Каталог запасных частей к технике: Lovol TD-904. FT800.39.002 RIGHT FINAL TRANSMISSION ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
FT800.39.002
1
1
2
2
3
3
4
5
5
6
7
8
9
10
11
11.1
11.2
11.3
11.3
11.4
11.4
11.5
11.6
11.7
11.8
12
13
14
15
16
17
18
19
20
21
22
Позиция на иллюстрации Заводской номер детали Название детали
FT800.39.002 FT800.39.002 RIGHT FINAL TRANSMISSION ASSEMBLY
1 GBT6176-M20X1.5-10-A3L HEXAGON NUT, TYPE-2
2 FT800.39.130 WASHER
3 FT800.39.101d DRIVING WHEEL FIXING BOLT
4 FT800.39.012 DRIVING SHAFT WELDMENT
5 GBT9877.1-FB100X130X12D SEAL RING
6 FT800.39.120 OIL SEAL RETAINER RING
7 GBT297-30215 TAPERED ROLLER BEARING
8 FT800.39.103a HALF SHAFT HOUSING
9 GBT297-30214 TAPERED ROLLER BEARING
10 FT800.39.132 ADJUSTING WASHER
11 FT800.39.011 FINAL TRANSMISSION PLANET BRACKET ASSEMBLY
11.1 FT800.39.104 PLANET CARRIER
11.2 FT800.39.106b PLANET CARRIER PRESSURE PLATE
11.3 FT800.39.110 PLANET GEAR ROLL NEEDLE OUTER SPACER RING
11.4 FT800.39.019 NEEDLE
11.5 FT800.39.109 NEEDLE INNER SPACER RING
11.6 FT800.39.107 PLANET GEAR
11.7 FT800.39.111 PLANET GEAR SHAFT
11.8 QLWZB140-12X32 PIN
12 FT800.39.105a PLANET CARRIER FIXING BOLT
13 FT800.39.112a THRUST WASHER
14 FT800.39.108 FINAL TRANSMISSION GEAR RING
15 FT800.39.114 RIGHT HALF SHAFT
16 FT800.39.134 ADJUSTING WASHER
17 FT800.39.135 ADJUSTING WASHER
18 FT800.39.136 ADJUSTING WASHER
19 FT800.39.133 ADJUSTING WASHER
20 FT800.39.131 ADJUSTING WASHER
21 FT800.39.138 ADJUSTING WASHER
22 FT800.39.137 ADJUSTING WASHER
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
