4. Комбайн CR9080 E3 (часть 2)
5. SHIELD STONE ROLL, LH

Каталог запасных частей к технике: New Holland Комбайн CR9080 E3 (часть 2). SHIELD STONE ROLL, LH

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано AGCO Amity CASE IH DongFeng Fortschritt Foton Franz Kleine Gaspardo Great Plains KRONE KUHN Lemken Lovol MacDon Massey Ferguson New Holland TIGARBO Vaderstad Versatile Wirax Агро Агротехмаш Бобруйскагромаш (ОАО «УКХ «Бобруйскагромаш») БЭМЗ ВгТЗ Воронежсельмаш ВТЗ Гомсельмаш ДКЗ ЗАО "Техника-сервис" ЗиД КЗК Кировец-Ландтехник Клевер Красная Звезда Лидагропроммаш Лидсельмаш ЛТЗ Машстройхолдинг Минитракторы Мордовагромаш МТЗ Навигатор-Новое машиностроение Нефтекамский автозавод ПТЗ Ремком РСМ Сибсельмаш ТеКЗ ТКЗ ХЗТСШ ХТЗ ЮМЗ

Модель Не выбрано CSX7080 (D660) (2008) T8 (2012) T9.615, T9.670 (2012) TL5040 (2012) TS6.110 (2012) Комбайн CR9080 E3 (часть 1) (2014) Комбайн CR9080 E3 (часть 2) (2014) Трактор T9.505 (часть 1) (2012) Трактор T9.505 (часть 2) (2012) Трактор TJ425 (часть 1) (2010) Трактор TJ425 (часть 2) (2010)

Схема > Не выбрано FEEDER SENSOR PLATE FEEDER, BALANCE FRAME BOTTOM PLATE BOTTOM PLATE FOR OPEN CONVEYOR STONE ROLL FRAME, (Prod Date) before 14-MAR-2013 STONE ROLL FRAME, (Prod Date) after 15-MAR-2013 STONE SUMP STONE ROLL SHAFT STONE ROLL FEEDER SHIELDS, LH FEEDER SHIELDS, RH FEEDER CHAIN (4) UPPER SHAFT DRUM, (Prod Date) before 14-JAN-2014 DRUM, (Prod Date) after 15-JAN-2014 CROP FEEDING AND CONTROL CHAIN CROP FEEDING DRIVE BELT CROP FEEDING DRIVE SHAFT PRODUCT FEEDING DRIVE BELT, 4HB PRODUCT FEEDING TENSIONER, 4HB PRODUCT FEEDING DRIVE BELT, 2HB PRODUCT FEEDING TENSIONER, 2HB HEADER DRIVE SHAFT, 3HB FOR CORN AND BEANS HEADER DRIVE BELT, 3HB FOR CORN AND BEANS HEADER DRIVE SHAFT, 2HB FOR GRAIN HEADER DRIVE BELT, 2HB FOR GRAIN VARIABLE HEADER DRIVE SHAFT FOR CORN AND BEANS VARIABLE HEADER DRIVE GEAR FOR CORN AND BEANS VARIABLE HEADER DRIVE BELT FOR CORN AND BEANS PRODUCT FEEDING DRIVE BELT 4HB WITH STONE TRAP PRODUCT FEEDING TENSIONER 4HB WITH STONE TRAP HEADER DRIVE SHAFT 3HB WITH STONE TRAP HEADER DRIVE 3HB WITH STONE TRAP HEADER DRIVE BELT AND TENSIONER 3HB WITH STONE TRAP HIGH SPEED STONE TRAP MODULE DRIVE LOW SPEED STONE TRAP MODULE DRIVE REVERSER ROTOR BEARING CONCAVE FOR SMALL GRAIN AND FIELD PEAS CONCAVE WITH ROUND BARS, (Prod Date) before 31-JAN-2014 CONCAVE WITH ROUND BARS, (Prod Date) after 01-FEB-2014 CONCAVE WITH SPIRAL ROUND BARS CONCAVE FOR RICE, CORN AND BEANS ROUND BAR SEPARATOR GRATES ROUND BAR SEPARATOR GRATES, WET CORN AWNING PLATES PERFORATED SEPERATOR GRATES CONCAVE CONTROL MAIN DRIVE DRUM VARIATOR BELT DRUM VARIATOR BRIDGE DRUM VARIATOR SPRING LOAD ADJUSTMENT HYDRAULICS ROTOR AND FEEDER VARIATOR ROTOR CORN AND GRAIN TWIN PITCH, RH ROTOR CORN AND GRAIN TWIN PITCH, LH TWIN PITCH REBUILD KIT - FOR SMALL GRAIN, CORN AND BEANS ROTOR, SMALL GRAIN, RH ROTOR, SMALL GRAIN, LH ROTOR, RICE, TWIN PITCH, RH ROTOR, RICE, TWIN PITCH, LH TWIN PITCH REBUILD RICE ROTOR CORN AND BEAN RH ROTOR CORN AND BEAN LH HARD THRESHING KIT KIT SERRATED AUGER LUGS AND SERRATED ROTOR EXTENSIONS DUAL SPEED ROTOR DRIVE ROTOR GEARBOX LH ROTOR DRIVE ROTOR GEARBOX 2-SPEED ROTOR SLUG WRENCH, (Prod Date) before 12-AUG-2012 SLUG WRENCH, (Prod Date) after 13-AUG-2012 FINGER SET SUNFLOWER COVER KIT BEATER DRIVE SHAFT BEATER DRIVE PULLEYS COVER PLATES ADJUSTABLE VANES, COVER PLATES INFEED AND SEPARATOR FRONT ADJUSTABLE VANES, TOP COVER PLATES INFEED AND SEPARATOR ADJUSTABLE VANES, TOP COVER PLATES, ABRASIVE ADJUSTABLE VANES, TOP COVER PLATES, ABRASIVE ROTARY SEPARATOR, SHAFT DISCHARGE BEATER BEATER ADJUSTMENT ROD BEATER GRATE COVER GREASING TUBES STRAW CHOPPER, GREASING CHOPPER DRIVE CHOPPER DRIVE, SHAFT PULLEYS CHOPPER DRIVE CHOPPER DRIVE, SHIELDS CHOPPER READY DRIVE CHOPPER READY DRIVE, SHAFT PULLEYS STRAWHOOD CONVEYOR MOUNTING PLATES CHOPPER DRIVE, SHAFT PULLEYS DOOR, SWATH KICKBACK, PSD SUPPORT, STRAW CHOPPER WITH PSD STRAW CHOPPER WITH ROLLER STRAW CHOPPER WITH ROLLER, ROLLER SUPPORT, STRAW CHOPPER READY STRAWHOOD CHOPPER, ROTOR FRAME CHOPPER, ROTOR FRAME TAILINGS ELEVATORS, SELF-LEVELING DRIVE - LH TAILINGS ELEVATORS, BOTTOM AUGER RH DRIVE SHAKER SHOE DRIVE - SELF-LEVELLING SHAKER SHOE DRIVE, GEARBOX - SELF-LEVELLING SHAKER SHOE DRIVE, POWER TAKE -OFF - SELF-LEVELLING SHAKER SHOE DRIVE, GEARBOX - SELF-LEVELLING GRAINPAN SIDE SLOPE FOR CORN GRAIN PAN SHAKER SHOE GRAEPEL SIEVE EXTENSION REMOTE CHAFFER ADJUSTMENT, UPPER SIEVE, 1 1/8dm REMOTE CHAFFER ADJUSTMENT, UPPER SIEVE, 1 5/8dm PRE-SIEVES UPPER SIEVES - CLOSZ 1 5/8dm UPPER SIEVES - PETTERSON 1 1/8dm UPPER SIEVES - CORN 1 5/8dm UPPER SIEVES - CLOSZ 1 1/8dm REMOTE CHAFFER ADJUSTMENT, LOWER SIEVE LOWER SHAKER SHOE, AGRESSIVE SHAKE LOWER SIEVES - 1 5/8dm LOWER SIEVES - 1 1/8dm, (Prod Date) before 09-DEC-2012 SIEVE, AIR DAM ECCENTRIC AND SHAKER SHOE GRAIN PAN, SUPPORTS GRAIN PAN, SUPPORTS SHAKER SHOE SHAKER SHOE SHAKER SHOE AUGER HOUSING - SELF-LEVELLING AUGER HOUSING - SELF-LEVELLING CLEANING SHOE FAN GUARD FAN, FRAME FAN, BLOWER FAN, GUIDE FIXATION, OPTI-SPREAD FIXATION, OPTI-SPREAD WIDE SPREADER HOOD AND COVER, OPTI-SPREAD WIDE SPREADER COVER, OPTI-SPREAD DISC ASSEMBLY, OPTI-SPREAD NARROW SPREADER DEFLECTORS, OPTI-SPREAD NARROW SPREADER DEFLECTOR SUPPORTS, OPTI-SPREAD WIDE SPREADER DEFLECTORS, OPTI-SPREAD™, (Prod Date) before 31-JAN-2014 WIDE SPREADER DEFLECTOR SUPPORTS, OPTI-SPREAD™, (Prod Date) before 31-JAN-2014 SIEVE LOSS-PROTECTION PLATE FIXATION, SPREADER HOOD WIDE SPREADER HOOD REMOTE CONTROL WIDE STRAW GUIDINGPLATE WIDE STRAW GUIDINGPLATE BUMPERS AND RAKES FRAME AND LH MOUNTING, WIDE CHAFF SPREADER RH MOUNTING, WIDE CHAFF SPREADER DISC ASSEMBLY MOUNTING, CHAFF SPREADER DISC ASSEMBLY, CHAFF SPREADER DEFLECTOR CORN KIT, WIDE CHAFF SPREADER DEFLECTOR CORN KIT, WIDE CHAFF SPREADER HYDRAULIC FAN DRIVE TAILINGS ELEVATORS, BOTTOM AUGER TO RH DRIVE TAILINGS ELEVATOR, LH TAILINGS ELEVATOR, RH TAILINGS ELEVATOR, BOTTOM AUGER BEATER, RH TAILINGS ELEVATOR, BOTTOM AUGER BEATER, LH TAILINGS ELEVATOR, GEARBOX, RH TAILINGS ELEVATOR, GEARBOX, LH TAILINGS ELEVATOR, DEFLECTORS GRAIN ELEVATOR, DRIVE GRAIN ELEVATOR, BOTTOM AUGER GRAIN ELEVATOR GRAIN ELEVATOR CHAIN, DRIVE GRAIN ELEVATOR CHAIN BUBBLE-UP, DRIVE BUBBLE-UP, GEARBOX BUBBLE-UP GRAIN ELEVATOR HEAD GRAIN ELEVATOR HEAD, WEAR PLATES GRAIN ELEVATOR HEAD, DRIVE GRAIN ELEVATOR DRIVE GRAIN ELEVATOR DRIVE, PIVOT GRAIN FLOW YIELD SENSOR NO MOISTURE SENSOR COVER GRAINTANK, RH GRAINTANK, MIDDLE GRAINTANK, LH GRAINTANK BOTTOM GRAINTANK CROSS AUGERS GRAINTANK FLOOR GRAINTANK EXTENSIONS GRAINTANK EXTENSION HINGES GRAINTANK COVERS, PIVOTING SYSTEM GRAINTANK COVER SIDE PANELS GRAINTANK COVERS GRAINTANK EXTENSION, CANVAS UNLOADING AUGER, DRIVE UNLOADING AUGER, DRIVE, CHAIN UNLOADING AUGER, GEARBOX GRAIN DISCHARGE, UPPER GEARBOX UNLOADING AUGER, FOR HEAVY DUTY UNLOADING AUGER, EXTENSION 1.3 M UNLOADING AUGER UNLOADING AUGER, CANVAS UNLOADING AUGER, SPOUT DIA KIT: FIRE EXTINGUISHER DIA KIT: HEADER LIFT CYLINDER KIT DIA KIT: HEADER LIFT CYLINDER KIT DIA KIT: HEADER LIFT CYLINDER KIT DIA KIT: HEADER LIFT CYLINDER KIT DIA KIT: NAVIGATION II CONTROLLER DIA KIT: FEEDER DRUM STOP KIT DIA KIT: SMOOTH RETHRESHING COVERS DIA KIT: REINFORCED UNLOADING TUBE EXTENSION KIT, 4.4FT DIA KIT, CR DIA TRACK COMPLETING DIA KIT: STEERING PLATFORM EXTENSION - 500MM AIR DEFLECTOR PLATE ENGINE GUARDS, PLATE ENGINE GUARDS, HOOD ENGINE GUARDS, FRAME DOOR LOCK SHIELD, LH SHIELD, RH SHIELD, LH SHIELD, LH SHIELD, RH SHIELD, RH FRONT SHIELDS MAIN SHIELD, SAFETY LOCK SHIELD STONE ROLL, LH SHIELD STONE ROLL, RH CR TRACK COMPLETING BATTERY, TRAY SHIELDS, REAR SHIELD LH SHIELD LH SHIELD LH SHIELD RH SHIELD RH LOWER SHIELDS SUPPORT FOR TRACKS SAFETY AND INSTRUCTION DECALS SAFETY AND INSTRUCTION DECALS SAFETY AND INSTRUCTION DECALS SAFETY AND INSTRUCTION DECALS COMMERCIAL DECALS SAFETY AND INSTRUCTION DECALS DECALS, NA FRENCH MONITOR SUPPORT PROTECTION FOR OPTI-SPREAD, (Prod Date) before 20-APR-2012 PROTECTION FOR CHOPPER, (Prod Date) before 21-NOV-2011 FENDERS CAB FRAME OPERATORS PLATFORM OPERATORS PLATFORM OPERATORS PLATFORM, LADDER REAR DECK LADDER REAR DECK RAILING REAR DECK ASSEMBLY ENGINE GUARDS, LADDER SHIELD LH SHIELD LH SHIELD RH PLATFORM EXTENSIONS, 250 MM PLATFORM EXTENSIONS, 500 MM PLATFORM EXTENSIONS, 750 MM STEP, RH OPERATORS SEAT BUDDY SEAT INSTRUCTORS SEAT OPERATORS SEAT OPERATORS SEAT OPERATORS SEAT OPERATORS SEAT OPERATORS SEAT OPERATORS SEAT OPERATORS SEAT OPERATORS SEAT CAB FRAME MOUNTING CAB FRAME DOOR, LH DOOR, RH CAB ROOF, OUTER WINDSHIELD GLASS CAB ROOF, INNER INTERIOR PADDING FOOTBOARD MAT OPERATORS SEAT, SUPPORT REAR PANEL REAR PANEL, LOWER STORAGE BOXES BRACKET

1

2

2

2

3

3

3

4

Позиция на иллюстрации	Заводской номер детали		Название детали
1	84484003		Support
2	140045		Belleville washer
3	43138		BOLT
4	84483986		Shield

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
