TS04433010000 BRAKE SYSTEM CONTROL ASSEMBLY-1
Каталог запасных частей к технике: Lovol TS-4A504-038K. TS04433010000 BRAKE SYSTEM CONTROL ASSEMBLY-1
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
AGCO
Amity
CASE IH
DongFeng
Fortschritt
Foton
Franz Kleine
Gaspardo
Great Plains
KRONE
KUHN
Lemken
Lovol
MacDon
Massey Ferguson
New Holland
TIGARBO
Vaderstad
Versatile
Wirax
Агро
Агротехмаш
Бобруйскагромаш (ОАО «УКХ «Бобруйскагромаш»)
БЭМЗ
ВгТЗ
Воронежсельмаш
ВТЗ
Гомсельмаш
ДКЗ
ЗАО "Техника-сервис"
ЗиД
КЗК
Кировец-Ландтехник
Клевер
Красная Звезда
Лидагропроммаш
Лидсельмаш
ЛТЗ
Машстройхолдинг
Минитракторы
Мордовагромаш
МТЗ
Навигатор-Новое машиностроение
Нефтекамский автозавод
ПТЗ
Ремком
РСМ
Сибсельмаш
ТеКЗ
ТКЗ
ХЗТСШ
ХТЗ
ЮМЗ
Модель
Не выбрано
TB-604
TD-1304
TD-904
TE-354
TE-404
TS-4A504-038K
Схема
>
Не выбрано
A498BT-38H ENGINE ASSY-1
A498BT-38H ENGINE ASSY-2 (CRANKSHAFT, FLYWHEEL)
A498BT-38H ENGINE ASSY-3 (PISTON RING)
A498BT-38H ENGINE ASSY-4 (CAMSHAFT)
A498BT-38H ENGINE ASSY-5 (AIR)
A498BT-38H ENGINE ASSY-6 (HYDRAULIC PUMP)
A498BT-38H ENGINE ASSY-7 (FLYWHEEL HOUSING)
A498BT-38H ENGINE ASSY-8 (OIL INJECTION PUMP)
A498BT-38H ENGINE ASSY-9 (FAN, WATER PUMP)
A498BT-38H ENGINE ASSY-10 (GENERATOR)
A498BT-38H ENGINE ASSY-11 (MAIN OIL SUMP)
A498BT-38H ENGINE ASSY-12 (OIL PUMP)
A498BT-38H ENGINE ASSY-13 (ENGINE HEAD)
A498BT-38H ENGINE ASSY-14 (CYLINDER COVER)
A498BT-38H ENGINE ASSY-15 (THERMOSTAT)
A498BT-38H ENGINE ASSY-16 (AIR INLET PIPE)
A498BT-38H ENGINE ASSY-17 (EXHAUST PIPE)
A498BT-38H ENGINE ASSY-18 (OIL FILTER)
FT500A.11.001 AIR FILTER SYSTEM ASSEMBLY
TC02131080000K COOLING SYSTEM ASSEMBLY-1
TC02131080000K COOLING SYSTEM ASSEMBLY-2
TS04132030000K RADIATOR BACKING BOARD INSTALLATION ASSEMBLY
TS04201010000 HAND THROTTLE CONTROL ASSEMBLY
TS04202010000 FOOT THROTTLE CONTROL ASSEMBLY
TS04203010000 PULL WIRE ASSEMBLY
TB550.211A CLUTCH SUBASSEMBLY
TB604.212A CLUTCH CONTROL ASSEMBLY
TC02220090000K EXHAUST SYSTEM ASSEMBLY-1
TC02220090000K EXHAUST SYSTEM ASSEMBLY-2
TC02311220000 FRONT DRIVING AXLE ASSEMBLY-1
TC02311220000 FRONT DRIVING AXLE ASSEMBLY-2
TC02311220000 FRONT DRIVING AXLE ASSEMBLY-3
TC02311220000 FRONT DRIVING AXLE ASSEMBLY-4
TC02311220000 FRONT DRIVING AXLE ASSEMBLY-5
TC02311220000 FRONT DRIVING AXLE ASSEMBLY-6
TB554.312 FRONT BRACKET ASSEMBLY
TC02320010000K FRONT DRIVING WHEEL ASSEMBLY
FT550.34F.001 REAR DRIVING WHEEL ASSEMBLY
TB604.371 GEARBOX HOUSING ASSEMBLY
TB604.372T MAIN GEARSHIFT ASSEMBLY-1
TB604.372T MAIN GEARSHIFT ASSEMBLY-2
TB604.373T AUXILIARY GEARSHIFT ASSEMBLY
TS04374010000 GEARBOX CONTROL MECHANISM ASSEMBLY-1
TS04374010000 GEARBOX CONTROL MECHANISM ASSEMBLY-2
TS04374010000 GEARBOX CONTROL MECHANISM ASSEMBLY-3
TS04374010000 GEARBOX CONTROL MECHANISM ASSEMBLY-4
TB604.375B BREATH ASSEMBLY
TB554.381 SHUTTLE SHIFT ASSEMBLY
TB504.382 REAR AXLE CENTRAL TRANSMISSION ASSEMBLY-1
TB504.382 REAR AXLE CENTRAL TRANSMISSION ASSEMBLY-2
TS04383010000 DIFFERENTIAL LOCK CONTROL MECHANISM ASSEMBLY
TB604.384 REAR AXLE HOUSING ASSEMBLY
TS04385010000 SHUTTLE SHIFT CONTROL MECHANISM
TB450.391 LEFT FINAL TRANSMISSION ASSEMBLY
TB450.392 RIGHT FINAL TRANSMISSION ASSEMBLY
TC04401080000 REDIRECTOR OR STEERING COLUMN ASSEMBLY
TC02402740000K FULL HYDRAULIC STEERING PIPE ASSEMBLY-1
TC02402740000K FULL HYDRAULIC STEERING PIPE ASSEMBLY-2
TB550.411A PTO GEAR ASSEMBLY
TB550.412A PTO SHAFT ASSEMBLY
TS04413010000 PTO CONTROL ASSEMBLY
TB554.421E TRANSFER CASE ASSEMBLY
TB454.422 TRANSFER CASE TRANSMISSION ASSEMBLY-1
TB454.422 TRANSFER CASE TRANSMISSION ASSEMBLY-2
TS04423010000 TRANSFER CASE CONTROL ASSEMBLY
TB504.431B LEFT BRAKE ASSEMBLY
TB504.432B RIGHT BRAKE ASSEMBLY
TS04433010000 BRAKE SYSTEM CONTROL ASSEMBLY-1
TS04433010000 BRAKE SYSTEM CONTROL ASSEMBLY-2
TS04433010000 BRAKE SYSTEM CONTROL ASSEMBLY-3
TC02440090000K SEAT INSTALLATION ASSEMBLY
TS04452010000 FLOOR ASSEMBLY-1
TS04452010000 FLOOR ASSEMBLY-2
TS04452010000 FLOOR ASSEMBLY-3
TS04453020000 UPHOLSTERY ASSEMBLY
TS04454010000 CONTROLLING COVER PLATE ASSEMBLY
TS04455020000 BACK REAR MUD GUARD DECORATION PART
TS04456020000 DASHBOARD ASSEMBLY
TS04457010000 FRONT CONNECTING ASSEMBLY
TS04458010000 REAR CONNECTING ASSEMBLY
TS04461010000 SAFETY FRAME ASSEMBLY
TS04471020000 BONNET ASSEMBLY-1
TS04471020000 BONNET ASSEMBLY-2
TS04471020000 BONNET ASSEMBLY-3
TS04473010000 BONNET LOCKING DEVICE ASSEMBLY
TS04475030000 BONNET SEAL INSTALLATION ASSEMBLY
TS04481090000K ENGINE HARNESS INSTALLATION ASSEMBLY
TS04482010000K BODY HARNESS INSTALLATION ASSEMBLY
TS04483020000K FRONT LAMP HARNESS INSTALLATION ASSEMBLY
TS04484070000K REAR LAMP HARNESS INSTALLATION ASSEMBLY
TS04485010000 BATTERY INSTALLATION ASSEMBLY
TS04487010000 COMBINED INSTRUMENT ASSEMBLY
TB550.489B PREHEATING EQUIPMENT ASSEMBLY
TS04490010000 TOOL BOX ASSEMBLY
TS04501010000 OIL TANK INSTALLATION ASSEMBLY-1
TS04501010000 OIL TANK INSTALLATION ASSEMBLY-2
TS04503010000 OIL CONVEYING PIPE ASSEMBLY
TC02553070000K HYDRAULIC AUXILIARY OIL TANK ASSEMBLY
TB400.53D TOW MECHANISM ASSEMBLY
TC02551250000K LIFTER INSTALLATION ASSEMBLY-1
TC02551250000K LIFTER INSTALLATION ASSEMBLY-2
TC02551250000K LIFTER INSTALLATION ASSEMBLY-3
TS04552010000 LIFTER OPERATION ASSEMBLY
TC02561160000K SUSPENSION ASSEMBLY-1
TC02561160000K SUSPENSION ASSEMBLY-2
TC02581510000K OIL PUMP/PIPE/FILTER ASSEMBLY
TC02582090000K MULTI-WAY VALVE OIL PIPE ASSEMBLY
TB300.583A SINGLE-WAY HYDRAULIC OUTPUT ASSEMBLY 2
TC03620010000K SAFETY BELT INSTALLATION ASSEMBLY
FT404.74A.002 FRONT BALLAST ASSEMBLY
TC02741010000 FRONT BALLAST BRACKET ASSEMBLY
FT600.91.001 REAR BALLAST ASSEMBLY
1
1
2
2
3
3
3
4
5
6
6
6
7
7
7
7
8
8
8
8
9
10
10
10
11
11
12
12
13
14
15
16
17
18
19
20
21
Позиция на иллюстрации
Заводской номер детали
Название детали
TS04433010000(6)
TS04433010000(6)
BRAKE SYSTEM CONTROL ASSEMBLY
1
TE250.212D-05(2)
CLUTCH PEDAL RETURN SPRING
2
GBT894.1-25(2)
CIRCLIP FOR SHAFT
3
GBT97.1-24-A0P(2)
FLAT WASHER
4
TE250.433C-02(2)
GASKET
5
TB604.433E.1(2)
LEFT BRAKE PEDAL UNIT
6
GBT882-B10X30-A0P(6)
PIN SHAFT
7
GBT97.1-10-A0P(6)
FLAT WASHER
8
GBT91-3.2X22-A0P(6)
SPLIT PIN
9
GBT5783-M10X45-8.8-A3L (2)
HEXAGON BOLT
10
GBT6170-M10-8-A3L(3)
HEXAGON NUT, TYPE-1
11
TB604.433E.2(2)
RIGHT BRAKE PEDAL UNIT
12
FT300.43.110(2)
PULL ROD REAR FORK
13
TB604.212.5(3)
UPPER PULL ROD WELDMENT
14
TB704.433-04(4)
CONNECTING PIN
15
TB604.433E.5(2)
ROCKER UNIT HUB
16
JBT7940.1-M8X1(2)
STRAIGHT FORCED FILLING OIL CUP
17
GBT6170-M10-LH-8-A3L(4)
HEXAGON NUT, TYPE-1
18
TB604.433E-03(4)
LOWER PULL ROD
19
TA700.431A-01(6)
DEXTROROTATION LONG HOLE CONNECT FORK
20
TB504.433-09(4)
RETURN SPRING
21
TB704.433.5(2)
RIGHT RETURN SPRING CONNECTING PLATE WELDMENT
