Каталог запасных частей к технике: Lovol TD-904. FT800.39.001 LEFT FINAL TRANSMISSION ASSEMBLY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
FT800.39.001
1
2
3
4
5
5.1
5.2
5.3
5.3
5.4
5.5
5.5
5.6
5.7
5.8
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
20
21
22
Позиция на иллюстрации Заводской номер детали Название детали
FT800.39.001 FT800.39.001 LEFT FINAL TRANSMISSION ASSEMBLY
1 FT800.39.108 FINAL TRANSMISSION GEAR RING
2 FT800.39.113 LEFT HALF SHAFT
3 FT800.39.112a THRUST WASHER
4 FT800.39.105a PLANET CARRIER FIXING BOLT
5 FT800.39.011 FINAL TRANSMISSION PLANET BRACKET ASSEMBLY
5.1 FT800.39.106b PLANET CARRIER PRESSURE PLATE
5.2 FT800.39.104 PLANET CARRIER
5.3 FT800.39.110 PLANET GEAR ROLL NEEDLE OUTER SPACER RING
5.4 FT800.39.107 PLANET GEAR
5.5 FT800.39.019 NEEDLE
5.6 FT800.39.109 NEEDLE INNER SPACER RING
5.7 FT800.39.111 PLANET GEAR SHAFT
5.8 QLWZB140-12X32 PIN
6 FT800.39.131 ADJUSTING WASHER
7 FT800.39.132 ADJUSTING WASHER
8 FT800.39.133 ADJUSTING WASHER
9 FT800.39.134 ADJUSTING WASHER
10 FT800.39.135 ADJUSTING WASHER
11 FT800.39.136 ADJUSTING WASHER
12 FT800.39.137 ADJUSTING WASHER
13 FT800.39.138 ADJUSTING WASHER
14 GBT297-30214 TAPERED ROLLER BEARING
15 FT800.39.103a HALF SHAFT HOUSING
16 GBT297-30215 TAPERED ROLLER BEARING
17 FT800.39.120 OIL SEAL RETAINER RING
18 GBT9877.1-FB100X130X12D SEAL RING
19 FT800.39.101c DRIVING WHEEL FIXING BOLT
20 FT800.39.012 DRIVING SHAFT WELDMENT
21 FT800.39.130 WASHER
22 GBT6176-M20X1.5-LH-10-A3L HEXAGON NUT, TYPE-2
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
