Каталог запасных частей к технике: MacDon-PW7. ELECTRICAL - LIGHTING
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
16
17
18
19
20
20
21
21
22
23
24
25
26
27
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 182937 | 182937 | CASE RED | |
| 190119 | 190119 | WIRE HARNESS | |
| 182184 | 182184 | WIRE HARNESS | |
| 182356 | 182356 | WIRE HARNESS | |
| 182137 | 182137 | WIRE HARNESS | |
| 182170 | 182170 | WIRE HARNESS | |
| 182090 | 182090 | WIRE HARNESS | |
| 182161 | 182161 | WIRE HARNESS | |
| 182043 | 182043 | WIRE HARNESS | |
| 190640 | 190640 | AGCO GRAY | |
| 190638 | 190638 | GREEN | |
| 182938 | 182938 | NH YELLOW | |
| 190744 | 190744 | BLACK | |
| 190650 | 190650 | AGCO GRAY | |
| 190073 | 190073 | GREEN | |
| 190072 | 190072 | NH YELLOW | |
| 182964 | 182964 | CASE RED - 2015 | |
| 190071 | 190071 | CASE RED - 2016 | |
| 190070 | 190070 | BLACK | |
| 190061 | 190061 | BLACK | |
| 190062 | 190062 | CASE RED - 2016 | |
| 182963 | 182963 | CASE RED - 2015 | |
| 190063 | 190063 | NH YELLOW | |
| 190064 | 190064 | GREEN | |
| BRACKET | BRACKET | BRACKET | |
| 190649 | 190649 | AGCO GRAY | |
| 1 | 182078 | LAMP ASSEMBLY | |
| 2 | BRACKET | BRACKET | |
| 3 | SHIELD | SHIELD | |
| 4 | 184344 | U-BOLT | |
| 5 | 184708 | WASHER | |
| 6 | 30716 | WASHER - LOCK SPRING (M8) | |
| 7 | 184687 | NUT | |
| 8 | 191121 | LENS | |
| 9 | 184683 | NUT | |
| 10 | 184705 | WASHER | |
| 11 | 184642 | BOLT | |
| 12 | 191123 | BULB | |
| 13 | 115147 | REFLECTOR-RED | |
| 14 | 115146 | ОТРАЖАТЕЛЬ | |
| 15 | 115145 | REFLECTOR - FLRSCNT RED-ORANGE | |
| 16 | 182189 | WIRE HARNESS | |
| 17 | 184301 | CLAMP | |
| 18 | 30631 | WASHER | |
| 19 | 184306 | CLAMP | |
| 20 | 135267 | SNAP RING | |
| 21 | COUPLER | COUPLER | |
| 22 | 133277 | CAP | |
| 23 | 184640 | BOLT HEX HD | |
| 24 | 184682 | NUT | |
| 25 | 184703 | WASHER | |
| 26 | 184701 | WASHER | |
| 27 | 182190 | ADAPTER |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
