HEADER DRIVE PULLEY
Каталог запасных частей к технике: MacDon-9250. HEADER DRIVE PULLEY
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
AGCO
Amity
CASE IH
DongFeng
Fortschritt
Foton
Franz Kleine
Gaspardo
Great Plains
KRONE
KUHN
Lemken
Lovol
MacDon
Massey Ferguson
New Holland
TIGARBO
Vaderstad
Versatile
Wirax
Агро
Агротехмаш
Бобруйскагромаш (ОАО «УКХ «Бобруйскагромаш»)
БЭМЗ
ВгТЗ
Воронежсельмаш
ВТЗ
Гомсельмаш
ДКЗ
ЗАО "Техника-сервис"
ЗиД
КЗК
Кировец-Ландтехник
Клевер
Красная Звезда
Лидагропроммаш
Лидсельмаш
ЛТЗ
Машстройхолдинг
Минитракторы
Мордовагромаш
МТЗ
Навигатор-Новое машиностроение
Нефтекамский автозавод
ПТЗ
Ремком
РСМ
Сибсельмаш
ТеКЗ
ТКЗ
ХЗТСШ
ХТЗ
ЮМЗ
Модель
Не выбрано
MacDon-9250 (2010)
MacDon-CA25 (2016)
MacDon-D50/D60/FD70 (2010)
MacDon-D65 (2016)
MacDon-FD75 (2019)
MacDon-M100 (2008)
MacDon-M105 (2011)
MacDon-M155 (2010)
MacDon-PW7 (2010)
Model 972 HARVEST HEADER (2019)
М 215908 B
Схема
>
Не выбрано
CAB FRAME, SEALS, GROMMETS AND MOUNTS
CAB UPHOLSTERY AND INSULATORS
CAB DOOR AND CAB RIGHT SIDE PANEL
CAB ROOF
WINDOWS
FOOTREST AND SIDE CONSOLE PANEL
STEERING COLUMN
INSTRUMENT PANEL
SIDE CONSOLE
REEL AND CONVEYOR SPEED CONTROL
GROUND SPEED LEVER
THROTTLE CONTROL – CUMMINS ENGINE TRACTORS
THROTTLE CONTROL – ISUZU ENGINE TRACTORS
CAB ELECTRICAL AND WIPER
CAB SEATS
CAB AIR CONDITIONING AND BLOWER GROUP
AIR CONDITIONING - ENGINE GROUP
HEATER – CUMMINS ENGINE TRACTOR
HEATER – ISUZU ENGINE TRACTOR
MAIN FRAME AND COVERS
LIFT LINKAGE
WALKING BEAM AND PIVOT
REAR WEIGHT PACKAGE
TRACTOR ELECTRICAL
ENGINE ASSEMBLY – CUMMINS ENGINE TRACTOR UNITS
ENGINE ASSEMBLY – ISUZU ENGINE TRACTOR UNITS
ALTERNATOR MOUNTING– CUMMINS ENGINE TRACTOR UNITS
ENGINE SUPERSTRUCTURE
FUEL SYSTEM
ENGINE AIR INTAKE – CUMMINS ENGINE TRACTOR UNITS
ENGINE AIR INTAKE – ISUZU ENGINE TRACTOR UNITS AND CUMMINS TRACTOR UNITS SN 17461 and ABOVE
ENGINE COOLING CUMMINS ENGINE TRACTOR UNITS
AIR INTAKE SCREEN CLEANER
HEADER DRIVE
Header Drive - BEVEL GEARBOX
Header Drive - BEVEL GEARBOX 22 Production and up
DRIVELINE (Engine to Bevel Gearbox)
HEADER DRIVE PULLEY
DRIVELINE SERIAL NUMBER 13824 and below
DRIVELINE SERIAL NUMBER 13825 and above
NEUTRAL INTERLOCK AND PINTLE ARMS
STEERING AND GROUND SPEED
HYDRAULICS: HEADER DRIVE
HYDRAULICS: CYLINDER CONTROL
Header Lift Cylinder 3.0" BORE SEAL KIT
Header Lift Cylinder 2.5" BORE SEAL KIT
HYDRAULICS: TRACTION DRIVE
HYDRAULICS: TRIPLE PUMP
HYDRAULICS: DOUBLE GEAR PUMP
HYDRAULICS: TWO-SPEED WHEEL MOTOR
TWO SPEED DRIVE: WHEEL MOTOR ASSEMBLY
HYDRAULICS: SINGLE SPEED WHEEL MOTOR
SINGLE SPEED DRIVE: WHEEL MOTOR ASSEMBLY
MODEL 6 POWER WHEEL SINGLE SPEED UNITS
MODEL 7 POWER WHEEL 935/495/295/815 TWO-SPEED UNITS
MODEL 8B POWER WHEEL 9352/4952/2952/8152 TWO-SPEED UNITS
MODEL RR POWER HUB 9352i/9352c, 4952i/4952c, 2952i/2952c, 8152i/8152c TWO-SPEED UNITS
DRIVE WHEELS AND TIRES
BRAKE ASSEMBLY – CUMMINS ENGINE TRACTORS (except xx52c models)
BRAKE ASSEMBLY – XX52i AND XX52c TRACTORS
925/935, 494/495, 294/295, 814/815 TRACTOR 16.5 FORKED CASTERS
925/935, 494/495, 294/295, 814/815 TRACTOR 9.5 FORKED CASTERS
925/935, 494/495, 294/295, 814/815 TRACTOR FORMED CASTERS
9352/4952/2952/8152 (INCLUDING “i” AND “c” MODEL) TRACTORS FORKED CASTERS
9352/4952/2952/8152 (INCLUDING “i” AND “c” MODEL) TRACTORS FORMED CASTERS
SAFETY DECALS
INFORMATION DECALS AND REFLECTORS
PRODUCT IDENTIFICATION DECALS
OPTIONAL HYDRAULICS – HEADER ANGLE KIT
OPTIONAL HYDRAULICS – FORE/AFT KIT
VALVE MANIFOLDS
1
2
2
3
4
5
5
6
7
8
9
10
A
C
Позиция на иллюстрации
Заводской номер детали
Название детали
1
44360
PULLEY
2
7900
МАНЖЕТА
3
21545
RING
4
44240
SUPPORT
5
7910
SPACER
6
21540
WASHER - HARDENED
7
5512
ГАЙКА
8
18605
ШПИЛЬКА
9
18671
FITTING- LUBE 1/4-28 UNF
10
111169
SUPPORT
A
20077
BOLT - HEX HD 3/8 NC X 10 LG GR 5 ZP
C
18637
WASHER - REG LOCK 3/8 IN NOM ID ZP
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
