Каталог запасных частей к технике: Lovol TS-4A504-038K. TB604.373T AUXILIARY GEARSHIFT ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1.1
1.2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
Позиция на иллюстрации Заводской номер детали Название детали
TB604.373T TB604.373T Assistant gear assembly
1 TB604.373T.4 SYNCHRONIZER ASSEMBLY
1.1 TB604.372T.3 SYNCHRONIZER ASSEMBLY
1.2 TB604.373T.3 CONE RING WELDMENT
2 GBT283-NUP210E Bearing
3 TB550.373-02 Circlip
4 TB550.373-03b Middle gear driving gear
5 TB550.373-12 Roller bearing
6 TB550.373-04b Spacing sleeve
7 TB550.373-05b Middle gear meshing gear seat
8 TB550.373-06a Middle gear meshing sleeve
9 GBT894.1-50 Circlip
10 GBT283-NUP308E Bearing
11 FT300.37.139 Assistant gear bearing cover
12 GBT93-10-A0P Standard spring washer
13 GBT5783-M10X30-8.8-A3L Hex bolt
14 FT300.37J.180 Spacing sleeve
15 GBT283-NF208 Bearing
16 GBT894.1-40 Circlip
17 TB550.373-08 Middle gear driven gear
18 TB550.373-09 Reverse gear meshing seat
19 FT300.37.111 Spacing sleeve
20 QLWZB120-K35X43X34ZW Needle bearing
21 FT450.37.103 Assistant gear driven gear
22 TB550.373-11a Limiting circlip
23 GBT894.1-35 Circlip
24 GBT283-NUP307E Bearing
25 TB550.373-16 AUXILIARY GEARSHIFT DRIVEN SHAFT
26 GBT20056-K25X31X20 NEEDLE AND CARRIER COMBINATION
27 TB550.373-15 LIMITING RETAINER RING
28 TB550.373-13 LIMITING RETAINER RING
29 TB550.373-14 LIMITING RETAINER RING
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
