Каталог запасных частей к технике: Lovol TD-904. TD1C311010000K FRONT DRIVING AXLE ASSEMBLY-6

Тип техники

Марка

Модель

Схема

TD1C311010000K(6)

TD1C311010002K(5)

TD904.311K.1.1

1

2

3

3.1

3.2

4

4

5

5

6

6

7

7.1

7.1

7.2

7.2

7.3

7.3

7.4

8

8

9

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

Позиция на иллюстрации	Заводской номер детали		Название детали
TD1C311010000K(6)	TD1C311010000K(6)		FRONT DRIVING AXLE ASSEMBLY
TD1C311010002K(5)	TD1C311010002K(5)		FRONT AXLE
TD904.311K.1.1	TD904.311K.1.1		MAIN REDUCER ASSEMBLY
1	TD904.311K.1.1-09		BOLT
2	TD904.311K.1.1.3		DIFFERENTIAL ASSEMBLY
3	TD904.311K.1.1.2		GEAR SPIRAL VEVEL ASSEMBLY
3.1	TD904.311K.1.1.2-02		DRIVEN SPIRAL BEVEL GEAR
3.2	TD904.311K.1.1.2-01		DRIVING BEVEL GEAR
4	GBT5786-M10X1.25X20-10.9		HEXAGON BOLT
5	GBT93-10-A3L		Standard Spring Washer
6	TD904.311K.1.1-07		LOCK SHEET
7	TD904.311K.1.1.1		HOUSING
7.1	GBT5789-M14X80-12.9		HEXAGON FLANGE NUT
7.2	TD904.311K.1.1.1-02		BEARING COVER
7.3	TD904.311K.1.1.1-03		LOCATING BUSH
7.4	TD904.311K.1.1.1-01		HOUSING
8	GBT297-32012		TAPERED ROLLER BEARING
9	TD904.311K.1.1-06		NUT
10	TD904.311K.1.1-05		ADJUSTING GASKET
11	TD904.311K.1.1-11		BEARING
12	TD904.311K.1.1-01		GASKET
13	GBT119.1-5m6X12-A3L(2)		COLUMN PIN
14	TD904.311K.1.1-02		SHAFT SLEEVE
15	GBT297-33207		TAPERED ROLLER BEARING
16	GBT3452.1-31.5X1.80G		RUBBER O-SEAL RING
17	TC05311070060		OIL SEAL SEAT
18	GBT308-6-G100-b		STEEL BALL
19	TC05311070063		OIL SEAL
20	TC05311070062		OIL RETAINER DISC
21	TC05311070061		LOCKING NUT
22	TD904.311K.1.1-12		SPACER BUSH
23	YP4.2.2-21		ADJUSTING GASKET

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
