TD800.503A OIL INLET/OUTLET PIPE ASSEMBLY
FT800.53.001 TOW MECHANISM ASSEMBLY
TS06551080000 LIFTER INSTALLATION ASSEMBLY-1
TS06551080000 LIFTER INSTALLATION ASSEMBLY-2
FT800.56A.001 SUSPENSION ASSEMBLY-1
FT800.56A.001 SUSPENSION ASSEMBLY-2
FT800.56A.001 SUSPENSION ASSEMBLY-3
TD1S581040000K OIL PUMP/PIPE/FILTER ASSEMBLY
TD1S582110000K HYDRAULIC SYSTEM EQUIPMENT ASSEMBLY-1
TD1S582110000K HYDRAULIC SYSTEM EQUIPMENT ASSEMBLY-2
TD1S582110000K HYDRAULIC SYSTEM EQUIPMENT ASSEMBLY-3
TD1S582110000K HYDRAULIC SYSTEM EQUIPMENT ASSEMBLY-4
FT800.74B.002 FRONT BALLAST BRACKET ASSEMBLY
FT800.74B.001 FRONT BALLAST ASSEMBLY
TS06801010000K BRAKE VALVE ASSEMBLY
TS06802010000 AIR CYLINDER ASSEMBLY
TS06803010000K AIR CONVEYING PIPELINE ASSEMBLY
TS06811010000 AIR CONDITION ASSEMBLY-CAB
TS06812010000 AIR CONDITION ASSEMBLY-ENGINE
FT804.91.001 REAR BALLAST ASSEMBLY
1
1
2
3
3
4
4
4
4
5
6
7
8
9
10
11
12
13
Позиция на иллюстрации
Заводской номер детали
Название детали
TD800.503A
TD800.503A
OIL INLET/OUTLET PIPE ASSEMBLY
1
Q67627
B-TYPE WORM TRANSMISSION HOSE CLAMP
2
FT700.50G.121
OIL RETURN PIPE
3
FT65.50.106
Hollow Bolt
4
JBT982-14
Compound seal washer
5
FT800A.50.162
OIL PIPE JOINT
6
FT800A.50P.081
OIL CONVEYING PIPE ASSEMBLY
7
GBT5783-M8X30-8.8-A2L
Hexagon Bolt
8
GBT97.1-8-A0P
Plain washer
9
GBT93-8-A0P
Standard spring washer
10
GBT6170-M8-8-A2L
Hexagon nut, style 1
11
TD800.503A-01
INSTALLATION BRACKET
12
FT800A.50.061a
FUEL FILTER ASSEMBLY
13
TD800.503J.1
OIL CONVEYING PIPE ASSEMBLY
