Каталог запасных частей к технике: Lovol TE-354. LIFTER INSTALLATION ASSEMBLY-1
1
2
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | FT800.55A.237 | ELASTIC PIN | |
| 2 | 18.55.107 | UPPER PULL ROD FRONT CONNECTING PIN | |
| 3 | GBT5782-M10X45 | BOLT | |
| 4 | GBT93-8 | WASHER | |
| 5 | TE250.55A.112 | REAR END COVER | |
| 6 | 18.55.159 | REAR END COVER PAPER GASKET | |
| 7 | 18.55.141 | LIMITING PIN | |
| 8 | 18.55.108 | OIL DISCHARGING PLUG | |
| 9 | JBT982-12 | Compound seal washer | |
| 10 | GBT97.1-20 | WASHER | |
| 11 | TE354.55.1 | LIFTER ASSEMBLY | |
| 12 | TE250.55.011 | VENTILATION PLUG BODY WELDMENT | |
| 13 | 18.55.104 | WASHER | |
| 14 | 18.55.136 | OIL FILLING COVER CORE | |
| 15 | TE354.55.110 | DIPSTICK | |
| 16 | GBT5783-M8X20 | BOLT | |
| 17 | TE354.55.103 | UPPER COVER PLATE | |
| 18 | TE354.55.108 | UPPER COVER GASKET | |
| 19 | GBTT5783-M10X30-A3L | BOLT | |
| 20 | GBTT93-10-A0P | WASHER | |
| 21 | YT300B.55.114 | CYLINDER TRUNK | |
| 22 | E300.55.012 | PISTON ASSEMBLY | |
| 23 | E300.55.117 | RETAINER RING | |
| 24 | GBT3452.1-75X5.3 | O-RING | |
| 25 | GBT3452.1-90X3.55 | O-RING | |
| 26 | GBT3452.1-77.5X3.55 | O-RING | |
| 27 | E300.55.118 | RETAINER RING | |
| 28 | TE354.55.106 | CYLINDER HEAD | |
| 29 | GBT93-14 | WASHER | |
| 30 | GBT5785-M14X1.5X50 | BOLT | |
| 31 | GBT97.1-5 | WASHER | |
| 32 | GBT828-M5X6X4-22H | SCREW | |
| 33 | GBT5785-M14X1.5X60 | BOLT | |
| 34 | 300.55.138 | PIN | |
| 35 | E300.55.140A | SPEED DROP VALVE HAND WHEEL | |
| 36 | GBT879-4X22 | PIN | |
| 37 | TE354.55.109 | ADJUSTING VALVE ROD | |
| 38 | GBT1235-22X2.4 | O-RING | |
| 39 | YT18.55.129 | ADJUSTING VALVE | |
| 40 | 25.55.169 | PLUG ZG18 | |
| 41 | 25.55.109A | HEXAGON SCREW PLUG | |
| 42 | JBT982-18 | Combined Seal Gasket | |
| 43 | GBT1235-18X2.4 | O-RING |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
