Каталог запасных частей к технике: Lovol TE-354. LIFTER INSTALLATION ASSEMBLY-3

Тип техники

Марка

Модель

Схема

1

2

3

4

5

6

7

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

34

34

34

35

35

36

37

38

38

39

40

Позиция на иллюстрации	Заводской номер детали		Название детали
1	18FP.57.110		PRESSURE PLUG
2	GBT3452.1-15X2.65G		RUBBER O-SEAL RING
3	18FP.57.111		ADJUSTING WASHER
4	18FP.57.112		SAFETY VALVE SPRING
5	18FP.57.119		SAFETY VALVE CORE
6	18FP.57.101		SAFETY VALVE SEAT
7	GBT3452.1-9.5X2.65G		O-SEAL RING
8	GBT5783-M5X16		BOLT
9	GBT93-5		WASHER
10	18FP.57.102		FRONT COVER
11	18FP.57.103		FRONT COVER PAPER GASKET
12	18FP.57.104A		DISTRIBUTOR HOUSING
13	150D.55.227-2		SEAL RING
14	JBT1000-M10X1X12		HEXAGON SCREW PLUG
15	18FP.57.113-1		SLIDING VALVE
16	18FP.57.120		WASHER
17	18FP.57.115		WASHER
18	18FP.57.114		SLIDING VALVE RETURN SPRING
19	GBT894.1-15		CIRCLIP FOR SHAFT
20	18FP.57.106		RETAINER PLATE
21	18FP.57.107		REAR COVER PAPER GASKET
22	GBT896-4		RETAINER RING
23	14FP.57.105		DIAL PIN
24	14FP.57.104		LOCATING BLOCK
25	GBT308-6V		STEEL BALL
26	14FP.57.118		LOCATING SPRING SEAT
27	14FP.57.119		LOCATING SPRING
28	14FP.57.121		MAT
29	14FP.57.120		SCREW PLUG
30	GBT93-6		Standard spring washer
31	GBT5782-M6X60		BOLT
32	18FP.57.108		REAR COVER
33	TE250.57.102		HANDLE SHAFT
34	GBT97.1-8(2)		WASHER
35	TE250.57.103		NYLON BUSH
36	TE354.57.1.1		CONTROL ARM WELDMENT
37	TE250.57.106		PULL ROD
38	GBT91-2X18		SPLIT PIN
39	TE250.57.101		CONTROL ROCKER 1
40	GBT879-6X22		ELASTIC PIN

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
