Каталог запасных частей к технике: Massey Ferguson Fend-8300/8350. Prop. Pump And Hydr. Pump

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
7
8
9
9
10
11
12
13
14
15
15
16
17
18
19
20
21
22
23
23
24
24
24
25
27
28
29
30
31
32
33
34
35
36
36
37
37
38
39
40
41
42
43
44
46
47
60
61
62
63
64
65
66
67
68
69
70
71
72
75
77
78
79
81
82
83
84
85
86
87
88
89
90
91
92
92
93
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
109
112
113
114
Позиция на иллюстрации Заводской номер детали Название детали
1 D45166900 PUMP
2 D45239900 CONNECTOR
3 D28786485 CONNECTOR
4 D45251500 UNION
5 D45250700 UNION
6 D45264100 UNION
7 339199X1 CIRCLIP
8 D28780900 PULLEY
9 SKF62042RS BEAR. 6204 2RS
10 D28780007 RING
11 D42621900 PIN
12 D28780008 BOLT
13 D28380003 RING
14 D28782527 ARM
15 D28780777 ECCENTRIC
16 D28780776 SPACER
17 D45744200 FERRULE
18 D28787403 ARM
19 D28780195 SPINDLE
20 D28787998 PIPE
21 D28210881 COMP.SPRING
22 D41100900 SPRING WASHER
23 D20400423 FLAT WASHER
24 3009695X1 Nut
25 D28787247 SUPPORT
27 1442739X1 Locknut
28 D20400459 WASHER
29 D45272200 UNION
30 D45736700 SUPPORT
31 D28250656 ARM
32 D41990045 BELT
33 D45730400 CLAMP
34 D20400437 WASHER
35 D28787079 PLATE
36 338616X1 Hose Clip
37 D28781312 BRACKET
38 D45169900 PUMP
39 D28780058 PULLEY
40 D28787077 COVER
41 D44740800 STRIP
42 D41102100 WASHER
43 D45463600 O-RING
44 D40692500 SCREW
46 D40690400 SCREW
47 D28786783 SUPPORT
60 D45103000 FILTER
61 D45165800 RETURN FL.FILTER
62 D45165900 FILTER
63 D28781818 PLATE
64 D28781819 KIT, SEAL
65 D28787072 BOTTOM
66 D45080021 DIPSTICK
67 D44900617 SENSOR
68 D45201600 PACKING
69 D28780947 WASHER
70 D46422300 COCK
71 3000483X1 Hose Clip
72 D28782176 HOSE
75 D28786449 SUCTION HOSE
77 D28786818 UNION
78 D28885052 UNION
79 D28782310 HOSE
81 D20400426 WASHER
82 D40693800 SCREW
83 D40418500 HEX. SOCK. SCREW
84 D43367400 BUSH
85 D28781123 PULLEY
86 339269X1 HEX. SOCK. SCREW
87 D28780603 TENSIONER
88 D46446700 ALTERNATOR
89 D41904200 BELT
90 D41092500 NUT
91 339761X1 Hex Cap Screw
92 D20400506 WASHER
93 394367X1 Locknut
94 D40425100 SCREW
95 D28760642 EARTH STRAP
96 D28780002 FITTING
97 D28780001 FITTING
98 3009493X1 Hex Cap Screw
99 D20400471 WASHER
100 1440329X1 Locknut
101 394367X1 Locknut
102 D46480900 BUFFER
103 D40749100 SCREW METRIC
104 D45715300 WASHER
105 D45715100 WASHER
106 D45145800 SEAL
107 D45103100 GASKET
108 3009509X1 Hex Cap Screw
109 D45166800 KIT, SEAL
112 D40693800 SCREW
113 D20400426 WASHER
114 D44744800 PROFILE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
