITHOUT THREE POINT HITCH DRAWBAR - CATEGORY 5, WITH THREE POINT HITCH DRAWBAR - QUICK HITCH - SCRAPER - T9.615 TOW CABLE WHEEL WEIGHTS - 500 & 1000 LBS. WHEEL WEIGHTS - 900 & 1600 LBS FRONT BUMPER BALLAST PACK - FRONT FRAME WEIGHT BALLAST PACK - REAR FRAME WEIGHT FRONT FRAME - WITHOUT SUSPENDED CAB FRONT FRAME - WITH SUSPENDED CAB REAR FRAME / FUEL TANK AND FENDERS - T9.615 REAR FRAME / FUEL TANKS AND FENDERS - T9.670 AUXILIARY VALVE MOUNT & OPTIONAL PTO BRACKET - WITHOUT PTO & THREE POINT HITCH CENTER CONNECTING LINK STEERING - HYDRAULIC CONTROL STEERING - HYDRAULIC CONTROL STEERING - HYDRAULIC CONTROL STEERING WHEEL STEERING COLUMN STEERING COLUMN CONTROLS STEERING - CONTROL VALVE STEERING CYLINDER, ATTACHMENTS STEERING CYLINDER - T9.615 STEERING CYLINDER - T9.670 AUTOGUIDANCE - VALVE, VALVE FITTINGS, & PLUMBING NON-AUTOGUIDANCE - VALVE, VALVE FITTINGS, & PLUMBING CONTROL VALVE - PRIORITY / STEERING FRONT AXLE MOUNTING REAR AXLE MOUNTING 500 SERIES AXLE - FRONT COVER - T9.615 & T9.670 500 SERIES AXLE - REAR COVER - T9.615 & T9.670 500 SERIES AXLE - CENTER AND LEFT-HAND CARRIER - T9.615 & T9.670 500 SERIES AXLE - DIFFERENTIAL, WITHOUT DIFFERENTIAL LOCK - T9.615 & T9.670 500 SERIES AXLE - DIFFERENTIAL, WITH DIFFERENTIAL LOCK - T9.615 & T9.670 500 SERIES AXLE - BRAKE AND RIGHT-HAND CARRIER - T9.615 & T9.670 500 SERIES AXLE - FINAL DRIVE - T9.615 & T9.670 600 SERIES AXLE - FRONT COVER - T9.670 600 SERIES AXLE - REAR COVER - T9.670 600 SERIES AXLE - CENTER AND LEFT-HAND CARRIER - T9.670 600 SERIES AXLE - DIFFERENTIAL, WITHOUT DIFFERENTIAL LOCK - T9.670 600 SERIES AXLE - DIFFERENTIAL, WITH DIFFERENTIAL LOCK - T9.670 600 SERIES AXLE - BRAKE AND RIGHT-HAND CARRIER - T9.670 600 SERIES AXLE - FINAL DRIVE - T9.670 AXLE LUBE MANIFOLD - 500 & 600 SERIES AXLES HUBS & WHEEL MOUNTING, 115MM AXLE - 500 SERIES AXLE HUBS & WHEEL MOUNTING, 140MM AXLE - 600 SERIES AXLE WHEEL SPACERS - 115MM AXLE, 10-BOLT HUB - 500 SERIES AXLE WHEEL SPACERS - 140MM AXLE, 18-BOLT HUB - 600 SERIES AXLE WHEELS AND SPACERS - 115MM AXLE, 10-BOLT HUB - 500 SERIES AXLE WHEELS - DUAL HUB WHEELS AND SPACERS - 140MM AXLE, 18-BOLT HUB - 600 SERIES AXLE WHEELS - TRIPLES HEATER HOSES AIR CONDITIONING - PLUMBING, COMPRESSOR, RECEIVER-DRYER HVAC AND CONTROLS HVAC AUTOMATIC TEMPERATURE CONTROL UNIT CAB AIR CLEANER HOUSING AND FILTER HVAC CAB AIR BLOWER FRONT CONSOLE HVAC - AIR DUCT, LOUVERS, AND INSULATION BATTERY CABLES BATTERY CABLES ENGINE HARNESS GROUP HARNESS - ENGINE HARNESS - TRANSMISSION LAYOUT HARNESS - TRANSMISSION HARNESSES - FRONT FRAME WIRING LAYOUT HARNESS - FRONT FRAME (NORTH AMERICA) HARNESS - FRONT FRAME (EUROPE) HARNESS - HYDRAULIC SUB ASSEMBLY HARNESS - WASHER BOTTLE HARNESSES - REAR FRAME WIRING LAYOUT (NORTH AMERICA) HARNESSES - REAR FRAME WIRING LAYOUT (EUROPE) HARNESS - REAR FRAME (NORTH AMERICA) HARNESS - REAR FRAME & TRAILER ADAPTER (EUROPE) HARNESS - SCR CHASSIS HARNESS - FRONT DASH HARNESS - FRONT LOWER WIPERS, LUXURY CAB HARNESS - CAB ROOF HARNESS - ARMREST ELECTRIC ADJUST HARNESS - AUXILIARY POWER HARNESS - MAIN CAB - NORTH AMERICA HARNESS - MAIN CAB - NORTH AMERICA HARNESS - MAIN CAB - NORTH AMERICA HARNESS - MAIN CAB - EUROPE HARNESS - MAIN CAB - EUROPE HARNESS - MAIN CAB - EUROPE HARNESS - THREE POINT HITCH HARNESSES - DIFFERENTIAL LOCK WIRING LAYOUT HARNESS - CHASSIS LIGHTS HARNESS - AUTO GUIDANCE, CAB & CHASSIS HARNESS - DISPLAY HARNESS - ISO, CHASSIS & CAB HARNESS - GPS ANTENNA, ROOF & SUB-ROOF HARNESS - FRONT & REAR MARKER LIGHTS (EUROPE) PTO HARNESS AND GEAR SPEED SENSOR HARNESS, SPOOL ADAPTER - EHR VALVES - 4 SPOOL HARNESS, SPOOL ADAPTER - EHR VALVES - 5, 6, & 8 SPOOL HARNESS - IMPLEMENT DEPTH CONTROLL HARNESS HARNESS, BATTERY EQUALIZER, SCR, 24V SYSTEM ALTERNATOR BATTERIES AND TRAY ASSEMBLY - T9.615 AND T9.670 POWER DISCONNECT - STARTER POWER DISCONNECT - CAB HEADLIGHTS - CHASSIS HEADLIGHTS - EUROPE TAIL LIGHTS - T9.615 TAIL LIGHTS (NORTH AMERICA) - T9.670 TAIL LIGHTS (EUROPE) - T9.670 REAR WORK LIGHTS LATERAL HID WORK LIGHTS MARKER LIGHTS, REAR (NORTH AMERICA) MARKER LIGHTS (EUROPE) WARNING LIGHTS - FRONT (EUROPE) WARNING LIGHTS - REAR (EUROPE) BEACON LIGHT - SINGLE BEACON LIGHT - DUAL BACK-AP ALARM GROUND SPEED RADAR ARMREST - ELECTRONIC CONTROLS & MONITORS ARMREST - ELECTRONIC JOYSTICK W/ PROPORTIONAL ROCKER CONTROL ARMREST CONTROLS - ELECTRIC ADJUST FORWARD-NEUTRAL-REVERSE POD FRONT CONSOLE SWITCHES - IGNITION & DIMMER ELECTRONIC CONTROL UNIT (ECU) INSTRUMENT CONTROL UNIT (ICU3) THREE POINT HITCH - WIRING & SWITCHES THREE POINT HITCH - REMOTE SWITCH ISO INTERFACE & TECU CONTROLLER CAB - MAIN ELECTRICAL CAB - RIGHT OVERHEAD CONSOLE, SWITCHES AND RADIO CAB - MAIN ELECTRONICS, HARNESS WITH FUSES AND RELAYS SPEAKERS AND ANTENNA BUSINESS BAND ANTENNA EXTERIOR MIRRORS - ELECTRIC ADJUST CLUTCH AND BRAKE CONTROL ELECTRONICS CLUTCH AND BRAKE CONTROL ELECTRONICS LIGHTING - CAB ROOF, EXTERIOR LIGHTING - CAB ROOF, INTERIOR WIPERS - STANDARD FRONT, REAR, RESERVOIR, & PLUMBING WIPERS - LOWER FRONT & PLUMBING, LUXURY CAB GPS RECEIVER - AFS262 WAAS/EGNOS/VBS GPS RECEIVER - AFS262 WAAS/EGNOS/VBS/HP/XP GPS RECEIVER - HARNESSES AND MOUNTING BRACKET AUTO GUIDANCE - HARNESSES AND SENSORS AFS MONITOR - FRED II LARGE TOUCHSCREEN DISPLAY BATTERY EQUALIZER/CONVERTER TOOL BOX AND MOUNTING LIFE HAMMER (EUROPE) DIA KIT - FIRE EXTINGUISHER DIA KIT - ENGINE BLOCK HEATER, 120 VOLT DIA KIT - ENGINE BLOCK HEATER, 240 VOLT DIA KIT - ENGINE BRAKE - CURSOR 13, 2-STAGE DIA KIT - PTO (NON-EUROPE) DIA KIT - PTO (EUROPE) DIA KIT - TRANSMISSION HEATER, 120 V DIA KIT - TRANSMISSION HEATER, 240 V DIA KIT - ADDITIONAL (+1) EHR VALVE DIA KIT - 4 TO 6 OR 8 EHR VALVES - CAB & ELECTRICAL COMPONENTS DIA KIT - POWER BEYOND COUPLER & LOW PRESSURE MOTOR RETURN DIA KIT - MEGAFLOW / TWINFLOW DIA KIT - HYDRAULIC REMOTE OIL DRAIN BOTTLE DIA KIT - AUXILIARY PUMP DRIVE DIA KIT - 2ND CASE DRAIN DIA KIT - THREE POINT HITCH, W/ ELECTRONIC REMOTES DIA KIT - 3/4" COUPLER DIA KIT - IMPLEMENT DEPTH CONTROL DIA KIT - FRONT TOW HOOK DIA KIT - SCRAPER REVERSE HITCH ADAPTER (STINGER) DIA KIT - FRONT BUMPER BALLAST W/OUT SUITCASE WEIGHT MOUNTS DIA KIT - FRONT BUMPER BALLAST W/ SUITCASE MOUNTS DIA KIT - REAR FRAME BALLAST DIA KIT - SUITCASE WEIGHT - 45 KG (100 LB) DIA KIT - WHEEL WEIGHTS, 500 & 1000 LBS DIA KIT - WHEEL WEIGHTS, 900 & 1600 LBS - T9.670 DIA KIT - LOWER FRONT WIPERS DIA KIT - BACKUP ALARM DIA KIT - ELECTRIC ARMREST ADJUSTMENT DIA KIT - ELECTRIC MIRRORS - EXTERIOR DIA KIT - ISO 11783 READY DIA KIT - CAB POWER DISCONNECT DIA KIT - AUTO GUIDANCE READY DIA KIT - BUSINESS BAND ANTENNA DIA KIT - RADIO, AM/FM/WB DIA KIT - RADIO, AM/FM/WB/SINGLE CD DIA KIT - GROUND SPEED RADAR DIA KIT - DUAL BEACON LIGHT DIA KIT - MARKER LIGHTS (NORTH AMERICA) DIA KIT - REAR HID WORK LIGHTS DIA KIT - LATERIAL HID WORK LIGHTS DIA KIT - HID HEADLIGHTS DIA KIT - SMOKING PACKAGE DIA KIT - MANUAL MIRRORS DIA KIT - INSTRUCTIONAL SEAT, CLOTH DIA KIT - "A" POST MONITOR MOUNT DIA KIT - RH WINDOW MONITOR MOUNT DIA KIT - FRED II DISPLAY READY DIA KIT - DECELERATOR PEDAL ENGINE HOOD, GRILLE, AND SUPPORT ENGINE HOOD, GRILLE, AND SUPPORT ENGINE HOOD, GRILLE, AND SUPPORT ENGINE HOOD LATCH (NORTH AMERICA) ENGINE HOOD LATCH (EUROPE) ENGINE DEBRIS SCREENS ACCESS DOOR AND PLATFORM ACCESS LADDER, RIGHT SIDE DECALS - HOOD AND SADDLE TANK DECALS - REMOTE VALVES, RIGHT AND LEFT DECALS, NA/ AUS. DECALS - N/A & AUS DECALS, ISO DECALS - ISO CLUTCH AND BRAKE CONTROL PEDALS DECELERATOR PEDAL CABLE - TOW VALVE CONTROL ARMREST ARMREST - MECHANICAL ADJUST ARMREST - MONITOR MOUNT MONITOR MOUNT - BAR TO MONITOR MONITOR MOUNT - RIGHT HAND WINDOW AND A-POST FRONT FENDERS - RIGHT AND LEFT SIDE REAR FENDERS AND SUPPORTS - RIGHT AND LEFT SIDE - T9.615 LADDER - DRIVER'S PLATFORM ACCESS, LEFT SIDE EXTERIOR MIRRORS - MANUAL ADJUST INSTRUCTIONAL SEAT SEAT TEATHER KIT - SCRAPER VERSION - T9.615 SEAT - OPERATORS SEAT - CUSHION ASSEMBLY SEAT - POSITIVE RESPONSE SUSPENSION ASSEMBLY SEAT COMPRESSOR KIT SEAT COMPRESSOR SERVICE KIT CAB MOUNTING, NON-SUSPENSION CAB MOUNTING, SUSPENSION CAB MOUNTING, SUSPENSION CAB FRAME, NON-SUSPENDED CAB FRAME, SUSPENDED CAB SKIRTS - STANDARD, DELUXE CAB, NON-SUSPENDED CAB SKIRTS - STANDARD, DELUXE CAB, SUSPENDED CAB SKIRTS - LUXURY CAB, NON-SUSPENDED CAB SKIRTS - LUXURY CAB, SUSPENDED CAB ROOF FOPS PLATE - T9.615 DOOR - LEFT HAND, INSTALLATION DOOR - LEFT HAND, COMPONENTS DOOR - RIGHT HAND, INSTALLATION DOOR - RIGHT HAND, COMPONENTS FRONT & REAR WINDOWS AND MOUNTING INTERIOR TRIM, CAB - COVERS, PANELS, AND FASTENERS INTERIOR TRIM, CAB - FLOORMATS, ACOUSTICAL BARRIERS, AND INSULATING FOAM INTERIOR TRIM, DELUXE CAB - FLOORMATS AND TRANSMISSION COVER PLATE INTERIOR TRIM, LUXURY CAB - FLOORMATS AND TRANSMISSION COVER PLATE INTERIOR TRIM, CAB - ELECTRICAL AREA & NON-TRAINER SEAT COVERS HEADLINER - WITH BLINDS, INSERTS, CONSOLE AND MIRROR HEADLINER - STANDARD FRONT CONSOLE AND SUPPORT

1

2

3

4

4

5

6

7

7

8

9

10

11

Позиция на иллюстрации	Заводской номер детали		Название детали
1	700-387		ELBOW, 45є, 1 3/16"-12 ORFS x M27 x 2 ORB, Inc. 2 - 3
2	637-64236		O-ring
3	238-6018		O-ring
4	84244557		HOSE ASSY., Transmission Cooler, PS4, 8C and 8.5C
4	84244561		HOSE ASSY., Transmission Cooler, PS6, 9C
5	84293545		HYD. TUBE, Transmission Oil Cooler Supply
6	84293547		HYD. TUBE, Transmission Oil Cooler Return
7	238-6018		O-ring
8	50-2551T1		Clamp
9	50-2533T1		Plate
10	895-11008		Washer
11	827-8065		Bolt

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
