Каталог запасных частей к технике: Lovol TD-1304. TS06551070000 LIFTER INSTALLATION ASSEMBLY-1

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
12
13
13
13
13
14
14
15
15
16
16
17
18
18
19
19
20
21
22
22
23
23
24
25
26
27
27
28
29
30
Позиция на иллюстрации Заводской номер детали Название детали
TS06551070000 TS06551070000 LIFTER INSTALLATION ASSEMBLY
1 GBT70.1-M8X25-8.8-A2L Inner Hexagon Screw
2 GBT93-8-A0P Standard spring washer
3 TS06551070010b OIL FILLING PIPE WELDMENT
4 GBT3452.1-32.5X1.80G O-ring sealant used for hydraulic or pneumatic parts
5 TS06551070013a BREATHER RUBBER PIPE
6 HF2902.50.3.12 HYDRAULIC OIL TANK BREATHER
7 Q67405200 Plastic Fastening Strip
8 TS06551070001d LIFTER ASSEMBLY
9 TS06551080025 BREATHER BRACKET
10 GBT16674.1-M16X45-10.9-A3L HEXAGON FLANGE NUT
11 GBT16674.1-M14X140-10.9-A3L HEXAGON FLANGE NUT
12 TS06551040011a LIFTING CYLINDER ASSEMBLY
12.1 TD2S551020011 OIL CYLINDER PIN SHAFT
12.2 TD2S551020012 SPRING LOCK PIN
12.3 TS06551040016 OIL CYLINDER
13 SPL-CO-M18-F3 HEXAGON NUT
14 GBT899-GM18-M18X55-10.9-A3L DOUBLE END STUDS
15 FT800.55A.116 PIN SHAFT
16 GBT899-GM18-M18X65-10.9-A3L DOUBLE END STUDS
17 FT800.55A.114c RIGHT OIL CYLINDER BRACKET
18 FT800.55A.105 WASHER
19 GBT91-6.3X40-A0P SPLIT PIN
20 FT800.55A.104c LEFT OIL CYLINDER BRACKET
21 GBT16674.1-M8X16-8.8-A2L Hexagon Flange Nut
22 GBT3452.1-32.5X1.80G(2) RUBBER O-SEAL RING
23 Q673B25 STEEL STRIP ELASTIC HOOP
24 TC04582390032 ADJUSTABLE JOINT
25 TC03551210009a OIL DISCHARGING PIPE WELDMENT
26 TD2S551010004 HOLLOW BOLT
27 JBT982-20 COMBINED SEAL GASKET
28 TC02551010005 SCREW PLUG M33
29 GBT16674.1-M8X50-8.8-A2L HEXAGON FLANGE NUT
30 TS06551070021 CONNECTING JOINT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
