Каталог запасных частей к технике: Lovol TE-354. TRANSMISSION CASE CONTROL MECHANISM ASSEMBLY-1

Тип техники

Марка

Модель

Схема

1.1

1.2

1.3

1.4

1.5

1.6

1.7

1.8

1.9

1.11

1.12

1.13

1.14

1.15

Позиция на иллюстрации	Заводской номер детали	Название детали
1	TE250.373F.1.1	MAIN GEARSHIFT CONTROL COVER ASSEMBLY
1.1	TE250.373F.1.1-01a	MAIN GEARSHIFT CONTROL ROD
1.1	GBT5782-M8X40-8.8-A2L	HEXAGON BOLT
1.2	GBT119.1-6h8X40-A0P	COLUMN PIN
1.3	FT800.37.138	GEARLEVER DUSTPROOF BONNET
1.4	FT250.37.248	STEEL WIRE RETAINER RING
1.5	GBT894.1-45	CIRCLIP FOR SHAFT
1.6	FT250.37.211	MAIN GEARLEVER SEAT
1.7	TE250.373F.1.1-03	PAD BLOCK
1.8	TE250.373F.1.1-02	GEARLEVER LOCATING PLATE
1.9	GBT854-8	STOPPING WASHER
1.11	FT250.37.183	GEARLEVER SPRING
1.12	FT300.37.164	GEARLEVER SPRING RETAINER RING
1.13	GBT879.1-5X35	SPRING COLUMN PIN
1.14	GBT879.1-8X35	SPRING COLUMN PIN
1.15	TE250.373F.1.1.1	MAIN GEARLEVER WELDMENT
2	GBT5783-M8X25-8.8-A2L	Hex head bolt
3	GBT93-8-A0P	Standard spring washer
4	TE250.373F.1.2	AUXILIARY GEARSHIFT LOWER CONTROL ROCKER WELDMENT
5	GBT879.1-6X24	Spring-type straight pin
6	GBT879.2-3.5X24	SPRING COLUMN PIN
7	GBT3452.1-12.5X1.80G	O-RING
8	Q72218	PLUG PIECE
9	GBT308-9.5-G200-b	STEEL BALL
10	FT704.42B.163	Retaining spring, fork shaft
11	GBT6172.1-M12-04-A3L	HEXAGON THIN NUT
12	GBT73-M12X25-14H-A3L	SLOTTED LOCKING SCREW
13	GBT5783-M6X20-8.8-A2L	Hexagon head bolt
14	GBT93-6-A0P	Standard spring washer
15	TE250.373F.1-03	SIDE-MOUNTED CONTROL LOWER COVER
16	TE250.373F.1-05	MAIN GEARSHIFT CONTROL TRANSFER ROD
17	TE354.373.1-01	SIDE-MOUNTED CONTROL UPPER COVER
18	TE250.373F.1-02	MAIN GEARSHIFT OUTER CONTROL FORK HEAD
19	TE250.373F.1-04	AUXILIARY GEARSHIFT CONTROL TRANSMISSION ROD
