Каталог запасных частей к технике: Lovol TS-4A504-038K. TB450.391 LEFT FINAL TRANSMISSION ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
5.1
5.1
5.2
5.3
5.3
5.4
5.5
5.5
5.6
5.7
5.8
5.9
5.9
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
20
21
Позиция на иллюстрации Заводской номер детали Название детали
TB450.391 TB450.391 LEFT FINAL TRANSMISSION ASSEMBLY
1 TB450.391-02 FINAL TRANSMISSION GEAR RING
2 TB450.391-01 LEFT FINAL TRANSMISSION HALF SHAFT
3 FT300.39.110 Driving Shaft Lock Piece
4 FT300.39.112 Driving Shaft Lock Bolt
5 TB450.391.1 FINAL TRANSMISSION PLANET BRACKET ASSEMBLY
5.1 FT300.39.111 Retainer Block
5.2 FT300.39.104 PLANET CARRIER
5.3 FT300.39.109 NEEDLE OUTER SPACER RING
5.4 TB450.391.1-01 FINAL TRANSMISSION PLANET GEAR
5.5 GBT309-P5X23.8-G2 NEEDLE
5.6 FT300.39.105 NEEDLE INNER SPACER RING
5.7 GBT879.1-5X26 PIN
5.8 QLWZB140-8X26 PIN
5.9 FT300.39.106 PLANET GEAR SHAFT
6 FT300.39.121 Adjusting Washer
7 FT300.39.122 Adjusting Washer
8 FT300.39.123 Adjusting Washer
9 FT300.39.113 SPACER BUSH
10 GBT276-6211 Deep Groove Ball Bearing
11 FT300.39.115 LEFT DRIVING SHAFT HOUSING
12 GBT276-6212 DEEP GROOVE BALL BEARING
13 GBT9877.1-FB70X95X10D SEAL RING
14 GBT3452.1-115X3.55G O-RING
15 FT300.39.116 OIL SEAL SEAT
16 GBT93-12-A0P Washer
17 GBT5783-M12X30-8.8-A3L Hexagon Bolt
18 FT300.39.136 REAR HUB BOLT LEFT
19 FT300.39.118 DRIVING SHAFT
20 FT300.39.137 WASHER
21 GBT6176-M16X1.5-LH-10- A3L HEXAGON NUT, TYPE-2
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
