Каталог запасных частей к технике: Lovol TS-4A504-038K. TC02311220000 FRONT DRIVING AXLE ASSEMBLY-4

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
21
22
22
23
23
24
25
26
27
28
Позиция на иллюстрации Заводской номер детали Название детали
TC02311220002(4) TC02311220002(4) FRONT AXLE
TC02311220000(4) TC02311220000(4) FRONT DRIVING AXLE ASSEMBLY
TC02311060006(2) TC02311060006(2) RIGHT FINAL TRANSMISSION ASSEMBLY
TC02311060005(2) TC02311060005(2) LEFT FINAL TRANSMISSION ASSEMBLY
1 TC02311020014 FRONT DRIVING SHAFT
2 TC02311020015 BOLT
3 TC02311010032 FLOATING OIL SEAL
4 GBT5783-M10X40-10.9-A3L HEXAGON BOLT
5 GBT93-10-A0P Standard spring washer
6 TC02311010050 BIG END COVER
7 TC02311010060 ADJUSTING GASKET
8 GBT276-6410 DEEP GROOVE BALL BEARING
9 TC02311020019 BIG END GEAR
10 GBT276-6310 DEEP GROOVE BALL BEARING
11 TC02311010055 GASKET
12 TC02311010054 LOCK WASHER
13 GBT5783-M8X35-8.8-A2L Hexagon head bolt
14 GBT3452.1-243X5.30G RUBBER O-SEAL RING
15 TC02311020020 END PINION
16 GBT276-6308 DEEP GROOVE BALL BEARING
17 TC02311010059 ADJUSTING GASKET
18 GBT893.1-90 CIRCLIPS FOR HOLE
19 TC02311010058 SEAL COVER
20 GBT893.1-102 CIRCLIPS FOR HOLE
21 TD904.311K.1-13 SCREW PLUG
22 GBT3452.1-21.2X2.65G RUBBER O-SEAL RING
23 TC02311060010 LEFT FINAL TRANSMISSION HOUSING
23 TC02311060012 RIGHT FINAL TRANSMISSION HOUSING
24 GBT301-51107 THRUSTBEARING
25 TC02311010057 BUSH
26 TC02311060011 END SPLINE SHAFT
27 GBT6172.1-M16-04-A3L HEXAGON THIN NUT
28 GBT5783-M16X50-10.9-A3L HEXAGON BOLT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
