Каталог запасных частей к технике: New Holland T9.615, T9.670. HARNESS - MAIN CAB - EUROPE

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
8
8
9
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Позиция на иллюстрации Заводской номер детали Название детали
1 84311783 Harness
2 179483А1 CONNECTOR, TO HVAC ATC Floor Module, C055F
3 239451А1 ELEC CONNECTOR, Female, 4 Pin, HVAC Module J1939, C059M
4 225316С1 ELEC CONNECTOR, Female, 2 Pin, Strobe/Beacon Lamp, C920M
5 225389С1 CONNECTOR, To Seat Controls, C642M
6 87410946 Wire connector
7 877291R1 Elec connector
8 84177907 Elec connector
9 227728А1 CONNECTION,ELECTRIC, Aux Power Outlet 1 and 2, C028M, C027M
10 872290R1 Elec connector
11 245488С1 ELEC CONNECTOR, 6 Pin, Lighting Logic Diode, C670M
12 87410948 Contact housing
13 87419488 Multipole connector
14 631801С1 CONNECTION, High, Low, and Work Lighting, CM494J, CM440B/CM440A, CM477C
15 113699А1 RECTIFIER, Diode, High, Low, and Work Lighting
16 739070С1 CONNECTOR, High, Low, and Work Lighting,
17 245482С1 ELEC CONNECTOR, 2 Pin, Left Front Work Light, C935M
18 245483С1 ELEC CONNECTOR, Male, 2 Pin, Left Front Work Light, DC935F
19 280451А1 CONNECTOR,ELECTRIC, To Implement Connections, C686M
20 280453А1 ELEC CONNECTOR, Male, 6 Pin, Plug, DC686F
21 223671А1 ELEC CONNECTOR, Female, 12 Pin, Scraper
22 223672А1 Remote/Draft Interface, C684M ELEC CONNECTOR, Male, 12 Pin, Plug, DC684F
23 87697628 Elec connector
24 225351C1 Elec connector
25 87696573 Elec connector
26 87698287 Elec connector
27 87382910 Wire connector
28 87382911 Wire connector
29 335461A1 Connector
30 223671A1 Contact housing
31 NSS Yoke
32 NSS Yoke
33 239451A1 Multipole connector
34 225326C1 Elec connector
35 84177900 Elec connector
36 87696184 Nut
37 84178657 Elec connector
38 87696194 Thin nut
39 298079A1 Connector
40 131735A1 Diode
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
