TD2S485010000K
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Позиция на иллюстрации
Заводской номер детали
Название детали
TD2S485010000K
TD2S485010000K
BATTERY INSTALLATION ASSEMBLY
1
GBT6177.1-M8-8-A2L
Hexagon Flange Nut
2
GBT97.1-6-A3L
Plain washer
3
TC05485040003
PAD BLOCK
4
TC05485040010
CONNECTING WIRE
5
TD2S485010001K
BATTERY POWER WIRE ASSEMBLY
6
TF1204.485A.1
BATTERY ASSEMBLY
7
TB450.485.1
Battery shock absorbing pad
8
TS08485010004K
PULL ROD
9
GBT818-M8X55-4.8-A2L
CROSS SCREW
10
TC05485040005
HARNESS TIGHTEN CLIP
11
TC05485090008
POWER WIRE ASSEMBLY
12
GBT93-8-A3L
Standard Spring Washer
13
GBT16674.1-M8X16-8.8-A2L
Hexagon Flange Nut
14
3203505D9-L
Lock cable ties
15
FT65.48.092
Wire through ring
16
TC05485040004
FIXING BRACKET
17
Q67405200
Plastic Fastening Strip
18
GBT16674.1-M8X30-8.8-A2L
HEXAGON FLANGE NUT
19
TG1454.485-01
PROTECTIVECOVERING
20
TG1454.485.4
POWER SWITCH
21
TC05485090009
BRACKET
22
GBT62-M6-A2L
Butterfly Nut
23
GBT93-6-A3L
Standard Spring Washer
24
GBT97.1-8-A3L
Flat Washer
25
GBT6170-M8-8-A2L
Hexagon nut, style 1
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
