Каталог запасных частей к технике: Massey Ferguson MF-7244 Activa. Cutter Bar Lifting Additional Ram

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано AGCO Amity CASE IH DongFeng Fortschritt Foton Franz Kleine Gaspardo Great Plains KRONE KUHN Lemken Lovol MacDon Massey Ferguson New Holland TIGARBO Vaderstad Versatile Wirax Агро Агротехмаш Бобруйскагромаш (ОАО «УКХ «Бобруйскагромаш») БЭМЗ ВгТЗ Воронежсельмаш ВТЗ Гомсельмаш ДКЗ ЗАО "Техника-сервис" ЗиД КЗК Кировец-Ландтехник Клевер Красная Звезда Лидагропроммаш Лидсельмаш ЛТЗ Машстройхолдинг Минитракторы Мордовагромаш МТЗ Навигатор-Новое машиностроение Нефтекамский автозавод ПТЗ Ремком РСМ Сибсельмаш ТеКЗ ТКЗ ХЗТСШ ХТЗ ЮМЗ

Модель Не выбрано Fend-8300/8350 (2007) MF-7244 Activa (2012) MF-8650 Dyna-VT (2012)

Схема > Не выбрано Engine Cylinder Head Cover Intake Manifold Exhaust Manifold Nozzles Injection Pump Assy Fuel Filter-Up 551510030 Fuel Filter-From Serial Namber 551510031 Accumulator Hydraulic-Up To 551510030 Accumulator Hydraulic-From Serial Namber 551510031 Fuel Filter-Up To 551510030 Fuel Filter-From Serial Namber 551510031 Fuel Lines Fuel Lines Fuel Lines Lube Oil Lines Turbocharger-Up To 551510030 Turbocharger-From Serial Namber 551510031 Oil Dipstick Oil Filters Watr Pump Thermostat Engine Breathers Starter Motor Alternator Cables Cables-From Serial Namber 551510031 Belt Electronic Control Unit Engine Installation-Up To 551510030 Engine Installation-From Serial Namber 551510031 Engine Installation Engine Installation-Holder Engine Installation Engine Installation-Blower Engine Installation Engine Air Cleaner Exhaust Silencer Fuel Tank-Up To 551510026 Fuel Tank-From Serial Namber 551510027 Fuel Tank-Holder Radiator Filter Radiator Filter Radiator Filter Radiator Filter Radiator Filter-Up to 551510026 Radiator Filter-From Serial Namber 551510031 Radiator Filter Radiator Filter Radiator Filter Radiator Filter Radiator Filter Radiator Elements Filter Transmission Radiator Power Take Power Take Radiator Filter Intake Front Axle Front Axle Rear Axle-4 WD-Hydraulic Lines Rear Axle-4 WD Rear Axle-4 WD-Final Drive Rear Axle-4 WD-Valve Rear Axle-4 WD-Hydraulic Cylinder Rear Axle Support Rear Axle-Adjustable Rear Axle-Adjustable Rear Axle-Adjustable Reducers Shift Levers Shift Levers Brakes Brakes Pump Elements And Brake Compensation Valve Brakes Elements Parking Brake Part Number Qty Description Number Qty Description Tow Hook Tow Hook Chassis Crawler Tracks-6 Rollers Chassis Crawler Tracks-6 Rollers Chassis Crawler Tracks-6 Rollers Chassis Crawler Tracks-6 Rollers Chassis Crawler Tracks-6 Rollers Chassis Crawler Tracks-6 Rollers-Up To 551510026 Chassis Crawler Tracks-6 Rollers-From Serial Number 551510027 Rollers Elements And Idler Wheels Chain Elements Chassis Crawler Tracks-7 Rollers Chassis Crawler Tracks-7 Rollers Chassis Crawler Tracks-7 Rollers Chassis Crawler Tracks-7 Rollers Chassis Crawler Tracks-7 Rollers Chassis Crawler Tracks-7 Rollers-Up To 551510026 Chassis Crawler Tracks-7 Rollers-From Serial Number 5515100272 Hydrostatic Pump Hydrostatic Pump Hydrostatic Pump Elements Pump Drive Pump Drive Gear Box Gear Box Gear Box Gear Box Hydrostatic Motor Hydrostatic Motor Elements Oil Tank-Up To 2008 Oil Tank-From 2008 Oil Tank-Up To 551510030 Oil Tank-From Serial Number 551510031 Valve Chest-From Serial Number 551510031 Multifunction Lever For Hydrostatic Transmission Multifunction Lever For Hydrostatic Transmission Multifunction Lever For Hydrostatic Transmission Elevator Transmission Front Elevator Front Elevator-Control Pulley Front Elevator-Upper Shaft Front Elevator-Lower Roller Front Elevator Standard-Transmission Front Elevator Standard-Guard Front Elevator-Lower Shaft Front Elevator Standard Front Elevator-Roller, Chain, Beater Bar Front Elevator Integral-Overhang Front Elevator Cutter Bar Levelling System Cutter Bar Lifting-Up To 551510048 Cutter Bar Lifting-From No 551510049 Cutter Bar Lifting Cutter Bar Lifting Reverser Reverser Frame Drum Housing Drum Housing Drum Housing Drum Variator-Up To 551510030 Drum Variator-From Serial Number 551510031 Drum With Bars Peg Drum Beater Behind Drum Concave Control Drive-Up To 551510048 Concave Control Drive-From No 551510049 Concave Control Drive Concave Spike Tooth Concave-Rice Spike Tooth Concave-Rice Concave, Corn, Mixed Crop-Up To 551510026 Concave for Maize and Sun Flower-From Serial Number 551510027 Concave, Corn, Mixed Crop Conveying Concave Conveying Concave Thresing Mechanism Drive Without Multi Crop Separator Straw Walkers Case Straw Walkers Case Rear Body Rear Body Straw Walker Parts For Normals Soils Parts For Normals Soils Straw Walker Drive Straw Walker Drive Swather Rake Straw Chopper-Transmission Straw Chopper-Transmission Straw Chopper-Transmission Straw Chopper-Drive Clutch Straw Chopper-Drive Guard Straw Chopper-Supports Straw Chopper-Supports Straw Chopper-BODY STIFFENER Straw Chopper-ELECTRIC SYSTEM Straw Chopper-Supports Straw Chopper-Chassis Straw Chopper-Chassis Straw Chopper-CHOPPER DRUM Straw Chopper-Spreader Housing Straw Chopper-DEFLECTORS Straw Chopper-DEFLECTORS Straw Chopper-STRAW CHOPPER EXCLUSION DEVICE Grain Pan Grain Pan Drive Вrain Pan Drive Shaker Shoe Shaker Shoe-Belt Tensioner Shaker Shoe Lower Shaker Shoe Lower Shaker Shoe Jpper Shaker Shoe Grain Elevator-NORMAL Grain Elevator-NORMAL Grain Elevator-NORMAL Grain Elevator-NORMAL Tailings Elevator-NORMAL Tailings Elevator-NORMAL Tailings Elevator-NORMAL Tailings Elevator-NORMAL Tailings Elevator-NORMAL Fan-Up To 551510026 Fan-From Serial Number 551510027 Fan Fan Fan Variator Fan Variator Elements Grain Elevator Anthwear-Chassis Grain Elevator Anthwear Grain Elevator Anthwear-CHAIN Grain Elevator Anthwear-UPPER TRANSMISSION Tailings Elevator Anthwear-Chassis Tailings Elevator Anthwear Tailings Elevator Anthwear-CHAIN Tailings Elevator Anthwear Tailings Elevator Anthwear-AUGER Item Part Number Fan Speed Variator Electric Digital Control Upper Sieve, Adjustable Lower Sieve Grain Tank Grain Tank Grain Tank Retractable Grain Tank Extension Retractable Grain Tank Extension Tank Feed Tank Feed Tank Feed Case Elements Grain Tank Unloading Auger Grain Tank Unloading Vertical Tube Grain Tank Unloading Vertical Tube Grain Tank Unloading Vertical Tube Grain Tank Unloading Vertical Tube Grain Tank Unloading Vertical Tube Lower Case Elements Upper Case Elements Drive And Unloading Tank Clutch Drive And Unloading Tank Clutch Drive And Unloading Tank Clutch Item Part Number Qty Swing-Type Control Ram And Piping-Up To 551510030 Swing-Type Control Ram And Piping-From Serial Number 551510031 Swivel Body, Right Side Body, Right Side Body, Right Side Body, Right Side Body, Left Side Engine Cover-Supports Engine Cover Engine Access Ladder R.H. Side Wall Guard R.H. Side Wall Guard-Up To 551510026 R.H. Side Wall Guard-From Serial Number 551510027 L.H. Side Wall Guard -Up To 551510026 L.H. Side Wall Guard-From Serial Number 551510027 Body, Right Side L.H. Side Wall Guard R.H. Side Wall Guard L.H. Side Wall Guard Platform Support Platform Support-Up To 551510048 Platform Support-From No 551510049 Driver's Platform-Up To 551510048 Driver'S Platform-From No 551510049 Driver's Platform-Up To 551510048 Driver'S Platform-From No 551510049 Ladder Footboard-Up To 551510026 Ladder Footboard-From Serial Number 551510027 Ladder Footboard-From Serial Number 551510027 Ladder Footboard-Up To 551510026 Ladder Footboard-From Serial Number 551510027 Platform Footboards-Left Side-Up To 551510048 Platform Footboards-Left Side-From No 551510049 Platform Footboards-Right Side-Up To 551510048 Platform Footboards-Right Side-From No 551510049 Cab-MAIN SEAT-Up To 551510048 Cab-MAIN SEAT-From Serial Number 551510049 Cab-Installation-Up To 551510048 Cab-Installation-From No 551510049 Cab-Installation-Up To 551510048 Cab-Installation-From No 551510049 Cab-Installation Cab-Climatized Cab-Up To 551510048 Cab-Climatized Cab-From No 551510049 Cab-Climatized Cab Cab-Roof Cab-LEFT DOOR Cab-Right Door Cab-Framing-Up To 551510048 Cab-Framing-From No 551510049 Cab-Framing Cab-Under Roof-Up To 551510048 Cab-Under Roof-From No 551510049 Cab-Headlight Cab-Up To 551510048 Cab-UNICONTROL Cab-AIR CONDITIONER-Up To 551510048 Cab-AIR CONDITIONER-From No 551510049 Cab-AIR CONDITIONER-Up To 551510048 Cab-AIR CONDITIONER-From No 551510049 Cab-AIR CONDITIONER Cab-AIR CONDITIONER Cab-REAR VIEW MIRRORS Ladder Footboard-Extention Up To 551510026 Ladder Footboard-Extention From Serial Number 551510027 Cab-STEERING COLUMN-Up To 551510048 Cab-STEERING COLUMN-From No 551510049 Cab-STEERING COLUMN-Up To 551510048 Cab-STEERING COLUMN-From No 551510049 Concave Control Drive Hydraulic Pump-Up To 551510030 Hydraulic Pump-From Serial Number 551510031 Valve Chest-Up To 551510030 Valve-Chest Elements-Up To 551510030 Valve-Chest Elements-Up To 551510030 Valve Chest-From Serial Number 551510031, Up To 551510048 Valve Chest-From No 551510049 Valve-Chest Elements-From Serial Number 551510031, Up To 551510048 Valve-Chest Elements-From No 551510049 Reel Circuit Hydraulic -Up To 551510030 Reel Circuit Hydraulic-From Serial Number 551510031, Up To 551510048 Reel Circuit Hydraulic-From No 551510049 Reel Circuit Hydraulic-Up To 551510048 Reel Circuit Hydraulic-From No 551510049 Drive Hydraulic Circuit Drive Hydraulic Circuit Connections For Hydraulics Pipes Straw Chopper-Transmission-Up To 551510030 Straw Chopper-Transmission-From Serial Number 551510031 Front Lighting Components Rear Lighting Components Electric System-Control Circuits Electric System-Control Circuits Electric System-Control Circuits Electric System-Control Circuits Electric System-Control Circuits Electric System-Control Circuits Electric System-Control Circuits Electric System-Control Circuits Starting Circuits Starting Circuits Valve-Chest Control Circuits-Up To 551510030 Valve-Chest Control Circuits-From Serial Number 551510031 Valve-Chest Control Circuits Valve-Chest Control Circuits-Up To 551510030 Item Valve-Chest Control Circuits-From Serial Number 551510031 Digital Instrumentation-Up To 551510048 Digital Instrumentation-Up To 551510048 Digital Instrumentation-From No 551510049 Beacon Light With Cab Operations Control Monitor Auxiliary Light Battery Disengaging Device Battery Auxiliary Light Tool Box Number Plate Holder Extinguisher Support Tool Box Support Decals Decals Decals Decals Decals Decals Straw-Lifter Rider Elevator Cleaning Blades Variations and Accessories Variations and Accessories Variations and Accessories Variations and Accessories Variations and Accessories Variations and Accessories-AUTOLEVEL TABLE KIT Czeh Republic Version Equipment, Denmark-Sweden Version Front Elevator-Guard Germany Version Wheels Block Switzerland Version Front Axle Spacer (Mm. 250) Rasp-Bar Concave Rasp-Bar Concave Electrical Adjustment Deflectors Electrical Adjustment Deflectors Parts For Sandy Soils Upper Sieve, Adjustable-Corn Front Elevator Support Kit Cutter Bar Levelling System-Up To 551510030 Cutter Bar Levelling System-From Serial Number 551510031 Cutter Bar Levelling System Cutting Table Block Quick Release Coupling Excluding Device For Additional Cilinder Of Cutt. Tool Box Additional Electric System Fuel Filter Fuel Filter-10 Micron Muddy Soil Guards Chaff Spreader-Transmission Chaff Spreader-Bracket-Right Side Chaff Spreader-LEFT SIDE SUPPORTS Chaff Spreader-Chassis Chaff Spreader-Guard Canvas Chain Drive For Ballast Weight On Rear Axle-4WD Ballast Weight On Rear Axle-Up To-2007-03-01 Ballast Weight On Rear Axle-From-2007-03-01 Rear Wheel Weight Ballast Weight On Rear Body Ballast Weight On Rear Body Spike Tooth Concave With 2 Complete Thresing Section Supplement Beater, Corn, Mixed Crop Concave, Corn, Mixed Crop Concave, Corn, Mixed Crop Upper Sieve, Corn, Cob, Mixed Crop Drum Bar Plates Equipment For Small Seeds Equipment For Soy Cutter Bar Lifting Additional Ram Rear Wheels Front Wheels

1

2

3

4

5

6

7

8

9

10

11

11

12

13

Позиция на иллюстрации	Заводской номер детали		Название детали
LA322543700	LA322543700		Ram
1	LA11112821		Cap Screw
2	LA11118521		Screw
3	LA11702921		Nut
4	LA12034771		Lock Washer
5	LA12034871		Lock Washer
6	LA12163311		Nut
7	LA321421850		Hydraulic Hose
8	LA322776550		Plate
9	LA321875100		Union
10	LA322003950		Bracket
11	LA322005550		Pin
12	LA322308350		Valve
13	LA322546100		Hydraulic, Cylin
14	LA322546300		Kit, Seal
14	LA322543900		Kit, Seal

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
