Каталог запасных частей к технике: Lovol TS-4A504-038K. TS04383010000 DIFFERENTIAL LOCK CONTROL MECHANISM ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18.1
18.2
18.3
18.4
19
20
21
22
Позиция на иллюстрации Заводской номер детали Название детали
TS04383010000 TS04383010000 Differential lock control mechanism assembly
1 GBT3452.1-15.0X2.65G O-ring sealant used for hydraulic or pneumatic parts
2 FT300.38.158a Differential lock shift fork shaft
3 FT300.38.160 Differential lock retraction spring
4 FT300.38.159a Differential lock shift fork
5 FT300.38.190 Differential lock shift block
6 GBT879.1-6X40 Spring-type straight pin
7 GBT879.2-3.5X40 Spring-type straight pin
8 GBT5781-M8X40-4.8-A2L HEXAGON BOLT
9 GBT91-2X14-A0P Split pin
10 GBT879.1-6X35 Spring-type straight pin
11 GBT879.2-3.5X35 Spring-type straight pin
12 TS04383010003 Rocker arm weldment
13 Q72220 Bowl type expansion plug
14 TS04383010001 Differential lock pedal unit
15 GBT882-B6X28 Pin shaft
16 GBT97.1-6-A0P Plain washer
17 GBT6170-M8-8-A2L Hexagon nut, style 1
18 TG1204.435.4 Seal lining seat assembly
18.1 TG1204.435.2-01 Spherical shaft seat
18.2 TG1204.435.2-02 Spherical shaft lining
18.3 GBT93-6 Standard spring washer
18.4 GBT818-M6X14-4.8-A2L Cross recessed pan head screw
19 TB554.383-05 Adjusting washer
20 TB554.383-06 Adjusting washer
21 TB554.383-07 Adjusting washer
22 TB554.383-08 Adjusting washer
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
